User Manual MONUMENT DISHWASHERS WITH DURAWASH DWMT MODELS www.zlinekitchen.com...
Page 2
ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
Page 3
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS ....1 OPERATION ........6 Filter System .
Page 5
TABLE OF CONTENTS CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your dishwasher. CAUTION This symbol indicates there are important operating and maintenance instructions in the manuals accompanying your dishwasher. WARNING BEFORE YOU BEGIN •...
• Do not install this dishwasher if it has missing or broken parts. If the dishwasher arrives damaged, contact ZLINE Customer Service at 1-614-777-5004 for help. FOR YOUR SAFETY Read and observe all CAUTIONS and WARNINGS shown throughout these instructions.
Page 7
IMPORTANT SAFETY INSTRUCTIONS FOR YOUR SAFETY Read and observe all CAUTIONS and WARNINGS shown throughout these instructions. While performing installations described in this booklet, gloves and safety glasses or goggles should be worn. Basic precautions before use • Read all instructions before using the dishwasher. •...
Page 8
IMPORTANT SAFETY INSTRUCTIONS • Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children away from the dishwasher when the door is open. • Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two weeks or more.
Page 9
To reduce the risk of electrical shock, fire, or injury to persons, the installer must ensure that the dishwasher is completely enclosed at WARNING the time of installation. DWMT-24 SPECIFICATIONS SPECIFICATIONS • 23 7/8" W x 24 1/2" D x 33 3/4" (min) - 35" (max) H Panel Ready Dimensions Dimensions •...
3. The dishwasher must be grounded or it can result in a risk of electric shock. 4. If there is any damage to the dishwasher, please contact ZLINE Customer Service at 1-614-777-5004. Do to attempt to repair or replace any part by yourself. For information on installing and setting up your dishwasher, refer to the Installation Manual provided with your appliance.
OPERATION FILTER SYSTEM Your dishwasher has a multiple filter system that includes four separate filter meshes. It separates dirty water and clean water into different chambers. The multiple filter system helps your dishwasher operate with better performance by using less water and less energy. SMART WASH SYSTEM Your dishwasher has a smart wash system under the normal wash program that selects the wash cycle based on how large and soiled the load is, permitting your dishwasher to...
OPERATION CONTROL PANEL USING THE CONTROL PANEL Your dishwasher’s control panel is located on the top edge of the door. The door must be open to select wash cycle settings and operate the dishwasher. POWER On/Off 3sec - Hold this button, located on the far left of the control panel, down for three seconds to turn the unit’s power on or off.
Page 13
OPERATION CONTROLS AND INDICATORS 7. DISPLAY - Shows the remaining hours and minutes of the current cycle, delay hours remaining, and error codes (see "Error Codes" on page 25). 8. Rinse Aid - Turns on when you need to add rinse aid. 9.
Page 14
OPERATION 15. START/CANCEL - Press to start the dishwasher after you have selected a cycle and function (if desired). Close the door. The cycle indicator begins to blink and the function indicator turns on. If you don’t close the door within four seconds of pressing START/ CANCEL, the dishwasher pauses.
OPERATION PREPARING AND LOADING DISHES PREPARING DISHES Preparing dishes for washing • Scrape away large pieces of food, bones, pits, toothpicks, and similar items. The continuous filtered wash system will remove the remaining food particles. • Burned-on foods should be loosened before loading into the dishwasher. •...
OPERATION OPERATION OPERATION ADJUSTING THE UPPER RACK ADJUSTING THE UPPER RACK OPERATION This dishwasher has a convenient top rack for silverware, This dishwasher has a convenient top rack for silverware, cutlery, and small items. ADJUSTING RACKS OPERATION ADJUSTING THE UPPER RACK ADJUSTING THE UPPER RACK This rack can be adjusted to accommodate varying loads, as sh This rack can be adjusted to accommodate varying loads, as shown below.
Page 17
OPERATION ADJUSTING THE UPPER RACK The height of the upper rack can be adjusted to accommodate loading taller dishes in either rack. 1. Lift the rack to move it to the upper position. 2. Press the handle to move it to the lower position. LOADING THE UPPER RACK The upper rack is designed for cups, glasses, small plates, bowls, and plastic items marked dishwasher-safe.
OPERATION LOADING RACKS LOADING THE TOP RACK You can place the items in the top rack randomly or in an orderly fashion. The image below shows how to load the top rack for 16 place settings: Large spoons Small spoons Knives Small forks Forks...
Page 19
OPERATION LOADING THE BOTTOM RACK The bottom rack is designed to accommodate plates, bowls, saucers, and cookware. The adjustable rack lets you load items up to 13" (330 mm) high. Large items should be placed along the edge, with the inside faces down, so they do not interfere with the middle or lower spray arms or prevent the detergent dispenser from opening.
