Unique UGP 14C Owner's Manual

Propane refrigerator
Hide thumbs

Advertisement

Quick Links

Download this manual
UGP 6C/8C/10C/14C
Propane Refrigerator
OWNER"S GUIDE
serial number:
APR2020V1

Advertisement

loading

Related Manuals for Unique UGP 14C

Summary of Contents for Unique UGP 14C

  • Page 1 UGP 6C/8C/10C/14C Propane Refrigerator OWNER”S GUIDE serial number: APR2020V1...
  • Page 3 UNIQUE UGP-6C/8C/10C/14C Propane Refrigerator Installation and Owner’s Manual WARNING WARNING FIRE OR EXPLOSION HAZARD CARBON MONOXIDE POISONING MAY If you smell gas: CAUSE DEATH OR INJURY 1. Open windows. 2. Do not attempt to light appliance and make When used without adequate combustion sure the appliance is in the OFF position.
  • Page 5 NOTE: The Combination Carbon Monoxide Alarm & Safety Shut-Off Instructions (CM Model), Owners/Installation Manual are stored inside the refrigerator. For Unique Appliances Support, Call Toll Free 1-877-427-2266 10. Regular maintenance of the fridge is critical to prevent unsafe levels of Carbon Monoxide. Before lighting the refrigerator at any time, clean the flue tube as per the Owner’s Manual &...
  • Page 7 M A N U F A C T U R E D A N D C E R T I F I E D B Y Unique Appliances “ & ” “ & ” Unique Appliances, 2245 Wyecroft Road Oakville, Ontario, Canada, L6L 5L7 Ph: 905-827-6154 Toll Free: 1-877-427-2266 Fax: 905-827-2027 www.Uniqueappliances.com...

  • Page 9: Table Of Contents

    T able of Contents Chapters Welcome Safety and Warnings Appliance Installation General Operating Instructions How to use the Refrigerator Maintenance & Service Troubleshooting & Suggested Spares Door Reversal and Removal Instructions Temperature Controls, Food Storage and Cleaning Parts & Warranty Carbon Monoxide Instructions (CM Model) –...

  • Page 11: Chapters

    Welcome & Congratulations ongratulations on your purchase of a UNIQUE refrigerator!. We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual very carefully.

  • Page 12: Safety And Warnings

    Safety and Warnings If you smell gas Open Windows • Don’t touch electrical switches • Extinguish any open flame • Immediately call your gas supplier • For your Safety Do not store or use gasoline or other flammable vapors and liquids in the •...
  • Page 13 Chapter Installation For best performance at high ambient temperatures, there must be free air circulation over the cooling unit at the rear of the refrigerator. Ensure that there is a free air space above the refrigerator and that the flue (chimney) on top of the cabinet is not covered in any way.
  • Page 14 Clearances Minimum clearances to combustible materials are: Top – 6” Sides – 2” Rear – 1” as shown in Figures. 1, 2 & 3. Note: DO NOT install the appliance directly on carpeting. Carpeting must be removed or protected by a metal or wood panel beneath the appliance, which extends at least the full width and depth of the appliance.
  • Page 15 connections should be checked for leaks with a non-corrosive leak detector and/or soap and water for a bubble check. – D ARNING O NOT USE FLAME TO CHECK FOR GAS LEAKS The gas supply system must incorporate a pressure regulator to maintain a supply pressure of not more than 12”...

  • Page 17: General Operating Instructions

    Chapter General Operating Instructions Importance of Leveling a Refrigerator The refrigerator must be adjusted to a vertical position in both directions. In an absorption refrigeration system, ammonia is liquefied in the finned condenser coil at the top rear of the refrigerator. The liquid ammonia then flows into the evaporator (inside the freezer section) and is exposed to circulating flow of hydrogen gas, which causes the ammonia to evaporate, creating a cold condition in the freezer.
  • Page 18 Gas Operation – for models with electronic ignition “Start-Up” Procedure Electronic Ignition (battery) 1. To start the refrigerator, turn the thermostat knob E to the maximum setting, #4. 2. Turn button G to “Gas” position, then push B button in first and hold, proceed to push in and hold the D button until you see the needle on the flame sensor C moving from the red into the green area.
  • Page 19 4. Adjust the thermostat knob to desired temperature setting after 8 hours of operation. CONTROLS – See Fig. #5 for a description of controls Figure. #5 Thermostat The refrigerator cooling temperature is controlled by a thermostat that can be adjusted by turning knob E to different settings to maintain the desired refrigerator temperature.

