Page 1 Installation Manual MONUMENT DISHWASHERS www.zlinekitchen.com...
Page 2 With an endless selection of features and finishes, our inspiration is your reality. ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
Page 4 WARRANTY COVERAGE ZLINE Kitchen and Bath dishwashers will be warrantied for one year from the original purchase date for the original purchaser of the product. TERMS This warranty applies only to the original purchaser of the product installed for normal residential use. This is defined as a single-family, residential dwelling in a non-commercial setting.
Page 5: Table Of Contents
TABLE OF CONTENTS GENERAL SAFETY INSTRUCTIONS BEFORE INSTALLATION INSTALLATION OPERATIONAL SAFETY INSTRUCTIONS OPERATION MAINTENANCE AND CLEANING TROUBLESHOOTING...
Page 6: General Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your refrigerator. CAUTION This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your WARNING refrigerator.
Page 7 IMPORTANT SAFETY INSTRUCTIONS FOR YOUR SAFETY IMPORTANT SAFETY INSTRUCTIONS Read and observe all CAUTIONS and WARNINGS shown throughout these instructions. While performing installations described in this booklet, gloves and FOR YOUR SAFETY safety glasses or goggles should be worn. Read and observe all CAUTIONS and WARNINGS shown throughout these instructions.
Page 8: Before Installation
BEFORE INSTALLATION PACKAGE CONTENTS • Dishwasher • Hose • Installation Kits • User Guide • Installation Guide If you have an installation problem, contact your dealer or installer. You are responsible for providing adequate electrical, plumbing, and other connecting facilities. PREPARING TO INSTALL YOUR DISHWASHER PARTS SUPPLIED •...
Page 9 BEFORE INSTALLATION ENCLOSURE REQUIREMENTS • The dishwasher must be installed so that the drain hose is no more than 10 ft. in length, for proper drainage. • This dishwasher is designed to be enclosed on the top and on both sides by a standard residential kitchen cabinet unit.
Page 10 BEFORE INSTALLATION DRAIN REQUIREMENTS • Follow all local codes and ordinances. • Do not exceed 10 ft. of drain hose. • Do not connect the drain lines from other devices to the dishwasher drain hose. • The dishwasher must be connected to a waste line with an air gap (not provided) or a 32 in.
Page 11 BEFORE INSTALLATION DRAIN PREPARATION The type of drain installation required depends on the answers to the following questions: • Do local codes or ordinances require an air gap? • Will the waste tee or garbage disposal connection be less than 18 in. above the floor? •...
Page 12 BEFORE INSTALLATION ELECTRICAL REQUIREMENTS • This appliance must be supplied with 120V, 60 Hz, and it must be connected to its own, properly grounded branch circuit that is protected by a 15 or 20 ampere circuit breaker or time delay fuse. •...
Page 13 BEFORE INSTALLATION GROUNDING INSTRUCTIONS Grounding Instructions – Cable Direct This appliance must be connected to a grounded metal, permanent wiring system, or an equipment grounding conductor must be run with the circuit conductors and be connected to the equipment grounding terminal or lead on the appliance. Grounding Instructions –...
Page 14 BEFORE INSTALLATION CABINET PREPARATION AND WIRE ROUTING • The wiring may enter the opening from either side, the rear, or the floor within the shaded area. • The electrical connection is on the front right of the dishwasher. • Drill a 1.5 in. maximum diameter hole to run the electrical cable through the wall of the cabinet.
Page 15 BEFORE INSTALLATION PREPARING THE HOT WATER LINE • The water connection is on the left side of dishwasher. • The hot water line may enter the opening from either side, the rear, or the floor within the shaded area. • The hot water line may pass through the same hole as the electrical and drain hose.
Page 16 BEFORE INSTALLATION CONNECTING THE WATER LINE TO THE WATER SUPPLY Turn off the water supply. 2. Install a hand shut-off valve in an accessible location, such as under the sink. This is optional, but strongly recommended, and may be required by local codes. 3.
Page 17: Installation
INSTALLATION YOU’LL NEED • Phillips screwdriver • Screws D - ST3.5 X 45 (4) • 1/4” and 5/16” nut driver • Brackets (2) • Screws B - ST4 X 14 (8) • Top Hook Mounting Seats (2) • Screws C - ST3.5 X 25 (2) •...
Page 18 INSTALLATION 3. Put the hook into the slot of the outer door for the positioning. Put the hook into the slot of the outer door, for the positioning. Fix the decoration door onto the outer door by screws and bolts. ATTENTON: you need an assistant to hold the top of the machine to prevent it forward.
Page 19 INSTALLATION 4. Fix the decoration door onto the outer door by screws.
