BN Thermic W16C Instructions Manual

Thank you for purchasing a BN Thermic product. Manufactured to a high standard, this product will,
if used according to these instructions and properly maintained, give you years of trouble free
performance. Please ensure instructions remain with your customer for their reference.
REGISTER: PLEASE REGISTER THIS PRODUCT ONLINE TO ACTIVATE
IMPORTANT: PLEASE READ THESE INSTRUCTIONS, NOTE THE SAFE
OPERATIONAL REQUIREMENTS, WARNINGS, AND CAUTIONS. USE THIS
PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURY AND WILL INVALIDATE THE WARRANTY.
S E C T I O N A – U S E R I N S T R U C T I O N S .
For installation instructions go to page 4
1 . INT RODUCT ION & SPECIF ICAT ION .
The W16C Wi-Fi Thermostat is an easy to install and use
7 Day, 6/1 Day or 5 / 2 Day Programmable Room
Thermostat which offers six time and temperature
changes per day. It is designed to provide automatic time
and temperature control for underfloor heating using air
temperature and a floor sensor. The thermostat works in
conjunction with an app available on Google Play or the
App Store. All settings are stored in the controller with
battery back-up.
Programming
Power Supply
Floor Temperature Sensor
Temperature Range
Display
No. Programs Per Day
Tamper Resistant
Dimensions
Electrical Protection
Complies with:
YOUR GUARANTEE AT www.bnthermic.co.uk
W16C- Programmable Heater Controller
7 Day, 6+1 Day or 5+2 Day (Default 5+2 Day)
230V ac 50 Hz 16A Maximum Load (Battery back-up)
NTC (10KΩ) +/- 0.5°C at 20°C
1°C to 45°C (Default 5°C to 30°C)
LED + Standby brightness setting.
6
Facility for locking the screen or the screen except "On / Off".
86mm x 86mm x 16mm deep when recessed. Fits standard
35mm recess boxes.
Class II
EN 301489-1, EMC Directive 2014/30/EU,
EN60950-1:2006 + a11:2009 + a1:2010 +
a12:2011 + a2:2013
INSTRUCTIONS FOR:-
Wi-Fi PROGRAMMABLE CONTROLLER
Model:- W16C
IP20
