Graco C Series Instructions And Parts List

INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Frame, Roller
3600 psi (24.8 MPa, 248 bar) Maximum Working Pressure*
*The best operating pressure is the lowest pressure that provides an even paint supply to the roller and typically
does not exceed 300 psi (2.1 MPa, 21 bar).
Model 244271, Series C
D 9 in. (22.9 cm) length
D 7/8" inlet with 1/2" roller cover
Model 244623, Series C
D 9 in. (22.9 cm) length
D 1/8" inlet with 1/2" roller cover
Pressure Relief Procedure
WARNING
To help prevent injection injuries,
follow this procedure whenever
you stop painting.
psi/MPa/bar
1. Put gun trigger safety in SAFETY ON position.
2. Shut off power to pump.
3. Turn prime/spray valve to the PRIME position to
relieve pressure in system.
4. Put gun trigger safety in SAFETY OFF position,
and trigger gun to relieve any pressure in hose.
5. Put gun trigger safety in SAFETY ON position, and
keep pump prime/spray valve in PRIME position
until you paint again.
If you suspect that the frame or hose is completely
clogged or that pressure has not been fully relieved
after following the steps above, VERY SLOWLY
loosen the tip retaining nut or hose end coupling and
relieve pressure gradually, then loosen completely.
Now clear the frame or hose obstruction.
