L2t Liquid Level Controller
October 2023
Figure 7. Configure
Configure
Guided Setup
Initial Setup
Calibrate
Calibrate Time Delay
Calibration Status
Calibration Date
Hours
Minutes
Person
Location
16
Manual Setup
Instrument
Instrument Clock
Instrument Date
Instrument Time
Device Information
Tag
Long Tag
Descriptor
Date
Message
Instrument Serial Number
Sensor Serial Number
Instrument Temperature
Units
Instrument
Temperature
Instrument Temperature Lower Limit
Instrument Temperature Upper Limit
Limit Switch
Limit Switch Setup
Limit Switch One
Limit Switch Two
Normal Position
Action
Trigger Point
Deadband
Limit Switch Status: Switch State
PV
PV High and Low Points for
Open/Close States
Direct or Reverse Action
PV Lower Alert Point
PV High Alert Point
PV Damping
Input Filter
Instruction Manual
D104782X012
Alert Setup
See figure 8
Mapping
Dynamic Variables
Primary Variable
Secondary Variable
Tertiary Variable
Quaternary Variable
HART
Communication Settings
Polling Address
Loop Current Mode
