- Page 1 260L / 9.0 cu. ft. SOLAR POWERED DC FRIDGE UGP-260L1 OWNER’S GUIDE serial number: FEB17V4...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important safety notes Installation Parts list Door removal and reversal instructions DC power connection Operation Cleaning Energy saving tips Troubleshooting Appliance information Parts diagram and list Notes Contact us Limited warranty Back Technical specifications... -
Page 3: Important Safety Notes
Congratulations! You have purchased one of the most efficient refrigeration products available on the market today. The Unique 260L1 solar powered DC fridge is designed to provide years of ef- ficient trouble-free operation. The design is optimized for energy savings with an efficient DC compressor and thick insulation. - Page 4 IMPORTANT SAFETY NOTES continued • To allow the interior to cool down properly, run the fridge for at least 4 hours empty before adding food. • This fridge is designed to operate on 12 or 24 volts DC ONLY. DO NOT CONNECT THIS FRIDGE TO AN AC (alternating current) POWER SOURCE.
- Page 5 It is not advised to connect an ap- pliance that has been damaged, especially damage to the electrical supply cable or refrigerant circuit. In the event of damage please contact your local product dealer or Unique Off-Grid Appliances for assistance. GENERAL SAFETY •...
- Page 6 IMPORTANT SAFETY NOTES continued supply cable. Also, be sure the electrical cable is not squeezed or bent when the appliance is being installed or moved. • Installation work and adjustments on the appliance must be carried out by qualified personnel only. Work performed by persons with inadequate technical knowledge may adversely effect the perfor- mance of the appliance, causing damage to the equipment, and void the warranty.
-
Page 7: Installation
INSTALLATION UNPACKING AND CLEANING Remove all packaging and securing tapes from the appliance. To avoid injury and causing damage to the appliance, be extremely cautious when using sharp or pointed tools to complete this task. Keep children away from the packaging material - DANGER OF SUF- FOCATION! Wash the inside and outside of the appliance with luke warm water and a mild soap or detergent. -
Page 8: Parts List
PARTS LIST PARTS LIST 1: Shelf 2: Freezer compartment 3: Bulb with cover 4: Thermostat 0 - 7 5: Door 6: Upper hinge 7: Lower hinge 8: Adjustable feet 9: Crisper 10: Detachable door rack 11: Middle hinge 12: Egg Tray 13: Power Cable 14: AC/DC Plug (optional for on-grid use) - Page 9 DOOR REMOVAL AND REVERSAL continued 5. Unscrew the adjustable feet (8) on the bottom. 6. Unscrew the lower hinge (7). 7. Remove the door (5). 8. Unscrew the middle hinge. 9. Remove the freezer door. 10. Unscrew the hinge pin from upper hinge (6) and screw it to the other side of the fridge.
-
Page 10: Dc Power Connection
POWER SOURCE, SUCH AS A SOLAR BATTERY SYSTEM OR CHARGE CONTROLLER. THE FRIDGE WILL AUTOMATICALLY OPERATE ON EITHER 12V OR UGP-260L1 Wiring Diagram Labe 24V DC. THE USER DOES NOT NEED TO MAKE ANY ADJUSTMENT. ATTENTION: Polarity is important in wiring this DC appliance. Be... - Page 11 DC POWER CONNECTION continued IN-LINE FUSE A 15A in-line fuse is provided with this fridge in order to protect the wiring. For 12V operation, use a 15A fuse. A standard automobile fuse is recommended and the fuse should be wired to the positive (“+”) side of the system close to the positive battery terminal.
-
Page 12: Operation
OPERATION Your Unique fridge, like any battery-powered refrigerating appli- ance, requires different care than appliances plugged into an elec- tric utility. Prudent operation is the key to extended service. STARTING THE FRIDGE After the fridge has been properly connected to the 12 or 24 VDC power source, the compressor will automatically turn on and the cabinet will begin cooling. - Page 13 OPERATION continued ADJUSTMENTS As the ambient temperature changes with the season, it may be nec- essary to adjust the thermostat to achieve the proper internal tem- perature. If the room/ambient temperature approaches the appliance’s internal operating temperature, the appliance will not function as it should.