Page 20 INSTALLATION STEP 2: CHECK THE DOOR BALANCE Opening the door of your dishwasher before it is installed will cause it to tip forward. Do not open the door until you are ready to install CAUTION your dishwasher. If it is necessary to open the door, hold the top of the dishwasher securely with one hand and hold the door with the other hand.
Page 21 INSTALLATION STEP 3: ADJUST THE LEVELING LEGS Move the dishwasher close to the installation location and lay it on its back. Note: Make sure that the leveling feet are tightened all the way or removed if trying to tilt the dishwasher. 2.
Page 22 INSTALLATION STEP 4: REMOVE THE KICK PLATE Remove the two kick plate screws with a Phillips screwdriver, then remove the Step 4: Remove the toekick kick plate. • Remove the two toekick screws with a Phillips screwdriver, then remove the toekick. DOWN You’ll need: YOU’LL NEED...
Page 23 INSTALLATION Power cord Remove the junction box cover on the front right of the dishwasher. 2. Make sure that the junction box’s electrical wires are pulled inside of the junction box. 3. Remove the lock nut from the strain relief, then push the strain relief into the round opening of the junction box.
Page 24 INSTALLATION Direct wiring Remove the junction box cover from the power supply junction box on the wall. 2. Locate the three dishwasher wires, (white, black, and green) with stripped ends, then insert the dishwasher wires through the small hole in the junction box. 3.
Page 25 INSTALLATION YOU’LL NEED • Adjustable wrench • Teflon thread seal tape • 90 elbow ° STEP 6: INSTALL THE 90° WATER SUPPLY ELBOW Wrap the male thread of the 90° elbow with Teflon thread seal tape twice. Do not use plumber’s putty. 2.
Page 26 INSTALLATION YOU’LL NEED • Phillips screwdriver • Drain hose • Screw-type hose clamps STEP 7: INSTALL THE DRAIN HOSE Make sure that the leveling feet are loosened before standing the dishwasher upright. They may be tight from shipping/packaging. 2. Turn the dishwasher upright. 3.
Page 27 INSTALLATION STEP 8: LEVEL THE DISHWASHER Important: The dishwasher must be level for proper dish rack operation and wash performance. Open the door, then place a level on the door and on the rack track inside the tub to make sure that the dishwasher is level. 2.
Page 28 INSTALLATION YOU’LL NEED • Adjustable wrench • Level • Philips screwdriver 3. If the door hits the tub, the dishwasher is not installed correctly. Adjust the leveling legs to align the door to the tub. If the edge of the door hits the side of the tub, the dishwasher is not installed correctly. Adjust the leveling legs to align the door to the tub.
Page 29 INSTALLATION STEP 9: INSERTING THE DRAIN HOSE THROUGH THE CABINET • Insert the drain hose into the hole in the cabinet wall. If a power cord is used, guide the end through a separate hole. Tip: Position the water line and house wiring on the floor to avoid interfering with the base of the dishwasher.
Page 30 INSTALLATION STEP 10: SLIDE THE DISHWASHER PARTIALLY INTO THE CABINET Caution: Do not push against the front panel with your knees. Damage will occur. Position the dishwasher in front of the opening, then slide the dishwasher into the opening a few inches at a time. 2.
Page 31 INSTALLATION YOU’LL NEED • Phillips screwdriver • Top mounting clips (2) • Screws A ST4 x 20 (2) (two for each method) STEP 12: SECURING THE DISHWASHER TO THE COUNTERTOP • For countertops made of wood or materials that won’t be damaged by drilling, use Method 1.
Page 32 INSTALLATION Method 2 Remove the plastic tub caps from the inside of the dishwasher tub. 2. Drive a wood screw through the hole in the side of the dishwasher into the cabinet frame. Important: Drive the screws straight and flush. If the screws are too tight, the sides will bow.
Page 33 INSTALLATION YOU’LL NEED • Adjustable wrench • Teflon thread seal tape • Hot water line kit STEP 13: CONNECTING THE WATER SUPPLY LINE Make sure that you wrapped the 90° elbow with Teflon thread seal tape twice. 2. Slide the compression nut, then the ferrule over the end of the water supply line. Note: If you use braided stainless steel, you do not need a ferrule or compression nut.
Page 34 INSTALLATION STEP 14: CONNECTING THE DRAIN HOSE Important: Follow all local codes and ordinances. Cut on the marked line as required for your installation. The drain hose’s molded end will fit 5/8” or 1” diameter connections on the air gap, waste tee, or garbage disposal.
