Linear Units KLE
Notes on Use and Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KLE 6 and is the answer not in the manual?

Questions and answers

Related Manuals for ITEM KLE 6

Summary of Contents for ITEM KLE 6

  • Page 1 Linear Units KLE Notes on Use and Installation...

  • Page 2: Table Of Contents

    Linear Units KLE ― Notes on Use and Installation Contents Symbols, safety........................................3 General safety information ....................................3 Correct use..........................................4 Improper use ..........................................5 Selecting suitable Linear Units KLE ..................................5 Design............................................5 Article names, geometry......................................6 General technical data ......................................8 Assembly.

  • Page 3: Symbols, Safety

    ▪ Observe the regulations pertaining to accident prevention and environmental protection that apply in the country and place of work where the product is being used. ▪ Use only item products that are in perfect working order. ▪ Failure to use original spare parts will invalidate the product warranty! ▪...

  • Page 4: Correct Use

    ▪ Do not alter the position of safety equipment, circumvent it or render it ineffective. KLE 6 60x60 LR and KLE 8 80x80 LR, as described here, corresponds to the state of the art and takes into account the gene- ral principles of safety applicable at the time this assembly guide was published.

  • Page 5: Improper Use

    We will assume no liability for any resulting damage or injury. Selecting suitable Linear Units KLE Design Linear Unit KLE 6 60x60 LR 0.0.605.07 Linear Unit KLE 8 80x80 LR 0.0.605.02 KLE 6 60x60 KLE 8 80x80 [mm] Max.

  • Page 6: Article Names, Geometry

    Linear Units KLE ― Notes on Use and Installation Article names, geometry Article name Order number Timing Belt Drive KLE 6 60x60 LR 0.0.605. 1 8 Timing Belt KLE 8 80x80 LR 0.0.604.95 Profile 6 60x60 KLE 0.0.603.83 Profile 8 80x80 KLE 0.0.600.42...
  • Page 7 Linear Units KLE ― Notes on Use and Installation The maximum deflection, f KLE 6 60x60 KLE 8 80x80 of the system is governed by the dimension of the profile [mm] Carriage length cross-section, the free profile [mm] Width of Reverse Units length and the force applied.

  • Page 8: General Technical Data

    Assembly Set KLE LR (0.0.612.72) is used to support assembly and maintenance of both sizes of system. It consists of the following parts: ▪ Drilling Jig KLE 8 80x80 LR 0.0.611.21 ▪ Drilling Jig KLE 6 60x60 LR 0.0.611.53 ▪ Pin Spanner KLE 0.0.611.82 ▪...

  • Page 9: Shaft And Profile Machining

    Safety distance S of KLE 6 60x60: = 26.0 mm KLE 8 80x80: = 63.5 mm Cutting Shaft D10 (KLE 6 60x60) / D14 (KLE 8 80x80) approx. 5 mm shorter than profile length: KLE 6 60x60: - 5 mm Shaft Profile...

  • Page 10: Press-Fitting The Shafts

    The maintenance holes need only be cut into the profile from one side so that the carriage grease nipples can be accessed. Press-fitting the Shafts Press Shafts D10 (KLE 6 60x60) / D14 (KLE 8 80x80) into the profile geometry using the Mounting Aid, Shaft Assembly Lever (part of Assembly Set KLE-LR, 0.0.612.72) and a suitable second Line 8 profile.
  • Page 11 To do this, suitable drill bushes are provided in the Drilling Jig at a distance of 30 mm (KLE 60) / 40 mm (KLE 80) from the profile edge. As the Shaft is hardened, lay the profile on its side and cut a hole from above on a pillar drill. KLE 6 60x60: Carbide spiral drill ⌀ 4 mm Recommended speed 3000 rpm KLE 8 80x80: Carbide spiral drill ⌀...

  • Page 12: Timing Belt, Strip

    KLE 8 80x80 Dowel Pin DIN 6325-6x18 For KLE units with Shaft lengths in excess of 3 m, Shafts D10 (KLE 6 60x60) / Shaft D14 (KLE 8 80x80) must be butt-joined. There must be no more than one butt joint. The recommended minimum Shaft length is LShaft min = 300 mm The butt joints thus created on the Shafts can be opposite each other, i.e.
  • Page 13 Linear Units KLE ― Notes on Use and Installation The ends of the Strip must be free of burrs. Insert the Strip all the way into the bottom of the profile (with the curved side facing down). The Timing Belt can be cut with conventional metal shears.

  • Page 14: Carriage

    Linear Units KLE ― Notes on Use and Installation Carriage Carriage KLE 6 60x60 / Carriage KLE 8 80x80 is supplied pre-assembled. 4x Hexagon Socket Head Cap Screws DIN 7984, bright zinc-plated 2x Hexagon Socket Head Cap Screws DIN 7984,...
  • Page 15 Allan key anti-clockwise. Tightening torque applied by torque spanner: KLE 6 60x60: T = 10 Nm KLE 8 80x80: T = 20 Nm Remove the Carriage from the guide track and fit the...

  • Page 16: Timing-Belt Reverse Unit, Timing-Belt Drive

    Linear Units KLE ― Notes on Use and Installation When subsequently inserting the Carriage into place, press the felts together to prevent them from being damaged. The plastic element must be correctly positioned before the Carriage is slotted on. The plastic element is used to cover the gap and must be assembled with the tooth-shaped ends pointing downwards.
  • Page 17 Align the Reverse Units with the end faces of Profile KLE and secure them in place: Tightening torque KLE 6 60x60 (M5): 6 Nm Tightening torque KLE 8 80x80 (M6): 10 Nm Lift the Timing Belt up out of the guide groove and press it onto the toothing on the end of the Carriage.

