User Manual
CLASSIC DISHWASHERS
DW7713 AND DW7714 MODELS
www.zlinekitchen.com
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW7714 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zline DW7714

Summary of Contents for Zline DW7714

  • Page 1 User Manual CLASSIC DISHWASHERS DW7713 AND DW7714 MODELS www.zlinekitchen.com...
  • Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
  • Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 OPERATION ........4 Product Specifications .

  • Page 5: Important Safety Instructions

    It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating the dishwasher. ZLINE is not liable for damages resulting from improper use or installation.
  • Page 6 • The dishwasher must be properly grounded or it can result in a risk of electric shock. A permanent electrical connection is allowed. • Do not operate the appliance if it’s damaged, malfunctioning, partially disassembled, or has missing or broken parts. If the unit arrives damaged, contact ZLINE at 1-614-777-5004 for help. BASIC PRECAUTIONS BEFORE USE •...
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS • To reduce the risk of injury, do not allow children to play in or on a dishwasher. Keep young children and pets away from the dishwasher when it is operating. Do not let children abuse, sit, or stand on the door or racks of the dishwasher. •...

  • Page 8: Operation

    OPERATION ELECTRIC SHOCK HAZARD • As with all equipment using electricity, water, and moving parts, potential hazards exist. To safely operate this appliance, become familiar with its operation and exercise care when using it. • The dishwasher must be properly grounded by a professional technician. Never connect it to an ungrounded outlet.

  • Page 9: Product Specifications

    NOTE: Specifications are subject to change without any notice for quality improvement purposes. The actual appearance of the dishwasher may differ from the illustrations in this manual. SPECIFICATIONS FOR DW7714-18 MODEL (18” PANEL READY) Capacity Up to 10 place settings •...
  • Page 10 OPERATION PRODUCT SPECIFICATIONS TERM DESCRIPTION LOCATION/APPEARANCE The pressure switch is a protection • In the back of the dishwasher device that detects water pressure. Pressure switch on the right. It prevents the water level from • Red, white, and blue. becoming too high.
  • Page 11 OPERATION PRODUCT SPECIFICATIONS - DW7714-18 1. Lock 6. Lower Spray Arm 2. Upper Basket 7. Detergent Dispenser 3. Upper Spray Arm 8. Cup Shelf 4. Cutlery Basket 9. Heating Element 5. Lower Basket 10. Rinse Aid Dispenser...
  • Page 12 OPERATION PRODUCT SPECIFICATIONS - DW7713-24 1. Lock 6. Detergent Dispenser 2. Upper Basket 7. Cup Shelf 3. Upper Spray Arm 8. Heating Element 4. Cutlery Basket 9. Rinse Aid Dispenser 5. Lower Basket...
  • Page 13 OPERATION FILTER SYSTEM Your dishwasher has a multiple filter system. In the system, there are three mesh filters. • It can separate soiled water and clean water in different chambers. • The system helps your dishwasher get better performance with less water and less energy. See page 20 for how to clean the filters.
  • Page 14 OPERATION HOW YOUR DISHWASHER CLEANS • Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms against soiled surfaces. • The dishwasher fills with water covering the filter area. Water is then pumped through the multiple filter system and spray arms.

  • Page 15: Control Panel

    OPERATION CONTROL PANEL 1. Start/Pause • Open the door to select the desired cycle and options, touch the Start/Pause button, and close the door within 4 seconds to start the cycle or begin the delay countdown. • To cancel and reset the program during the cycle, open the door and touch Start/Pause for 3 seconds.
  • Page 16 OPERATION 3. Delay • To delay the start of a selected cycle, press the delay start pad until the desired delay time shows in the LED display. You can delay the start for 1 to 24 hours. • To cancel the delay start option before the delay period is over, press the start/cancel pad for 3–5 seconds.
  • Page 17 (see Troubleshooting, 22). • If error codes are displayed and troubleshooting measures are unsuccessful, contact ZLINE Customer Service at 1-614-777-5004 for help. We will be able to provide assistance in troubleshooting the problem and/or locate an authorized service technician if needed.
  • Page 18 OPERATION CYCLE CHART PROGRAM DESCRIPTION OF CYCLE WATER CYCLE TIME • Pre Wash • Main Wash (140 °F/60 °C) 19.7 Liters Heavy • Rinse (149 °F/65 °C) minutes (5.2 Gallons) • Rinse with Sanitize (156 °F/69 °C) • Drying • Pre Wash •...

