Quick Start Guide
O4P25X2

Advertisement

loading

Related Manuals for Speco O4P25X2

Summary of Contents for Speco O4P25X2

  • Page 1 Quick Start Guide O4P25X2...
  • Page 2 This owner's manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, contact Speco Technologies Tech Support at 1-800-645-5516 Important Safeguards and Warning 1.
  • Page 3 Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation. Note: Before installation, check the package and make sure that all components are included.

  • Page 4: Installation

    Overview Overview ① Ethernet Connector (PoE++) ② 3.5mm Audio Out ③ 3.5mm MIC In ④ Alarm In/Alarm Out ⑤ 24VDC/AC Power Input Jack* Ground *24VDC Power adapter included Installation Please make sure the wall is strong enough to bear the dome camera’s weight.
  • Page 5 Insert SD card ① Loosen the two screws of the dome. ② Open the cover and insert SD card. ◆ Install the Speed Dome 78.5mm 8.0mm Adapter Fasten the adpater to the bracket. ① Drill the screw holes on the wall ②...

  • Page 6: Cable Connection

    Cable Connection ALM-OPEN ALM-COM ALM-GND ALM-IN1 DC24V Power Connect to earth ground 24V A Earth 24V B Alarm Connection: 1. Alarm Input a) There is one independent alarm input port (ALM-IN1) and one grounding port (ALM-GND). b)Alarm input(NO type): Connect DC5V~DC12V voltage between the alarm input port( ALM-IN1) and the grounding port (ALM-GND).
  • Page 7 The camera is set to DHCP by default. ② Install IP Scanner from the CD and run it after installation. 5C:F2:07:24:68:B9 O4P25X2 ③ In the device list, you can view the IP address, model number, and MAC address of each device. Select the applicable device and double click to open up the web viewer.
  • Page 8 The login interface is shown above. Default user name is admin and password is 1234. After logging in, follow directions to install applicable plugins if prompted.
