Instructions
PLURAL COMPONENT
Mixer Manifold
3000 psi (21.0 MPa, 210 bar) Maximum Working Pressure
Model 215625 Series C
Low Volume Mixer: 1/4 npt fluid outlet; for use in low
volume applications, such as air spray urethanes.
Model 215626 Series C
High Volume Mixer: 1/2 npt fluid outlet; for use in high
volume applications, such as airless spray or high solids
epoxy.
Model 241692 Series A
Includes Model 215626 and a static pipe mixer.
Ball Valve Kit 218413
Updates the handle and ball valve of Series A,
Model 215625, Low Volume Mixer. See page 10.
Ball Valve Kit 218414
Updates the handle and ball valve of Series A,
Model 215626, High Volume Mixer. See page 10.
Read warnings and instructions.
See page 2 for Table of Contents.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 1980, Graco Inc. is registered to I.S. EN ISO 9001
Get other manuals https://www.bkmanuals.com
307400P
06305
Advertisement
Related Manuals for Graco C Series
Summary of Contents for Graco C Series
- Page 1 Model 215626, High Volume Mixer. See page 10. Read warnings and instructions. 06305 See page 2 for Table of Contents. GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441 Copyright 1980, Graco Inc. is registered to I.S. EN ISO 9001 Get other manuals https://www.bkmanuals.com...
- Page 2 D This equipment is for professional use only. D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor. D Do not alter or modify this equipment.
- Page 3 WARNING INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin is a serious injury.
- Page 4 REACTIVE CHEMICALS HAZARD Graco Inc. does not manufacture or supply any of the reactive chemical components that are used in this equipment, and is not responsible for their effects. Because of the vast number of chemicals that could be used, and their varying chemical reactions, the buyer and user of this equipment should de- termine all facts relating to the materials used, including any of the potential hazards involved.
- Page 5 For assistance in setting up a plural component sys- in your pump instruction manual. tem, contact your Graco distributor. This will help as- sure that you select the proper type and size equip- 2. Fluid hoses: Use only grounded hoses with a max- ment for your job.
- Page 6 Operation Start-up Solvent may channel through viscous fluids and leave a coating of mixed fluid on the inner tube of your hose. The mixer manifold was tested in oil, which was left in to protect the manifold. Before operating, thoroughly Fig 2 shows the handle in the UP, or closed, position and the flush the manifold to prevent contamination of the right solvent valve open with solvent flowing through the...
- Page 7 Operation Be sure all fluid is thoroughly flushed from the hose Solvent after each use. Resin Hardener Disassemble all other dispensing equipment, as nec- essary, and clean thoroughly. CAUTION To prevent fluid from setting up in the dispensing equipment, flush the system frequently. Be sure there is adequate solvent in the solvent supply before starting to spray.
- Page 8 Operation Pressure Relief Procedure 1. Close the mixer fluid valves. 2. Flush the dispensing equipment as described in the Flushing Procedure on page 6. WARNING 3. Shut off the fluid and solvent pumps. INJECTION HAZARD 4. Hold a metal part of the spray gun firmly to a The system pressure must be manually grounded metal pail, and trigger the gun to relieve relieved to prevent the system from...
- Page 9 Service Manifold Repair (See Page 10. ) 7. Tighten the needle valve slightly, so that the tapered end centers in the seat (6) and holds its position. WARNING 8. Turn the six socket screws (2) oppositely and To reduce the risk of serious injury whenever you evenly to 60–70 in-lbs (6.7–7.9 NSm).
- Page 10 Parts Ref No.13 Ref No.24 Ball Valve 215622, Series B Ball Valve 215623, Series B Low Volume High Volume 32‡ 33‡ 34‡ 33‡ 05769 05768 13 or 24 Model 215625 Manifold, Series C Model 215626 Manifold, Series C Instruction label covers parts 7 and 8 when assembled.
- Page 11 Parts Models 215625 and 215626, Series C Part No. Description Qty. Part No. Description Qty. 165964 . NUT, packing 100721 PLUG, internal hex; 1/4; 1/4 npt 178745 . STEM 104472 CAPSCREW, hex hd; 172094 . SEAT, ball; Nylatron 10–32 x 1–1/2 178743 .
- Page 12 Parts Model 241692 Series A 5765B Part No. Description Qty. Part No. Description Qty. 215626 MANIFOLD, mixer; see full parts 156823 UNION, swivel and listing on pages 10 and 11 108233 VALVE, needle 157676 UNION, swivel, 90_ 502265 BUSHING, reducer, pipe 155699 ELBOW, street 512506...
- Page 13 Technical Data Maximum working pressure ..... 3000 psi (21.0 MPa, 210 bar) Fluid port size Model 215625 ..........1/4 npt(m) Model 241692 .
- Page 14 Dimensions Model Model Model 215625 215626 241692 5.0 in 5.5 in 5.5 in Overall Length (127 mm) (140 mm) (140 mm) 5.375 in. 6.25 in 19.85 in Overall Height (136 mm) (159 mm) (504 mm) 1.375 in 1.25 in 1.25 in Overall Width (35 mm) (32 mm)
- Page 15 Notes head.notes 307400 Get other manuals https://www.bkmanuals.com...
- Page 16 Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
