Graco C Series Installation

Air dryer kit for drying the pressurized air supplied to both of the xm pfp tanks

Hide thumbs Also See for C Series:

Download this manual

Installation

XM PFP

Air Dryer Kit

For drying the pressurized air supplied to both of the XM PFP tanks.

For professional use only.

Kit 262896, Series C

160 psi (1.1 MPa, 11 bar) Maximum Working Pressure

Important Safety Instructions

Read all warnings and instructions in this

manual and in XM PFP Operation manual

3A2776. Save all instructions.

3A2987D

ti20099b

Need help?

Do you have a question about the C Series and is the answer not in the manual?

Page 1 Installation XM PFP Air Dryer Kit 3A2987D For drying the pressurized air supplied to both of the XM PFP tanks. For professional use only. Kit 262896, Series C 160 psi (1.1 MPa, 11 bar) Maximum Working Pressure Important Safety Instructions Read all warnings and instructions in this manual and in XM PFP Operation manual 3A2776.
Page 2 Related Manuals Related Manuals b. Install the elbow (C1) into the air dryer system and ensure that it points up. Manuals are available at www.graco.com c. Install the bushing (B) onto the elbow Manual in Description fitting (C1). English 3A2776 XM PFP Setup - Operation d.
Page 3 Parts Parts ti20100b See your Dryaire Desiccant System Instructions - Ref Part Description 24M178 SYSTEM, desiccant air dryer Parts manual for desiccant air dryer system parts. 100206 BUSHING, pipe See Related Manuals, page 2. 156971 FITTING, nipple, short 210866 HOSE, coupled NOTE: D1-D3 are 3 ft coupled hose and are supplied 16F537 HOSE, coupled, 6 ft with XM PFP.
Page 4 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
