ASSEMBLY MANUAL / OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 570U and is the answer not in the manual?

Questions and answers

Bill Bruce
February 3, 2025

Need operators manual for Schwann 220 exercise bike

0

Subscribe to Our Youtube Channel

Related Manuals for Schwinn 570U

Summary of Contents for Schwinn 570U

  • Page 1 ™ ASSEMBLY MANUAL / OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions Operations Safety Warning Labels / Serial Number Adjustments Initial Setup Quick Start / Manual Program Parts Hardware Tools Pausing or Stopping Assembly Results Leveling the Bike GOAL TRACK Statistics Moving the Bike Console Setup Mode Maintenance Console Features Troubleshooting...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions. •...

  • Page 4: Safety Warning Labels / Serial Number

    SAFETY WARNING LABELS AND SERIAL NUMBER • Set up and operate this machine on a solid, level, horizontal surface. • is the recommended safe distance for access, passage and emergency dismounts from the machine. Keep third parties out of this space when machine is in use. not hit the user.
  • Page 5 SPECIFICATIONS Maximum User Weight: Total Surface Area (footprint) of equipment: Machine Weight: Power Requirements (AC Adapter): 141cm (55.6”) 105cm (41.3”) 54cm (21.4”) please follow the prescribed methods at an approved waste center. Before Assembly Select the area where you are going to set up and operate your machine. For safe operation, the location must be along the side used to access the machine and to the rear of the machine clear.

  • Page 6: Parts

    PARTS 13 (R) 12 (L) Item Qty Description Item Description Main Assembly Seat Post Front Stabilizer Adjustment Knob Rear Stabilizer Seat Top Shroud Mast Gasket Console Water Bottle Holder Handlebars AC Adapter Console Handlebar Mount Cover Note: Media Cable is in a bag.

  • Page 7: Hardware

    HARDWARE / TOOLS Item Description Lock Washer M8 Curved Washer M8 Flat Washer M8 Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware after the proper assembly of your machine.

  • Page 8: Assembly

    ASSEMBLY 1. Attach Stabilizers to Main Frame Note: front stabilizer point forward, and the Schwinn decal on the rear stabilizer faces outward from the machine. ® 6 mm 6 mm 2. Install Console Mast, Mast Gasket and Top Shroud on Main Assembly NOTICE: Shroud snap into the Main Assembly.
  • Page 9 3. Install Handlebars on Console Mast NOTICE:...
  • Page 10 4. Install Console on Console Mast Note: NOTICE:...
  • Page 11 5. Install Seat Post on Frame NOTICE: Make sure the Adjustment Knob engages the Seat Post. Do not set the Seat Post position higher than the stop mark (STOP) on the tube. STOP 6. Attach Seat to Seat Post NOTICE:...
  • Page 12 7. Install Pedals If the threads strip due to improper installation, then the Pedals can disengage from the bike and/or break while under usage, which can result in serious injury to the user. Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is based from a seated position on the bike.
  • Page 13 8. Install Water Bottle Holder Note: 9. Connect AC Adapter 10. Final Inspection Inspect your machine to ensure that all hardware is tight and components are properly assembled. Be sure to record the serial number in the field provided at the front of this manual. Do not use or put the machine into service until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s Manual.

  • Page 14: Leveling The Bike

    BEFORE YOU START Leveling Your Bike Levelers are found on each side of the Rear Stabilizer. Turn the knob to adjust the stabilizer foot. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur.
  • Page 15 FEATURES Console Water Bottle Holder Handlebars with Elbow Pads MP3 Input Adjustable Seat USB Port Seat Slider Adjustment Knob Seat Post Adjustment Knob Speakers Pedals Stabilizers Media Tray Levelers Fully Shrouded Flywheel Bluetooth ® Transport Rollers Media Cable Power Connector WARNING! Use the values calculated or measured by the machine’s computer for reference purposes only.

  • Page 16: Console Features

    Console Features The Console provides important information about your workout and lets you control the resistance levels while you display with touch control buttons to navigate you through the ™ exercise programs. Note: Though your machine is Bluetooth ® ® enabled connection.
  • Page 17 Schwinn DualTrack Display ™ Upper Display Data 40% 70% Program Display Intensity Display Heart Rate Zone Display The Heart Rate Zone shows which zone the current heart rate value falls into for the current User. These Heart Rate Consult a physician before you start an exercise program.
  • Page 18 Achievement Display workouts. The Console display will congratulate and inform the User of their achievement, along with a celebratory sound. Lower Display Data Speed Time tional time of the machine. Note: Distance Note: To change the measurement units to English Imperial or metric, refer to the “Console Setup Mode” section in this manual.

