Installation

1 Define the position of the joystick.
When the arrow at the bottom of the joystick points to the front, a
forward movement of the joystick will result in an according forward
movement of the wheelchair.
If needed, you can change this positioning in steps of 90° with the
Configurator Software.
2 Place the mounting ring around the joystick housing.
3 Secure the Q2M half clamp to the mounting ring.
Use an Allen wrench to mount the 20 mm bolt.
NOTE:
using the Q2M half clamp.
CAUTION:
force may damage the unit.
4 Slide the unit over a Q2M Rod, or any other 6 mm rod, to position the
Micro Joystick on the wheelchair.
A Q2M Rod D6 50 mm is included in your package, but you can use any
other Q2M Rod (e.g. a C- or S-Rod from the Multi Swing).
5 Place and secure the interface unit and all cabling on the wheelchair.
Micro Joystick Installation manual
It is not advised, but you may mount the joystick without
Tighten the screws firmly, but not excessively. Excessive
