- Page 1 HPSBOC 3524C v.1.1 HPSBOC 27,6V/3A/2x17Ah/OC Buffer switch mode power supply unit with technical outputs. Edition: 8 from 01.06.2016 Supercedes edition: 7 from 01.04.2015...
-
Page 2: Table Of Contents
PSU, with high energy efficiency. The PSU is housed in a metal enclosure (colour RAL 9003) which can accommodate two 17Ah/12V batteries. A micro switch indicates door opening (front cover). OPTIONAL POWER SUPPLY CONFIGURATIONS: (visualisation available at: www.pulsar.pl) 1. Buffer power supply unit HPSBOC 27,6V/8x0,3A/2x17Ah. - HPSBOC3524C + LB 8x0,3A (AWZ577 or AWZ580) + 2x17Ah 2. - Page 3 GREEN POWER plus www.pulsar.pl HPSBOC3524C 6. Buffer power supply unit HPSBOC 27,6V/24V/8x0,3A/2x17Ah. - HPSBOC3524C + RN25024 (27,6V/24V) + LB8 8x0,3A (AWZ577 or AWZ580) +2x17Ah 7. Buffer power supply unit HPSBOC 27,6V/2x5V÷18V/2x2A ÷1,3A/2x17Ah. - HPSBOC3524C + 2xDCDC20 (2x5V÷18V/2A÷1,3A) + 2x17Ah 8. Buffer power supply unit HPSBOC 27,6V/2x5V÷18V/2x2A ÷1,3A/8x0,5A/2x17Ah.
- Page 4 GREEN POWER plus www.pulsar.pl HPSBOC3524C Fig. 2. The view of the PSU. Element no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU.
-
Page 5: Specifications
GREEN POWER plus www.pulsar.pl HPSBOC3524C 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3). 176÷264V AC Mains supply Current up to 0,9A@230VAC Supply power 100W max. Efficiency –... -
Page 6: Installation
GREEN POWER plus www.pulsar.pl HPSBOC3524C Operation safety (tab.5). Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input and output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min. -
Page 7: Installation Procedure
GREEN POWER plus www.pulsar.pl HPSBOC3524C 2.2 Installation procedure. 1. Before installation, cut off the voltage in the 230V power-supply circuit. 2. Mount the PSU in a selected location and connect the wires. 3. Connect the power cables (~230Vac) to L-N clips of the PSU. Connect the ground wire to the clip marked by the earth symbol PE (PSU module connector). -
Page 8: Technical Outputs
GREEN POWER plus www.pulsar.pl HPSBOC3524C 3.2 Technical outputs The PSU has indication outputs: EPS - absence of AC supply output: - OC type output that indicates AC power loss. Under normal status, with 230V AC supply, the output is connected to ground (L level –... - Page 9 GREEN POWER plus www.pulsar.pl HPSBOC3524C 4.3 Maintenance. Any and all maintenance operations may be performed following the disconnection of the PSU from the power supply network. The PSU does not require performing any specific maintenance measures, however, in case of significant dust rate, its interior is recommended to be cleaned with compressed air. In case of fuse...
- Page 10 The power supply unit is adapted for a sealed lead-acid battery (SLA). After the operation period it must not be disposed of but recycled according to the applicable law. Pulsar Siedlec 150, 32-744 Łapczyca, Poland Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50 e-mail: biuro@pulsar.pl, sales@pulsar.pl http:// www.pulsar.pl, www.zasilacze.pl...