  • Page 19: Bluetooth ® Connectivity

    Workout with Other Fitness Apps ® USB Charging Note: Review, understand, and follow all warning instructions and the correct operation as supplied with your Virtual Reality equipment. No one under the age of 13 should use this exercise equipment or the Virtual Reality experience. Before starting a workout with the Virtual Reality experience, be sure the workout area is and will be clear throughout the workout, and that all persons or pets are restricted from the workout area.

  • Page 20: Remote Heart Rate Monitor

    Remote Heart Rate Monitor Monitoring your Heart Rate is one of the best procedures to control the intensity of your exercise. Contact Heart Rate Note: The heart rate chest strap must be an uncoded heart rate strap from Polar Electro or an uncoded POLAR compatible model.
  • Page 21 in that target zone for over 20 minutes. The longer you maintain your target heart rate, the more fat your body will burn. The graph is a brief guideline, describing the generally suggested target heart rates based on age. As noted above, your optimal target rate may be higher or lower.

  • Page 22: Operations

    OPERATIONS What to Wear How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.

  • Page 23: Quick Start / Manual Program

    Push OK to set. Note: Quick Start ( Manual ) Program Manual Workout, each column represents a 2 minute time period. The active column will advance across the 1. Sit on the machine. 3. Push the QUICK START button to start the Manual program. Note: to end the workout.
  • Page 24 Edit User Profile 2. Push the OK button to select the User Profile. option. screen. 4. The Console display shows the NAME prompt and the current User Profile name. Note: The User name will be blank if this is the first edit. The name of a User Profile is limited to 10 characters. Push the OK button to accept the displayed User name.
  • Page 25 buttons to change the prompt. Note: Mode screen. 4. The Console display shows the RESET prompt and the current User Profile name. Push OK to start the Reset User 6. Push OK to make your selection. Changing Resistance Levels program. To rapidly change the resistance level, push the desired Resistance Level Quick Button. The Console will adjust Note: Once a User views all the Categories, they will be expanded to display the Programs within each of the Categories.
  • Page 26 CHALLENGES Interval Stairs the Goal value. 1. Sit on the machine. 2. Push the USER button 3. Push the Programs button. 4. Push the elect a Category of Workout. elect a Profile Workout, and push OK. 6. Use to select a , and push OK.
  • Page 27 Recovery Test Program Note: From an elevated heart rate, select the Recovery Test Program. The Console will show “STOP EXERCISING” and the heart rate. You must grip the heart rate sensors for the duration of the test if not using a Remote Heart Rate Monitor. late your recovery score.

  • Page 28: Pausing Or Stopping

    4. Push the Custom Program 1. Sit on the machine. 3. Push the Programs button. 4. Push the To continue in the Custom Program, push the Left button and the Console shows Custom Program again. Push OK. 6. To edit the Custom Program, use the to adjust the resistance values.

  • Page 29: Goal Track Statistics

    play the value. HR signal, the Console automatically goes into Sleep Mode. ™ USER button to select a User Profile. 2. Push the GOAL TRACK button. The Console will display the LAST WORKOUT values and activate the corresponding Achievement light. Note: Goal Track statistics can be viewed even during a workout.

  • Page 30: Console Setup Mode

    CONSOLE SETUP MODE 8. Push the “INSERT USB” prompt. I . The Console will record the Statistics to the USB Note: 9. Push the OK. The user workouts have been reset. When a User performs a workout that surpasses the “LONGEST WORKOUT” or of the previous workouts, the Console will congratulate with an audible sound and tell the User the new achievement.

  • Page 31: Maintenance

    MAINTENANCE Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is necessary to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done.
  • Page 32 Maintenance Parts Console HR Cables Flywheel Console Mast CHR Sensors Brake Assembly Pedals Seat RPM Sensor Crank Arms Seat Post w/ Slider Left Shroud Adjustment Knob Servo Motor Power Inlet Seat Post Shroud Right Shroud Water Bottle Holder Top Shroud Rear Stabilizer Handlebar Mount Cover Mast Gasket...

  • Page 33: Troubleshooting

    TROUBLESHOOTING Condition/Problem Things to Check Solution No display/partial display/ Make sure unit is plugged into a functioning wall outlet. unit will not turn on outlet Check connection on Connection should be secure and undamaged. Replace console adapter or connection at unit if either are damaged. Check data cable integrity All wires in cable should be intact.
  • Page 34 Condition/Problem Things to Check Solution No speed/RPM reading, Check data cable integrity All wires in cable should be intact. If any are cut or crimped, Console displays “Please replace cable. Pedal” error code Check data cable Be sure cable is connected securely and oriented properly. connections/orientation Small latch on connector should line up and snap into place.
  • Page 35 Condition/Problem Things to Check Solution Fan will not turn on, but Check for blockage of fan Console operates rial from fan. If necessary, detach the Console to help with removal. Replace the Console if unable to remove blockage. Unit rocks/does not sit Check leveler adjustment Adjust levelers until bike is level.
  • Page 36 ™ ™ ™ ™ ™ ™...