Page 20
OPERATION LOADING THE SILVERWARE BASKET The silverware basket is divided into three separate sections, which can be placed in either the upper or lower racks. CAUTION: Make sure nothing protrudes through the bottom of the silverware basket that would block the lower spray arm from turning effectively. ADDING A DISH The silverware basket is divided into three separate sections, and it can be placed in either the upper or lower racks.
OPERATION USING DETERGENT FILLING THE DETERGENT DISPENSER 1. Push the detergent dispenser cover latch downward to open the detergent cup. 2. Add detergent (dry powder, liquid, or packet) to the cup. 3. Close the detergent dispenser cover. The amount of detergent required depends on the cycle selected and the soil level on the dishes.
OPERATION USING RINSE AID FILLING THE RINSE AID DISPENSER Your dishwasher is designed to use a liquid rinse aid. The use of rinse aid greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month.
Page 23
OPERATION Rinse aid greatly improves drying and reduces water spots and filming. Without rinse aid, your dishes and dishwasher interior will have excessive moisture. In addition, the heated dry option will not perform as well without rinse aid. The rinse aid dispenser, located next to the detergent cup, automatically releases a measured amount of rinse aid during the last rinse.
Page 24
MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING FACTORS AFFECTING PERFORMANCE FACTORS AFFECTING PERFORMANCE Caution: TO AVOID BURN INJURY: Allow the heating element to cool before TO AVOID BURN INJURY: Allow the heating element to cool before attempting to clean the interior of your dishwasher. CAUTION attempting to clean the interior of your dishwasher.
MAINTENANCE AND CLEANING 2. Rotate the cylinder filter, then lift it out. 3. Lift the fine filter from the bottom of the tub. 4. Take out the fabric filter.
Page 26
5. Flush the filters by holding them under running water. MAINTENANCE AND CLEANING 5. Flush the filters by holding them under running water. 6. Replace the fabric filter. Replace the fine filter. 8. Replace the cylinder filter. 6. Replace the fabric filter. Replace the bottom rack.
Page 27
MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING The inside of the dishwasher is self-cleaning under normal use. If needed, the tub gasket can be cleaned with a damp cloth. Use a brush to clean the opening in the The inside of the dishwasher is self-cleaning under normal use. If needed, the tub gasket can end of the gasket.
Page 28
MAINTENANCE AND CLEANING CLEANING THE AIR GAP If there is an air gap installed with your dishwasher, make sure it is clean so the dishwasher will drain properly. Before you clean the air gap, turn off the dishwasher, then remove the plastic air gap cover and clean with a toothpick.
TROUBLESHOOTING Refer to this table to correct minor issues before calling for service. CODE MEANING POSSIBLE CAUSE • Faucet is not opened Slow fill time/fill time has exceeded • Water intake is restricted time alloted • Water pressure is too low Overflow A leak in the dishwasher The display board can’t receive or the...
Page 30
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The door may not be Make sure that the door is closed properly. closed and latched. Make sure that the The power is off or power is connected not connected. dishwasher won’t start and turned on. Refer to the “Delay”...
Page 31
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Make sure that the water pressure is above 20 psi. The water pressure is too low. Use your dishwasher when water demand is low. Make sure that the dishwasher is connected to a hot water supply. If not, The inlet water change the water supply temperature is too low.
Page 32
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION For extremely hard water, Water hardness is too high. install a water softener. Reload the dishwasher as shown in "Preparing Dishes are loaded improperly. and Loading Spots and Dishes" on page 9. filming on dishes Old or damp rinse aid Use fresh, liquid rinse aid.
Page 33
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Check the air gap (if so equipped). Make sure that The drain is clogged. the disposer is empty (if so connected). Make sure that the drain The dishwasher does The drain hose is kinked. hose is not kinked and is not drain properly.
Page 34
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION There are black Make sure that the water Aluminum utensils have rubbed or gray marks inlet temperature is not less against the dishes. on the dishes than 120 °F (49 °C). Use a spot cleaner to Coffee or tea stains.
ZLINE Kitchen and Bath (“ZLINE”) dishwashers have a one year parts and service warranty. ZLINE warranty periods begin from the original purchase date of the product and solely cover the original purchaser of the product, delivered new and in its original carton. The limited warranty covers all parts and labor for necessary repairs if any part of the product, or the product itself, proves to be defective in materials or workmanship.
Page 36
ZLINE reserves the right to offer to replace the defective part or the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
Page 37
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
Page 38
1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of our User Manual and Installation Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
