- Page 1 Linear Guide 6 60 PS Linear Guide 6 60 PS Transverse Carriage Assembly guide...
-
Page 2: Table Of Contents
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Contents Symbols, safety ........................................2 General safety information ....................................3 Correct use ..........................................3 Improper use ..........................................4 Product description .........................................4 Technical data .........................................4 Preparing for assembly ......................................6 Fitting the linear guide rail .....................................6 Fitting the magnetic strips .....................................7... -
Page 3: General Safety Information
▪ Do not alter the position of safety equipment, circumvent it or render it ineffective. The Linear Guide 6 60 PS and Linear Guide 6 60 PS Transverse Carriage documented here correspond to the state of the art and take into account the general principles of safety applicable at the time this guide was published. Nevertheless, failure to observe the safety instructions and warning notices in this guide may result in personal injury and damage to property. -
Page 4: Improper Use
Product description Linear Guide 6 60 PS consists of two torsion-resistant profile rails and two heavy-duty bearing carriages. The guide is suitable for precise, low-friction movements. Linear Guide 6 60 PS adds a compact and complete encapsulated guidance solution to the item linear technology portfolio. - Page 5 Storage temperature: -20°C to +70°C Relative humidity: 5% to 85% Linear Guide 6 60 PS and Linear Guide 6 60 PS Transverse Carriage are intended as a permanent fixture to be used in an area that is protected from the weather.
-
Page 6: Preparing For Assembly
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Preparing for assembly Switch off the power to the system before carrying out any installation, cleaning or maintenance work on Linear Guide 6 60 PS. -
Page 7: Fitting The Magnetic Strips
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide The rail is a total of 20 mm shorter than the Support Profile and must be centred, that is to say 10 mm from each edge. Furthermore, manual pressure must be applied to keep the rail pressed permanently against the stop edge while the screws are being tightened. -
Page 8: Fitting The Carriage
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Fitting the carriage Ensure the relevant assembly aid of the Bearing Carriages (recirculating ball guide carriages) does not slip out. If this happens, balls could be lost. -
Page 9: Fitting The End Caps
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Next, screw the intermediate carriage plate securely onto the body of the carriage using the eight Counter- sunk Screws M4x10. Tightening torque M = 3 Nm... -
Page 10: Fitting The Steel Strip
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Once everything has been properly fitted and screwed into place, move the carriage over the entire length of the axis byhand, checking the operation and smooth running of the guide. - Page 11 Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Fit the two guides – correctly aligned – onto the steel strip. The correct alignment of the steel strip guides is important and must be ensured.
-
Page 12: Fitting Cover Profile Le 6
Tightening torque M = 1.5 Nm Alternatively, Transverse Carriage Plate can also be used to build a Linear Guide 6 60 PS Transverse Carriage. First, use a mallet to fit the Caps X 6 60x12. Centre the transverse carriage plate on the intermediate carriage plate, ensuring both are parallel. -
Page 13: Accessories For Linear Guide 6 60 Ps
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Accessories for Linear Guide 6 60 PS Proximity Switch KLE 6 60x60 - 1NC (0.0.604.41) Proximity Switch KLE 6 60x60 - 1NO (0.0.609.31) Inductive proximity switch, positive switching... -
Page 14: Checklist
Linear Guide 6 60 PS, Linear Guide 6 60 PS Transverse Carriage – Assembly guide Checklist Assembly of Linear Guide 6 60 PS Checks Checked Comment Visual inspection Screws tightened Carriage aligned Unusual running noises during manual test run Rubbing... -
Page 15: Care And Cleaning
Incorrect care and/or cleaning risks causing damage. A cloth and a standard domestic cleaning agent are adequate for cleaning Linear Guide 6 60 PS. Check that the substances you are using are suitable for use on paints and plastics. Aggressive cleaning agents and pressure washers may damage the product. - Page 16 Industrietechnik GmbH Friedenstrasse 107-109 42699 Solingen Germany Phone +49 212 6580 0 Fax +49 212 6580 310 info@item24.com item24.com...