  • Page 20: How To Use The Refrigerator

    The setting of the thermostat is critical and we recommend it be adjusted to maintain a dry frost on the cooling fins (approx. 38° Fahrenheit or 3° Celsius). Adjust the thermostat knob closer to “Max” (clockwise) when the outside temperature rises. NOTE: When first turning the refrigerator on, move refrigerator controls to maximum, which is the recommended initial setting.
  • Page 21 RIDGE ECTION Inside the refrigerator compartment, the defrost water runs from a collector channel to a drip tray/cup at the rear of the refrigerator where it normally evaporates. If heavy frost has built up on the cooling fins creating a lot of defrost water. Be aware your water reservoir may overflow.
  • Page 22 Shut Down Procedure A. Turn gas valve knob to the “off” position B. If the refrigerator will not be in operation for a period of weeks, it should be emptied, defrosted, cleaned and the doors left open. The ice tray should also be dried and kept outside the cabinet, also turn off gas at the main supply source.

  • Page 23: Maintenance & Service

    Chapter Maintenance & Service The user should be aware of service that must be done on a regular schedule to keep the refrigerator operating properly. Installation must be by a licensed gas fitter in accordance with local codes or in the absence of local national Fuel Gas Code, ANSI Z233.1 and in Canada B149.2 Propane Storage and Handling Code (latest edition).
  • Page 24 Check burner flame for proper appearance. The flame should be light blue with no yellow at the tip. See figure #6 Fig. #6 Fig. #7 Burner Mounting Screw Burner Jet/Orifice The LP gas pressure should be checked and the main regulator readjusted if •...
  • Page 25 Warning - DO NOT use a pin or wire when cleaning the burner orifice as damage can occur to the precision opening. This can cause damage to the refrigerator or create a fire hazard. It will also create extremely dangerous levels of carbon monoxide.
  • Page 27 Chapter TROUBLESHOOTING INSTRUCTIONS & SUGGESTED SPARE PARTS TO KEEP ON HAND REFRIGERATOR DOES NOT COOL, CHECK LIKELY CAUSES: Burner orifice clogged. Clean. See section Maintenance & Service, C HAPTER Check to ensure refrigerator is level – (left to right and front to back). Restriction on airflow across cooling unit.
  • Page 28 Spare Parts The following is a list of commonly used parts which are available: Burner orifice • Burner • Electrode with wire • Thermocouple • Safety valve & Thermostat • Baffle • Contact your dealer or an authorized service center for parts and repairs as needed. Quote Model &...

  • Page 29: Door Reversal And Removal Instructions

    Chapter Door Removal & Reversal Instructions NOTE: The direction in which your refrigerator doors open (door swing) can be reversed, from left to right or right to left, by moving the door hinges from one side to the other. Reversing the door swing should be performed by a qualified person. 1.
  • Page 31 Chapter Temperature Controls NOTE: Due to the nature of a gas operated absorption fridge, temperatures in the fridge compartment will drop to freezing even on the lowest setting when the ambient temperature surrounding the fridge drops to or below 60° F/ 15.0° C overnight and will freeze your food or drink products.
  • Page 32 Looking Inside SHELF ADJUSTMENT Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting the shelves, remove all food. Crispers & Deli Drawers The crispers, located under the bottom refrigerator shelf, are designed for storing fruits, vegetables, and other fresh produce. Wash items in clear water and remove excess water before placing them in the crispers.