- Page 14 OPERATION continued DEFROSTING Before cleaning or repositioning the fridge, you must DISCONNECT the appliance from the electrical power supply. DEFROSTING THE UNIT The fridge compartment will become pro- gressively covered with frost. This should be removed periodically with a plastic scraper. However, when the ice becomes very thick on the interior walls, complete defrosting should be carried out.
- Page 15 OPERATION continued WATER CATCH BASIN There is a water catch basin located at the back of the fridge for excess water or as a result of defrosting. The hot condenser coil runs into the water catch basin and evaporates the water slowly: NOTE: Take notice when doing a complete defrost as the water catch basin could overfill with large volumes of water going in the water catch basin all at once.
-
Page 16: Cleaning
CLEANING Internal Cleaning Wash the inside of the appliance with luke warm water and a mild soap. Never use abrasive or corrosive cleaning agents, steel wool, scouring sponges, chemical cleaning agents, or highly perfumed cleaning products to clean the interior as these will damage the sur- face and leave behind a strong odor. -
Page 17: Troubleshooting
TROUBLESHOOTING Before contacting a service technician, your local product dealer or Unique Off-Grid Appliances, please check the following points. If you contact a technician to repair a fault listed below, or to repair a fault caused by misuse, abuse, or faulty installation, a charge will be made even if the appliance is under warranty. - Page 18 TROUBLESHOOTING continued Excessive frost • Is the weather hot and humid? If so, this will and ice has increase the rate of frost build-up in the built up cabinet. • Ensure that stored food is properly packaged. • Check that the door is closed and has a good seal, and that nothing is preventing the door from closing properly.
- Page 19 UGP-260L1 PARTS DIAGRAM AND LIST...
- Page 20 PARTS DIAGRAM AND LIST continued Item # Part # Description UGP-BCD260JS-001 Upper hinge cover UGP-BCD260JS-002 Upper hinge group UGP-BCD260JS-003 Plugs UGP-BCD260JS-007 Adjustable foot UGP-BCD260JS-008 Lower hinge parts UGP-BCD260JS-009 Flange screw M5x16 UGP-BCD260JS-010 Low adjustable foot UGP-BCD260JS-011 Screw ST3x10 UGP-BCD260JS-012 Lamp cover UGP-BCD260JS-013 Thermostat regulator knob UGP-BCD260JS-015 Screw ST3.5x12 UGP-BCD260JS-017 Thermostat shell...
- Page 21 PARTS DIAGRAM AND LIST continued Item # Part # Description UGP-BCD260JS-035 Middle hinge UGP-BCD260JS-036 Door switch UGP-BCD260JS-042 Compressor connect cable UGP-BCD260JS-043 The speed resistance cable UGP-BCD260JS-044 Trouble light and cable UGP-BCD260JS-045 Plug UGP-BCD260JS-046 Back cover UGP-BCD260JS-047 Compressor base UGP-BCD260JS-048 Process tube UGP-BCD260JS-049 Compressor UGP-BCD260JS-051 Drip tray UGP-BCD260JS-052 Drier filter...
-
Page 22: Appliance Information
APPLIANCE INFORMATION (manual copy - keep with your records) To make care and servicing of your solar powered DC fridge easy and efficient, please record the following information for future reference: Model: Serial Number: Purchased From: Date Purchased: NOTES... -
Page 23: Contact Us
This Warranty is made only to the first purchaser (”original purchaser”) who acquires this fridge for his/her own use and will be honored by Unique Gas Products Ltd. and by the Seller. Purchaser must retain their receipt as proof of purchase date. - Page 24 56 W 12V/24V AV. RUN CURRENT 4.5A on 12V - 2.5A on 24V FRIDGE TEMP. RANGE -4˚C to +10˚C FREEZER TEMP. RANGE -15˚C to -6˚C © 2017 Unique Gas Products Ltd., 2245 Wyecroft Road, Oakville, Ontario, Canada, L6L 5L7 www.uniqueoffgrid.com...
