- Page 1 USER MANUAL Edition: 1 from 27.04.2023 Supersedes edition: Power supplies DING2 series v1.0 Switch mode power supply units with battery backup for a DIN rail Grade 2...
-
Page 2: Table Of Contents
DING2 series Features: compliance with norm EN50131-6:2017 LED optical indication in grade 1, 2 and II environment class dynamic battery test compliance with norm (KD) EN60839-11- battery circuit continuity control 2:2015+AC:2015 standard and I environment class ... -
Page 3: Block Diagram
DING2 series Depending on a required protection level of the alarm system in the installation place, the PSU efficiency and the battery charging current should be set as follows: Grade 1, 2 - standby time 12h: The 12h standby output current can be calculated from the formula:... -
Page 4: Specifications
DING2 series Fig. 2a. View of power supply module (12V2A model) Fig. 2b. View of power supply module (12V3A, 12V5A, 24V2A, 24V3A models) 1.4. Specifications: - electrical parameters (Tab. 2) - operation safety (Tab. 3) - operating parameters (Tab. 4) - Page 5 Table 2. Specifications. Model DING2-12V2A DING2-12V3A DING2-12V5A DING2-24V2A DING2-24V3A PSU type EN50131-6 A, Grade 1,2, II environmental class Supply voltage ~ 200 - 240 V Current consumption 0,4 A 0,5 A 0,7 A 0,6 A 0,9 A Power frequency 50/60 Hz Inrush current 40 A Output power PSU...
-
Page 6: Installation
Table 3. Operation safety. Protection class EN 62368-1 Protection grade EN 60529 IP20 Electrical strength of insulation: - between input and output circuits of the PSU 4000 V DC min. - between input circuit and protection circuit 2500 V DC min. - between output circuit and protection circuit 500 V DC min. -
Page 7: Operating Status Indication
DING2 series Fig. 3 Connecting batteries depending on voltage version of power supply: a) version 12V, b) version 24V. Switch on the 230 V supply. LEDs on the PCB of power supply should light (see section 3.1). After installing and checking proper working, the enclosure can be closed. -
Page 8: Technical Outputs
DING2 series 3.2 Technical outputs. The PSU is equipped with indication outputs: EPS FLT - technical output indicating 230 V power failure. The output indicates 230 V power failure. In case of power failure, contacts of relay change over after about 30 seconds. -
Page 9: Battery Charging Time
DING2 series 3.5 Battery charging time. PSU has a battery circuit charged with direct current. Current selection is done with use of the I jumpers. Table below shows how long does it take to charge a (fully discharged) battery up to min. 80% of its nominal capacity.