  • Page 33: Cleaning

    A freezer operates most efficiently when it is slowly loaded to 2/3 full. • ACKAGING OODS FOR REEZING To minimize dehydration and quality deterioration, use aluminum foil, freezer • wrap, freezer bags or airtight containers. Force as much air out of the packages as possible and seal them tightly. •...
  • Page 34 NOTES: Do not use razor blades or other sharp instruments, which can scratch the appliance surface when removing adhesive labels. Any glue left from tape or labels can be removed with a mixture of warm water and mild detergent, or, touch the glue residue with the sticky side of tape you have already removed.
  • Page 35 Chapter Parts Diagram and Lists – UGP 6C/8C/10C/14C UGP-6C...
  • Page 36 UGP-8C UGP-10C...
  • Page 38 CO-Monitor and Components – all units...
  • Page 39 UNIQUE – UGP 6C Item Code Cabinet Heat sink UGP-DL22502524 Drip tray UGP-DL22501294 Drainage hose UGP-DL00009088 Drip pan UGP-DL10001155 Hinge cover UGP-DL22001080 Screw UGP-DL00003005 Screw cap UGP-DL10001193 Top hinge UGP-DL22001079 Top hinge cover UGP-DL22001074 Freezer door - White UGP-DL90000008 Freezer door – Black UGP-DL90000009 Fridge door –...
  • Page 40 Item Code Top shelf UGP-DL22501296 Middle shelf UGP-DL22501297 Bottom shelf UGP-DL27501306 36-1 Ventilation hood UGP-DL27501310 36-2 Bottom wearing plate UGP-DL27501312 Cooling unit UGP-DL22503082 Heater UGP-DL27501293 Glass wool UGP-DL00006007 Insulation cover UGP-DL22501136 40-1 cover cap UGP-DL22501173 Baffle UGP-DL27501007 Baffle holder UGP-DL18502082 Checkpoint assembly UGP-DL27501365 43-1...
  • Page 41 Item Code Balcony spacer UGP-DL22502241 Connector UGP-DL10001114 Thermostat UGP-DL18301115 UGP-DL18301029 Connector UGP-DL10001115 Safety valve UGP-DL18301005 Connector UGP-DL22001180 Thermocouple UGP-DL10001349 Thermostat bracket UGP-DL18301012 Power cord holder UGP-DL28801267 Rotary switch UGP-DL10001213 Bracket UGP-DL10001271 Knob UGP-DL27501362 Thermostat Wire UGP-DL27501292 Thermocouple Wire UGP-DL10001350 Front bottom UGP-DL27501328 Rear bottom UGP-DL27501329...
  • Page 42 Item Code freezer shelf UGP-DL222501280 Screw cover UGP-DL27501363 Heat Shield UGP-DL18501044 Big brush UGP-DL22001096 Small brush UGP-DL27501318 UGP-9RV-SSO-C CO Detector 9RV SSO-C QMP-Interrupter Block Interrupter Block for CO-Monitored fridges QMP-Mosfet-C Mosfet Assembly - for CO-Monitored Models...
  • Page 43 UNIQUE UGP 8C Parts List Item Code Cabinet Heat sink UGP-DL22502524 Drip tray UGP-DL22501294 Drainage hose UGP-DL00009088 Drip pan UGP-DL10001155 Hinge cover UGP-DL22001080 Screw UGP-DL00003005 Screw cap UGP-DL10001193 Top hinge UGP-DL22001079 Top hinge cover UGP-DL22001074 Freezer door - White UGP-DL90000008 Freezer door –...
  • Page 44 Item Code Screw UGP-DL00003068 Castor UGP-DL14502072 Top shelf UGP-DL22501296 Middle shelf UGP-DL22501297 Bottom shelf UGP-DL27501306 36-1 Ventilation hood UGP-DL27501310 36-2 Bottom wearing plate UGP-DL27501312 Cooling unit UGP-DL22503082 Heater UGP-DL27501293 Glass wool UGP-DL00006007 Insulation cover UGP-DL22501136 40-1 cover cap UGP-DL22501173 Baffle UGP-DL27501007 Baffle holder UGP-DL22502227...
  • Page 45 Item Code Flame indicator UGP-DL18301013 Bracket UGP-DL27501355 Balcony spacer UGP-DL22502241 Connector UGP-DL10001114 Thermostat UGP-DL18301115 UGP-DL18301029 Connector UGP-DL10001115 Safety valve UGP-DL18301005 Connector UGP-DL22001180 Thermocouple UGP-DL10001349 Thermostat bracket UGP-DL18301012 Power cord holder UGP-DL28801267 Rotary switch UGP-DL10001213 Bracket UGP-DL10001271 Knob UGP-DL27501362 Thermostat Wire UGP-DL27501292 Thermocouple Wire UGP-DL10001350...