  • Page 19: Dish Preparation

    OPERATION DISH PREPARATION • Prior to loading the dishwasher, scrape away large pieces of food, bones, pits, toothpicks, etc. The continuously filtered wash system will remove remaining food particles. • Burned-on foods should be loosened before loading. Empty liquids from glasses and cups. •...
  • Page 20 • Load large items such as pans and pots so their open sides face downwards. We recommend loading cups, stemware, and small plates in the upper basket. Model DW7714-18 Model DW7713-24 8 place settings 10 place settings LOADING THE UPPER BASKET •...
  • Page 21 4. Forks 2. Knives 5. Large Spoons 3. Salad Forks 6. Large Forks Model DW7714-18 8 place settings Model DW7713-24 10 place settings Do not let items extend or protrude though the bottom of the basket to avoid blocking the spray arm.

  • Page 22: Filling The Detergent Dispenser

    OPERATION FILLING THE DETERGENT DISPENSER Open the detergent dispenser cap by pushing the detergent dispenser release button. NOTE: The flap should always open at the end of a dishwashing cycle. 4. Add the recommended amount of detergent to the main wash detergent compartment.

  • Page 23: Maintenance And Cleaning

    MAINTENANCE AND CLEANING FILLING THE RINSE AID RESERVOIR • Your dishwasher has been designed to use liquid rinse aid only. • Using a powdered rinse aid will clog the reservoir opening and cause the dishwasher to malfunction. • Rinse aid improves the drying performance of the dishwasher. Do not add regular detergent to the rinse aid reservoir.
  • Page 24 MAINTENANCE AND CLEANING CLEANING THE EXTERIOR • It’s best to clean spills on the outside of your dishwasher as they occur. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. • Do not use benzene, wax, thinner, chlorine bleach, or alcohol. These materials may discolor the inner walls and cause stains.

  • Page 25: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Power supply or power line Check and connect power supply The dishwasher is not connected won’t start Delay start option has Refer to delay start section in been selected this manual Rinse Aid Display screen shows “LSb” Add rinse aid light is on The dishwasher is connected...
  • Page 26 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Inspect detergent dispenser door latch Detergent Improper operation of the for operation; if using pod or solid dispenser detergent cover detergent, this may prevent the closure won’t close of the detergent dispenser door Make sure the dishwasher is Previous cycle has not Water remains in connected to hot water;...
  • Page 27 TROUBLESHOOTING CODE ERROR MESSAGE POSSIBLE REASON 1. Check the water supply 2. Check the inlet valve 3. Check the inlet During the water inlet step, 4. Check the flow meter if the flow meter can’t detect 5. Check the pressure switch the water after 4 minutes, the 6.
  • Page 28 TROUBLESHOOTING CODE ERROR MESSAGE POSSIBLE REASON (Only appears in the 1. Check the inlet water temperature factory mode) 2. Check the thermistor E6 - Thermal sensor cut. 3. Check the PCB E7 - Thermal sensor short. If one button is pushed for more than 30 seconds, the The warning will be resolved when the dishwasher will display an...
  • Page 29 TROUBLESHOOTING E1 Longer Inlet Time Is there any water in the tub? Is the incoming water pressure Is the incoming water turned on? 20 PSI -145 PSI? Is the water supply line installed correctly? Is the drain hose Adjust water pressure Is the water supply Replace the hose.

  • Page 30: Warranty

    ZLINE Kitchen and Bath (“ZLINE”) dishwashers have a one year parts and service warranty. ZLINE warranty periods begin from the original purchase date of the product and solely cover the original purchaser of the product, delivered new and in its original carton. The limited warranty covers all parts and labor for necessary repairs if any part of the product, or the product itself, proves to be defective in materials or workmanship.
  • Page 31 ZLINE reserves the right to offer to replace the defective part or the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
  • Page 32 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
  • Page 33 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of our Installation and User Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
