Schwinn 190 How To Update Firmware

NOTICE: This addendum provides instructions on how to update Console firmware version R5.103.40, 44, or 50 to version 63 for
the Schwinn 190 / 590U Upright and Schwinn
™
when paired to an app on a phone or tablet, and will allow the Console to accept future updates through the JRNY
If you need assistance, please call
side US/Canada). To find your local distributor, go to: www.nautilusinternational.com
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand
all Warnings on this machine.
Nautilus, Inc., www.NautilusInc.com, 5415 Centerpoint Parkway, Groveport, OH 43125 U.S.A. - Customer Service: North America (800) 605-3369, csnls@nautilus.com | outside
U.S. www.nautilusinternational.com | Printed in China | © 2023 Nautilus, Inc. | Schwinn, Schwinn logo and JRNY are trademarks owned or licensed by Nautilus, Inc., registered or
otherwise protected by common law in the United States and other nations. |
Refer to the Assembly Manual for complete safety instructions.
Disconnect all power to the machine before you service it.
The following procedure should only be applied to a fully
assembled and inspected machine for correct performance
in accordance with the Owner's Manual.
Section 1 - To update the firmware version:
1.
Unplug the AC adapter from the wall outlet and machine.
2.
Insert the supplied USB Flash Drive into the USB port
on top of the Console.
Note: Image provided for placement of the USB Port only.
Image may not match your machine.
3.
Plug the AC Adapter into the machine and wall outlet.
Note: The update takes about 5 minutes. Steps 4 - 7 (below)
describe what will happen during that time.
4.
When power is supplied to the machine with the
USB Flash Drive installed, the screen will stay dark for
approximately 1 minute. This delay in the screen coming on
is the only indication that the update is in progress.
5. Once Phase 1 of the update is complete, the screen will
briefly come on and display "THANKS FOR CHOOSING
SCHWINN CARDIO". Then Phase 2 of the update process
will begin immediately.
Schwinn
TM
Update Console Firmware
Nautilus Customer Service (if purchased in US/Canada) or your local distributor (if purchased out-
190/290/590U/590R Bike
™
290 / 590R Recumbent Bikes. This will improve the Console function
™
ORIGINAL DOCUMENT - ENGLISH VERSION ONLY
USB port (Schwinn 290 shown)
™
USB port
Addendum
8030556.011523.A
app.
™
