Summary of Contents for ITEM PS 4-15
- Page 1 Linear Guide System PS 4-15 Notes on Use and Installation...
- Page 2 G E N E R A L General hazard warning Appropriate use C O N T E N T Application Setting up the Guide Carriage and Lubricating the Linear Guide System Technical Data Maintenance Preparations for Assembly Replacing the Wipers Installing the Guide Rail Re-lubrication Symbols, safety...
- Page 3 Close all openings with appropriate protective devices so that no detergent can ƒ Use item products only in technically perfect condition. enter the system. Use no aggressive detergents. Do not use a high-pressure cleaner for the cleaning.
- Page 4 The key features of Linear Guide Sys- The Linear Guide System is pre-loaded when it leaves the factory. tem PS 4-15 are its high carrying capacity, rigidity and compact design. Each Linear Guide System carriage can be freely combined with every Linear Guide The carriages must be used in combination in order to absorb high forces and moments.
- Page 5 For a higher moment loading, provision should be made for a slide construction In order to maintain the permissible positional tolerances with this type with two or more guide carriages on an arrangement of two rails, in order to of arrangement, the parallel guide rails must be mounted on a common prevent any torsional load on the individual guide rails and any tilting of the rail supporting profile.
- Page 6 Installing the Guide Rail As a result of the internal stresses generated when the guide rails are ground Insert the screws, DIN 912 M4x16 Property Class 10.9 (No. 0.0.406.75) into to shape, a rail in as-supplied condition may not be perfectly straight. However, the holes in the guide rail and tighten them by hand.
- Page 7 Setting up the Guide Carriage and Lubricating the Linear Guide System Remove the guide carriage from its packaging. If lubrication with grease is specified, withdraw the protective rail from the raceways and smear the ball bearings with grease. For oil lubrication the grease should be wiped from the ball rows carefully.
- Page 8 Apart from errors during assembly, the principal causes of sealing function, are protected from damage. The lubrication damage to Linear Guide System PS 4-15 are inadequate protec- intervals should be determined by the operating conditions of tion against contamination and lack of lubrication. Therefore, the Linear Guide System.
