This document describes the ISO5500 Evaluation Module (EVM) and allows designers to analyze and
evaluate the Texas Instruments ISO5500 Isolated Gate Driver.
The ISO5500EVM can be used to evaluate device parameters while acting as a guide for board layout.
The board allows the user to evaluate device performance using a simulated (10-nF) IGBT load installed
on the board, or to install an IGBT or MOSFET (TO-247 package) onto the board and drive it with the
ISO5500.
..................................................................................................................
1
1.1
1.2
2
2.1
2.2
1
2
3
4
...................................................................................................................
1
2
1
Introduction
1.1

Overview

This ISO5500EVM was designed to allow the user to evaluate the performance and features of the
ISO5500. This includes the IGBT desaturation protection (DESAT) and the UVLO circuit that ensures a
sufficient gate voltage is available to drive the IGBT or MOSFET. The printed-circuit board (PCB) also
includes provisions to adjust the turnon/turnoff characteristics by changing the loading between the
ISO5500 output and the IGBT (or MOSFET) gate.
The EVM kit includes the ISO5500 data sheet.
diagram.
QuietZone is a trademark of 3M.
SLLU136A - September 2011 - Revised November 2012
Submit Documentation Feedback