  • Page 18: Calculating Timing Belt Tension

    = Permissible force for Timing Belt R10 T5 [N] = 300N Bperm = Frictional force, loss of friction when running light (for Linear Unit KLE 8 80x80 [N]: 75N Linear Unit KLE 6 60x60 [N]: 40,5N ΔL = Necessary elongation of the overall Timing Belt length [mm]...

  • Page 19: Tightening The Timing Belt

    Tightening the Timing Belt You can tighten the Timing Belt using Reverse Unit KLE 6 60x60 or Reverse Unit KLE 8 80x80. Two Hexagon Socket Head Cap Screws DIN 912 are provided for this purpose on the end of the Reverse Unit.
  • Page 20 Linear Units KLE ― Notes on Use and Installation Tip: Instead of measuring the movement of the tensioning axle, it is advisable to measure the actual elongation of the Timing Belt. When using this approach, the exact position of the tensioning axle before you make any adjustments is irrelevant and measu- rement errors can be minimised.

  • Page 21: Support System, Carriage Plate

    KLE 6 60x60 KLE 8 80x80 The carriage plate of the KLE 6 60x60 and the carriage plate KLE 8 80x80 each have two holes which are used for pinning the carriage plate to the cover plate of the carriage.

  • Page 22: Drive, Synchronisation

    Linear Units KLE ― Notes on Use and Installation Drive Synchronization The basic element of a KLE unit is now fully assembled; the next step consists of attaching a ▪ Drive Unit and any required ▪ synchronisation with a second Drive Unit The drive The Drive Set contains all the components needed for connecting a motor or gearbox.
  • Page 23 Linear Units KLE ― Notes on Use and Installation [mm] KLE 6 60x60 KLE 8 80x80 Coupling Housing depth Centring Piece ⌀ f 59.5 Coupling Housing height Depth of insertion of drive shaft Table 8 Preparing the drive If force is transferred from the coupling to the drive shaft using frictional resistance, the Coupling Half to be connected to the drive shaft must be provided with a hole the size of the shaft and then connected with the latter.
  • Page 24 Linear Units KLE ― Notes on Use and Installation Coupling Half to be machined, for con- necting a drive shaft KLE 6 60x60: ⌀ 6 mm - 24 mm KLE 8 80x80: ⌀ 8 mm - 28 mm Coupling Housing to be machined, for...
  • Page 25 Tightening torque for the fastening screw in the Cou- pling Half: KLE 6 60x60: M6 = 10 Nm KLE 8 80x80: M8 = 20 Nm Press the Coupling Insert into place. Next, screw the Coupling Housing to the Drive Unit KLE.

  • Page 26: Synchronising Two Linear Units Kle

    ▪ Hexagon Socket Head Cap Screws St, bright zinc-plated When designing the synchronised Linear Units, the drive speed and distance between the Linear Units are key criteria. The length of Synchroniser Shaft (b) is defined as follows: KLE 6 60x60 KLE 8 80x80 Tube D20x3 St...
  • Page 27 Next, hold the prepared Synchroniser Shaft with the two Coupling Halves right and left in the installation position and use a rubber hammer to carefully drive the Coupling Halves onto the assembled Coupling Half of the KLE 6 60x60 or KLE 8 80x80.

  • Page 28: Prepared Kle Drive Set

    Assembling Drive Set KLE 8 80x80 AP/WP 80 – 0.0.673.27 This section describes the assembly of the Drive Sets of the KLE 8 80x80 and KLE 6 60x60, which are prepared for item drive components, gearboxes and motors. Due to the performance range of the KLE 8 80x80 and KLE 6 60x60, two motors and two gearboxes with different output ranges are available and can be connected with the linear axis using Drive Sets that have been prepared appropriately.
  • Page 29 Linear Units KLE ― Notes on Use and Installation Next, press the Coupling Insert into place and screw the Coupling Housing to the Drive Unit. Use the Hexagon Socket Head Cap Screws M4x18 [d] included with the Drive Set to secure the motor to the gearbox of the Linear Unit.
  • Page 30 Linear Units KLE ― Notes on Use and Installation Hexagon Socket Head Cap Screw M5x65, T = 10 Nm Hexagon Socket Head Cap Screw M4x12, T = 6 Nm Hexagon Socket Head Cap Screw M5x14, T = 10 Nm Hexagon Socket Head Cap Screw M3x14, T = 4 Nm Centring Piece D40 KLE 60x60 Hexagon Socket Head Cap Screw M6x85, T...

  • Page 31: Proximity Switches

    (by removing the Caps of the Reverse Units). The minimum distance is determined by the Carriage geometry and the contact plate located on it: KLE 6 60x60: dmin = 80 mm + S KLE 8 80x80: dmin = 100 mm + S This does not factor in the Carriage braking distance.

  • Page 32: Maintenance

    Linear Units KLE ― Notes on Use and Installation Maintenance Basic lubrication for the guide is applied by the operator under normal operating conditions. The service life for the initial lubrication applies to normal operating conditions. A special oil press can be used to provide additional lubrication to the guide system. To do this, move the Carriage to the “maintenance position”...

  • Page 33: Disposal

    The packaging must be returned to the available return and collection systems. Product development and documentation A process of continuous product development ensures that products from item Industrietechnik GmbH always exhibit a high standard of innovation. Consequently, there could be inconsistencies between this guide and the product you have acquired.
  • Page 34 Industrietechnik GmbH Friedenstrasse 107-109 42699 Solingen Germany Phone +49 212 6580 0 +49 212 6580 310 info@item24.com item24.com...