Page 35 INSTALLATION YOU’LL NEED • Phillips screwdriver • Coupler for extending drain line • Screw-type hose clamps (if applicable) Method 1 - Air gap to a waste tee or garbage disposal. Method 2 - High drain loop to a waste tee or garbage disposal. 4.
Page 36 INSTALLATION STEP 15: PERFORMING A PRE-TEST CHECK Review this list after installing your dishwasher to avoid problems or charges for a service call not covered by your warranty. • Make sure that power is turned OFF. • Make sure all foam and paper packaging is removed. •...
Page 37 INSTALLATION STEP16: WET TESTING THE DISHWASHER Turn on the power supply (or plug the power cord into the outlet.) 2. Select rinse cycle on dishwasher (refer to the User Guide for instructions). 3. Press START/CANCEL and close door. 4. Make sure that water enters the dishwasher. If water does not enter the dishwasher, check to be sure that water and power are turned on.
Page 38 INSTALLATION YOU’LL NEED • Phillips screwdriver STEP 17: REPLACING THE KICK PLATE • Place the kick plate against the legs of the dishwasher. The slots should align with the kick plate bracket screw holes. Allow the kick plate to touch the floor. Install the kick plate screws.
Page 39: Operational Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your dishwasher. CAUTION This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your dishwasher.
Page 40 IMPORTANT SAFETY INSTRUCTIONS BASIC PRECAUTIONS BEFORE USE: • Read all instructions before using the dishwasher. • The manual does not cover every possible condition and situation that may occur. • Use the dishwasher only for intended function as described in this manual. •...
Page 41 IMPORTANT SAFETY INSTRUCTIONS • Do not use the dishwasher if it has a damaged power line or plug, and do not plug the dishwasher into a damaged outlet, failure to observe these instructions may result in electrical shock. • Remove the door to the washing compartment when removing an old dishwasher from service or discarding it.
Page 42: Operation
OPERATION Water supply temperature should be between 120° F and 150° F. 2. Dispose of the discarded appliance and packing material properly. 3. The dishwasher must be grounded or it can result in a risk of electric shock. 4. If there is any damage to the dishwasher, please contact customer service at 614-777-5004.
Page 43 OPERATION FILTER SYSTEM Your dishwasher has a multiple filter system which includes four separate filter meshes. It separates dirty water and clean water into different chambers. The multiple filter system helps your dishwasher to get better performance with less water and less energy.
Page 44 OPERATION USING THE CONTROL PANEL Your dishwasher’s control panel is located on the top edge of the door. The door must be open to make settings and operate the dishwasher. POWER On/Off - 3sec - Hold this button down for three seconds to turn the power on or off.
Page 45 OPERATION CONTROLS AND INDICATORS Options can add enhancements to the cycle selected. DISPLAY - Shows the remaining hours and minutes of the current cycle, delay hours remaining, and error codes (see “Error Codes” on page 56). 8. Rinse Aid - Turns on when you need to add rinse aid. Sanitized - Turns on when a sanitized cycle is finished.
Page 46 OPERATION 14. HI TEMP WASH - Use to maintain the water temperature at140° F max. This option is available with the AUTO, NORMAL, and HEAVY cycles. 15. START/CANCEL - Press to start the dishwasher after you have selected a cycle and function (if desired). Close the door. The cycle indicator begins to blink and the function indicator turns on.
Page 47 OPERATION PREPARING AND LOADING DISHES Preparing dishes for washing • Scrape away large pieces of food, bones, pits, toothpicks, and similar items. The continuous filtered wash system will remove the remaining food particles. • Burned-on foods should be loosened before loading. •...
Page 48 OPERATION OPERATION ADJUSTING THE UPPER RACK ADJUSTING THE UPPER RACK ADJUSTING THE UPPER RACK This dishwasher has a convenient top rack for silverware, This dishwasher has a convenient top rack for silverware, cutlery, and small items. This dishwasher has a convenient top rack for silverware, cutlery, and small items. This rack can be adjusted to accommodate varying loads, as sh This rack can be adjusted to accommodate varying loads, as shown below.
Page 49 OPERATION ADJUSTING THE UPPER RACK The height of the upper rack can be adjusted to accommodate loading taller dishes in either rack. Lift the rack to move it to the upper position. 2. Press the handle to move it to the lower position. LOADING THE UPPER RACK The upper rack is designed for cups, glasses, small plates, bowls, and plastic items marked dishwasher-safe.
Page 50 OPERATION LOADING THE TOP RACK You can place the items in the top rack randomly or in an orderly fashion. The image Loading the top rack below shows how to load the top rack for 16 place settings: You can place the items in the top rack randomly or in an orderly fashion. The image below shows how to load the top rack for 16 place settings: Large spoons Large spoons...
