ICON PRO-FORM 360P PulseMonitor User Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Class H Fitness Product

Model No. PETL30131

Serial No.

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts,

please call:

08457 089 009

or write:

ICON Health & Fitness, Ltd.

Customer Service Department

Unit 4

Revie Road Industrial Estate

Revie Road

Beeston

Leeds, LS118JG

email: csuk@iconeurope.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Serial

Number

Decal

USER'S MANUAL

Visit our website at

www.iconeurope.com

Table of Contents

Need help?

Do you have a question about the PRO-FORM 360P PulseMonitor and is the answer not in the manual?

Questions and answers

Summary of Contents for ICON PRO-FORM 360P PulseMonitor

Page 1 If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 or write: ICON Health & Fitness, Ltd. Customer Service Department Unit 4 Revie Road Industrial Estate Revie Road Beeston Leeds, LS118JG email: csuk@iconeurope.com...
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the centre of this manual. PROFORM is a registered trademark of ICON Health & Fitness, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure No other appliance should be on the same cir- that all users of this treadmill are adequately cuit.
Page 4 35 or persons with pre-existing health problems. Read all instructions before using. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 5: Before You Begin
BEFORE YOU BEGIN Congratulations for selecting the new PROFORM ® ing this manual, please call our Customer Service P treadmill. The 360 P treadmill combines advanced Department at 08457 089 009. To help us assist you, technology with innovative design to help you get the please note the product model number and serial num- most from your exercise in the convenience and pri- ber before calling.
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 7 3. With the help of a second person, raise the Uprights (25, 29) to the vertical position. Open part bag B. Set the Crossbar (40) on the brackets on the Uprights (25, 29). Attach the Crossbar with two Crossbar Screws (39). Do not tighten the Crossbar Screws yet.
Page 8 6. Place the Console Base (47) on the Right Handrail (72) and the Left Handrail (not shown). Attach the Console Base with four 3/4” Screws (61) (only two Screws are shown). Do not overtighten the Screws. Insert the Wire Harness (42) through the two indicated nylon ties on the Console Base (47).
Page 9: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPOR- TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 10 CONSOLE DIAGRAM Note: If there is a thin sheet of Clip plastic on the console, remove it. Next, stand on the foot rails of the treadmill. Find the CAUTION: clip attached to the key (see the drawing above), and Before operating the slide the clip onto the waistband of your clothes.
Page 11 To stop the walking belt, press the Stop button. Note: The console can display speed and dis- The Time/Incline display will begin to flash. To tance in either miles or restart the walking belt, press the Start button or kilometers. The letters the Speed + button.
Page 12 When you are finished using the treadmill, move When you are finished exercising, remove the the on/off switch near the power cord to the off po- key. sition. Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest level.
Page 13: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
Page 14 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
Page 15: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
Page 16 Locate the Reed Switch (10) and the Magnet (18) on the left side of the Pulley (17). Turn the Pulley until the 3 mm Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 3 mm (1/8 in.).
Page 17: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.
Page 18 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 19 NOTES...
Page 20 PART LIST—Model No. PETL30131 R0903B No. Qty. Description No. Qty. Description No. Qty. Description Hood U-nut Ground Wire Rail Screw Bookrack Right Rear Motor Belt Console Base Endcap Pad Motor Tension Bolt Lift Frame Ground Rear Roller Flat Washer Wire Adjustable Bolt Motor Star Washer Console Screw...
Page 21 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. 3/4” Screw (61)–8 Silver Ground Crossbar Screw 1” Tek Screw (58)–4 Screw (75)–2 (39)–2 1”...
Page 22 EXPLODED DRAWING—Model No. PETL30131 R0903B...
Page 23: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, contact the ICON Health & Fitness, Ltd. office, or write: ICON Health & Fitness, Ltd. Customer Service Department Unit 4, Revie Road Industrial Estate Revie Road Beeston Leeds, LS118JG Tel: 08457 089 009...

This manual is also suitable for:

Petl30131
