- Page 1 032023 /SPECIALTY VR1-D DELI SERVICE MERCHANDISER U S E R M A N U A L...
-
Page 2: Table Of Contents
Remove Rear Raceway 17 Electrical Conduit (Electrical Box) 17 Wiring Diagram Index 18 Wiring Diagrams DOE 2012 Hussmann refrigerated merchandisers configured for sale for use in the United States Energy meet or surpass the requirements of the DOE 2012 energy efficiency standards. ciency... -
Page 3: Notice/Warning
Notice WARNING 1. DO NOT load or stand over top of case. Glass breakage may occur if precautions are disregarded. *Broken glass can cause lacerations, cuts, and puncture wounds which may result in severed arteries or tendons, amputations, eye injuries, or exposure to disease. -
Page 4: General Information
Shortages: Check your shipment for any possible shortages of material (See Parts List page 9). If a shortage should exist and is found to be the responsibility of Hussmann Chino, notify Hussmann Chino. If such a shortage involves the carrier, notify the carrier immediately, and request an inspection. -
Page 5: Case Sections
CASE SECTIONS VR1-D VR1-D-8 PLAN... -
Page 6: Installation
Case is to arrive at store as was shipped form factory. See reference above for proper shipment referencing. (Not actual case) Receiving case Upon receiving your new Hussmann Case all equipment should be thoroughly examined for shipping damage before and during unloading. This equipment has been carefully inspected at our factory. -
Page 7: Lifting And Transport
1. The VR1-D merchandiser can be raised at one Instructions end underneath the deck with a forklift or J-Bar if 1. The VR1-D can be lifted by a forklift at forklift is not accessible to allow the placement of typical lifting points. -
Page 8: Skid Removal
Installation (cont’d) Skid Removal and Placement (Channel-Style panels. Check for damage before discarding packaging. Legs) In the case a fork lift truck is not available follow Important: See lifting instructions to properly lift the demonstration below to properly lift case us- case when being placed on dollies or permanent ing a Johnson Bar (J-Bar) to place on dollies to location. -
Page 9: Level Case
Installation (cont’d) Leveler Adjustment (Channel-Style Legs) Note: To avoid removing concrete flooring, begin line up levelling from the Highest point of Position the case at the highest point. Set a long the store floor. magnetized level (4ft [1220 mm] or more) on either underneath the deck or on top of the case. -
Page 10: Setting And Joining
Installation (cont’d) Setting and Joining The sectional construction of these models enable them to be joined in line to give the effect of one continuous display. An alignment pin kit is supplied with every case and must be used in alignment. Leveling IMPORTANT! IT IS IMPERATIVE THAT CASES BE LEVELED FROM FRONT TO BACK AND... - Page 11 Installation (cont’d) Setting STEP 2. Set first case over the highest part of STEP 1. Using case blueprints, measure off and the floor and adjust legs so that case is level. mark on the floor the exact dimensions of where the cases will sit.
- Page 12 Installation (cont’d) STEP 6. To compress butyl at joint, use two Jurgenson wood clamps. Make sure case is level STEP 4. Apply liberal bead of case joint sealant from front to back and side to side on inside (Silicone) to first case. Sealant area is shown in bulkheads at joint.
-
Page 13: Body Panels Install
Installation (cont’d) Front Body Panel Install Rear Body Panel Install -No tools will be needed to install body the A screwdriver or battery powered driver front panels. will be required for the rear panels -The front body panel will slide behind the -Fasten the rear upper body panel using upper retaining channel and rest atop the (6) stainless steel finish screws... -
Page 14: Refrigeration
If in the case pressure sealed at factory already. Seal both the inside was not maintained, contact your Hussmann and outside. We recommend using an expanding Service Technician for further assistance. -
Page 15: Refrigerant Spec Sheet
Refrigeration Spec Sheet... -
Page 16: Electrical
Electrical Field Wiring Merchandiser Electrical Data Field wiring must be sized for component am- Technical data sheets are shipped with this peres stamped on the serial plate (refer to pg manual. The data sheets provide merchandiser 16 for location). Actual ampere draw may be electrical data. -
Page 17: Remove Rear Raceway
Electrical Cont’d Remove Rear Raceway Electrical Conduit (Electrical Box) The merchandisers electrical conduit can be The merchandisers electrical access is located found inside the compartment at the rear. Re- at the rear of the case. Fasteners must be re- moving the raceway will gain access to the elec- moved in order to gain access. -
Page 18: Wiring Diagram Index
Wiring Diagram Index VR1-D-4-R 3015037 VR1-D-6-R 3015038 VR1-D-8-R 3015039 VR1-D-12-R 3015040... -
Page 23: User Information
User Information Start Up Load Limit See the merchandisers Data Sheet Set for refrig- Each Merchandiser has a load limit. Shelf life of erant settings and defrost requirements. Bring perishables will shorten if load limit is violated. merchandisers down to the operating tempera- tures listed on the Data Sheet. -
Page 24: Maintenance
Maintenance Case Cleaning Clean frequently to avoid build-up of hard, stub-born stains. A stainless steel cleaning solution may be Long life and satisfactory performance of any used periodically to minimize scratching and remove equipment are dependent upon the care it stains. -
Page 25: Do's And Do Not's
Maintenance Cont’d ꞏ Remove the product and all loose debris to avoid clogging the waste outlet. ꞏ Store product in a refrigerated area such as a cooler during the cleaning process. Remove only as much product as can be taken to the cooler in a timely manner. -
Page 26: Troubleshooting
Troubleshooting Problem Possible Cause Possible Solution Case temperature is Ambient conditions may Check case position in store. Is the case located near an too warm. be affecting the case open door, window, electric fan or air conditioning vent that operation. may cause air currents? Case must be located minimum 15 Ft away from doors or windows. - Page 27 Troubleshooting Cont’d Problem Possible Cause Possible Solution Water has pooled Case drain is clogged. Clear drain. under case. Repair as needed. PVC drains under case may have a leak. Seal as needed. Case tub has unsealed opening. Install case to case joint and seal as needed. If the case is in a line- up, case to case joint is missing or unsealed.
- Page 28 August 31, 2018 This warning does not mean that Hussmann products will cause cancer or reproductive harm, or is in violation of any product-safety standards or requirements. As clarified by the California State government, Proposition 65 can be considered more of a ‘right to know’...
- Page 29 To obtain warranty information or other support, contact your Hussmann representative. Please include the model and serial number of the product. Hussmann Warranty / Technical Assistance (800) 592-2060 Hussmann Corporation, Corporate Headquarters: Bridgeton, Missouri 63044 2014...