  • Page 46 Item Code Screw cover UGP-DL27501363 Heat Shield UGP-DL22501209 Big brush UGP-DL22001096 Small brush UGP-DL27501318 UGP-9RV-SSO-C CO Detector 9RV SSO-C QMP-Interrupter Block Interrupter Block for CO-Monitored fridges QMP-Mosfet-C Mosfet Assembly - for CO-Monitored Models...
  • Page 47 UNIQUE – UGP 10C Parts List Item Code Cabinet Heat sink UGP-DL22502524 Drip tray UGP-DL22501294 Drainage hose UGP-DL00009088 Drip pan UGP-DL10001155 Hinge cover UGP-DL22001080 Screw UGP-DL00003005 Screw cap UGP-DL10001193 Top hinge UGP-DL22001079 Top hinge cover UGP-DL22001074 Freezer door - White UGP-DL90000008 Freezer door –...
  • Page 48 Item Code Top shelf UGP-DL27501306 Middle shelf UGP-DL27501307 Bottom shelf UGP-DL27501415 36-1 Ventilation hood UGP-DL27501310 36-2 Bottom wearing plate UGP-DL27501312 Cooling unit UGP-DL22503082 Heater UGP-DL27501293 Glass wool UGP-DL00006007 Insulation cover UGP-DL22501136 40-1 Cover cap UGP-DL22501173 Baffle UGP-DL27501007 Baffle holder UGP-DL22502227 Checkpoint assembly UGP-DL27501365 43-1...
  • Page 49 Item Code UGP-DL18301029 Connector UGP-DL10001115 Safety valve UGP-DL18301005 Connector UGP-DL22001180 Thermocouple UGP-DL10001349 Thermostat bracket UGP-DL18301012 Power cord holder UGP-DL28801267 Rotary switch UGP-DL10001213 Bracket UGP-DL10001271 Knob UGP-DL27501362 Thermostat Wire UGP-DL27501292 Thermocouple Wire UGP-DL10001350 Front bottom UGP-DL27501328 Rear bottom UGP-DL27501329 Connector UGP-DL10001116 Spring UGP-DL10001145 Button...
  • Page 50 UNIQUE – UGP 14C Parts List Item Code Freezer door White - White UGP-DL38801127 Fridge door White - White UGP-DL38801128 Freezer door White – Black UGP-DL38801129 Fridge door White - Black UGP-DL38801130 Cover for Ice Tray UGP-DL03001004 Ice tray UGP-DL03001003...
  • Page 51 UNIQUE – UGP 14C Parts List Lower shield bracket UGP-DL38801045 Cabinet Top Hinge Opening cover UGP-DL22001080 Heat sink UGP-DL38801111 Drip tray UGP-DL38801012 Water sieve UGP-DL27801005 Drip pan UGP-DL10001155 Battery holder UGP-DL27501190 Battery UGP-DL00013848 Battery cover UGP-DL27501342 Heating Element UGP-DL38801108 Caster Wheel...
  • Page 52 UNIQUE – UGP 14C Parts List Connector UGP-DL10001405 Gas Valve Button UGP-DL18301034 Spring UGP-DL10001145 Thermocouple Connector UGP-DL22001180 Thermocouple UGP-DL10001523 On/Off Safety valve UGP-DL18301005 Outlet connector for safety valve UGP-DL10001406 Burner Connecting Pipe UGP-DL38801040 Complete check point UGP-DL10001477 Screw UGP-DL22501206 Washer...
  • Page 53 UNIQUE – UGP 14C Parts List UGP-9RV-SSO-C CO Detector 9RV SSO-C QMP-Interrupter Block Interrupter Block for CO-Monitored fridges QMP-Mosfet-C Mosfet Assembly - for CO-Monitored Models...
  • Page 55 (b) as to any prior defects in materials or workmanship covered by this warranty, the Product has not been repaired or altered by anyone except Unique; and (c) the model number and manufacture date label has not been removed, defaced or otherwise changed; and (d)
  • Page 57  Unique Appliances and the seller will not be liable for direct or indirect loss of foods caused by failure in operation. In case of failure, the owner must provide proof of purchase, Model, and Serial Number to the Seller or ...

This manual is also suitable for:

Ugp 6cUgp 8cUgp 10c