Page 51 OPERATION LOADING THE BOTTOM RACK The bottom rack is designed to accommodate plates, bowls, saucers, and cookware. The adjustable rack lets you load items up to 13 inches high. Large items should be placed along the edge, with the inside faces down, so they do not interfere with the Loading the bottom rack middle or lower spray arms or prevent the detergent dispenser from opening.
Page 52 OPERATION LOADING THE SILVERWARE BASKET The silverware basket is divided into three separate sections, which can be placed in either the upper or lower racks. Caution: Make sure that nothing protrudes through the bottom of the silverware basket to block the lower spray arm. ADDING A DISH The silverware basket is divided into three separate sections, which can be placed in either the upper or lower racks.
Page 53 OPERATION FILLING THE DETERGENT DISPENSER Push the detergent dispenser cover latch downwards to open the detergent cup. 2. Add detergent (dry powder, liquid, or packets) to the cup. 3. Close the detergent dispenser cover. The amount of detergent required depends on the cycle selected and the soil level on the dishes.
Page 54 OPERATION FILLING THE RINSE AID DISPENSER Your dishwasher is designed to use a liquid rinse aid. The use of rinse aid greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month. Try to keep the dispenser full, but do not over fill it.
Page 55 OPERATION USING RINSE AID Rinse aid greatly improves drying and reduces water spots and filming. Without rinse aid, your dishes and dishwasher interior will have excessive moisture. In addition, the heated dry option will not perform as well without rinse aid. The rinse aid dispenser, located next to the detergent cup, automatically releases a measured amount of rinse aid during the last rinse.
Page 56: Maintenance And Cleaning
MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING FACTORS AFFECTING PERFORMANCE FACTORS AFFECTING PERFORMANCE Caution: Caution: TO AVOID BURN INJURY: Allow the heating element to cool before TO AVOID BURN INJURY: Allow the heating element to cool before attempting to clean the interior of your dishwasher. attempting to clean the interior of your dishwasher.
Page 57 MAINTENANCE AND CLEANING 2. Rotate the cylinder filter, then lift it out. 3. Lift the fine filter from the bottom of the tub. 4. Take out the fabric filter.
Page 58 MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING 5. Flush the filters by holding them under running water. 5. Flush the filters by holding them under running water. 6. Replace the fabric filter. Replace the fine filter. 6. Replace the fabric filter. 8.
Page 59 MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING The inside of the dishwasher is self-cleaning under normal use. If needed, the tub The inside of the dishwasher is self-cleaning under normal use. If needed, the tub gasket can be cleaned with a damp cloth. Use a brush to clean the opening in the gasket can be cleaned with a damp cloth.
Page 60 MAINTENANCE AND CLEANING Your dishwasher should be protected from freezing if you plan to leave it for extended periods in an unheated place. Have a qualified person do the following: To disconnect service: Turn off the electrical power to the dishwasher at the supply source by moving fuses or tripping circuit breaker.
Page 61: Troubleshooting
TROUBLESHOOTING Refer to this table to correct minor issues before calling for service. ERROR CODES If there is an air gap installed with your dishwasher, make sure it is clean so the dishwasher will drain properly. Air gap is not part of your dishwasher. Before you clean the air gap, turn off the dishwasher, then remove the plastic air gap cover and clean with a toothpick.
Page 62 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The dishwasher The door may not be closed Make sure that the door is won’t start properly. closed and latched. The power is off or not Make sure that the power is connected. connected and turned on. The delay start option is selected.
Page 63 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The dishes are not The water pressure is too low. Make sure that the water clean enough pressure is above 20 psi. Use your dishwasher when water demand is low. The inlet water temperature is Make sure that the dishwasher is too low.
Page 64 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Spots and filming Water hardness is too high. For extremely hard water, install on dishes a water softener. Dishes are loaded improperly. Reload the dishwasher as shown in “Preparing and Loading Dishes” on page 42. Old or damp rinse aid power is Use fresh, liquid rinse aid.
Page 65 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Suds in the tub Using improper detergent. or Make sure to use only automatic pod style cleaners. dishwasher detergent. The dispenser is not designed for the use of pods. To use pods, throw them into the bottom of the tub and it will release the detergent like normal.
Page 66 Need additional information? Scan the QR code to view the most up-to-date version of our user manual and installation guide. Need to purchase a part or accessory for your ZLINE product? Visit ZLINEparts.com, ZLINE's official parts distribution partner.
Page 67 2.0.0 zlinekitchen.com 1-614-777-5004 contact@zlinekitchen.com...
