  • Page 1 allac ishwashers Installation Guide and Users Manual...

  • Page 2: Registering Your Product

    REGISTERING YOUR PRODUCT Please register your ZLINE appliance. Begin the simple registration process by scanning the QR code. SCAN ME By registering your appliance, you will have easy and accurate access to: • Technical Support • Warranty Service • Tracking your support inquiries •...
  • Page 3 With an endless selection of features and finishes, our inspiration is your reality. ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive...

  • Page 4: Warranty

    WARRANTY COVERAGE ZLINE Kitchen and Bath dishwashers parts will be warrantied for one year from the original purchase date for the original purchaser of the product. TERMS This warranty applies only to the original purchaser of the product installed for normal residential use.
  • Page 6 TABLE OF CONTENTS SAFETY INSTRUCTIONS BEFORE INSTALLATION Electric Shock Hazard Tools and Parts Enclosure Dimensions INSTALLING THE DISHWASHER Adjusting Height Water Supply Connection Steam Protection Foil Placement of Dishwasher into Enclosure Drain Hose and Water Supply Adjusting the Kick Plate Installation Checklist Final Instructions OPERATION...

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS To prevent accidents, which could cause serious injury or death, as well as dishwasher damage, read these instructions before installation and/or use. When using the dishwasher, carefully follow the precautions in this manual. These are provided in order to save time and effort and to help ensure optimum dishwasher performance.

  • Page 8: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these installation instructions completely before installing and follow them carefully. Save these installation instructions and pass them on to any future user. WARNING CAUTION NOTICE • In addition to these instructions, the dishwasher shall be installed: •...
  • Page 9 SAFETY INSTRUCTIONS • Dishwasher must be secured to adjacent cabinetry using the brackets provided. Failure to do this may cause damage to property or bodily injury. • Ensure that any plastic wrappings, bags, small pieces etc. are disposed of safely and kept out of the reach of children.
  • Page 10 • When loading items to be washed: • Locate sharp items so that they are not likely to damage the door seal. • Load sharp knives with the handles up to reduce the risk of type injuries. • Do not wash plastic items unless they are marked “dishwasher safe”or the equivalent.
  • Page 11 SAFETY INSTRUCTIONS • Do not store or use flammable liquids or vapors in the area of the dishwasher, near or on the appliance. • Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for such a period, before using the dishwasher, turn on all hot-water faucets and let the water flow from each for several minutes.
  • Page 12 WARNING • Connect to a properly rated, protected, and sized power supply circuit to avoid electrical overload. • The dishwasher is designed for an electrical supply of 120 V (volts), 60 Hz (hertz), AC, connected to a dishwasher-de dicated, properly grounded, electrical circuit with a fuse or breakers rated for 15 amperes.

  • Page 13: Before Installation

    BEFORE INSTALLATION Tools which may be needed: Pipe Wrench Wire Cutter Drill Hole Saw Hammer Wire Stripper Tape Measure Torx Screwdriver Philips Screwdriver Flathead Screwdriver Scissors Adjustable Wrench Level Brush Pencil Materials which may be needed: (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/4”...

  • Page 14: Manual Bag

    The parts required for positioning the dishwasher are in plastic bags. Check that all of the following parts are contained in plastic bags. MANUAL BAG The dishwasher comes with a manual bag containing the product manual. DISHWASHER PARTS BAG 1 a.
  • Page 15 BEFORE INSTALLATION 18” 24”...
  • Page 16 The mounting brackets in the plastic bag should be used when the dishwasher is installed in the cabinetry. Use of any parts other than mounting brackets may result in damage to property or bodily injury. If countertop material is wooden, etc. If countertop material is ceramic, etc.

  • Page 17: Installation

    INSTALLATION installing the dishwasher ADJUSTING HEIGHT Before the dishwasher is placed into the cabinetry, the front legs will be completely retracted. Place into the cabinetry. 2. Adjust the leg level with a flathead screwdriver to stabilize the dishwasher and raise it to the enclosure height. 3.
  • Page 18 24” If the height of the enclosure is 33 7/8” to 35 7/8”, use short supports as shown in the figure. If the height of the enclosure is above 35 7/8”, use long supports as shown in the figure. ops.(+50) H=35 7/8” to 37 3/4”...

  • Page 19: Water Supply Connection

    INSTALLATION installing the dishwasher WATER SUPPLY CONNECTION Water supply may be connected to the dishwasher in one of two ways: • With metal braided hose. • With copper tubing Braided Hose/Copper Tubing • After connections are made, turn on the water supply to check for leaks. •...

  • Page 20: Steam Protection Foil

    STEAM PROTECTION FOIL Steam will be output when the dishwasher door is opened during the operation of the dishwasher and after completion of the working cycle. In order to prevent the resulting steam from collecting and damaging at the underside of the counter top, use a steam protection foil included in the plastic bag.

  • Page 21: Placement Of Dishwasher Into The Opening

    INSTALLATION PLACEMENT OF DISHWASHER INTO THE OPENING Now, place the dishwasher into the opening and get ready to connect all hoses and electrical connections. • The power-supply receptacle for the appliance shall be installed in a cabinet or on a wall adjacent to the undercounter space in which the appliance is to be installed.

  • Page 22: Drain Hose Connection

    DRAIN HOSE CONNECTION Check the parts on the sink to which the drain hose will be connected. 2. There are several ways to insert the drain hose into the drain hose connector of the sink, as shown in the following figures. Connect the drain hose in accordance with the water pipe installation regulations in your region.
  • Page 23 INSTALLATION 3. Check the size of the sink’s drain hose connector. If needed, cut the drain hose so its end fits onto the sink connector (5/8", 3/4", or 1" - as shown below). If the end of the drain hose does not fit onto the drain hose connector of the sink, use an adapter, purchasable at a plumbing/hardware supply store.
  • Page 24 installing the dishwasher 5. If there is no air gap, make sure to hang the middle of the drain hose well above the sink cabinet base to prevent back flow. Dishwasher Sink Drain Hose Min. 30 in. Min. 20 in. 6.

  • Page 25: Adjusting The Kick Plate

    INSTALLATION installing the dishwasher ADJUSTING THE KICK PLATE Now that the dishwasher is successfully installed, attach the kick plate to the dishwasher. The two piece kick plate can be adjusted to the height and depth needed for the kitchen. 18” If the height is above 32 9/32”...
  • Page 26 3. As shown below, the cylindrical feet of the adjustable plinth are attached to the plinth fixing metal parts and shifted through the cavity of the part. 4. Depending on the desired depth, plinth locking (s) is attached to the kick plate bracket (n).

  • Page 27: Installer Checklist

    6. If the dishwasher does not operate properly, refer to the troubleshooting section. • If dishwasher is not operating properly after following these steps: Contact ZLINE at 1-614-777-5004 to schedule an authorized service agent to inspect the new dishwasher for any function related failure.
  • Page 28 OPERATION (18") 4.1. General Appearance 1. Upper basket with racks 2. Upper spray arm 3. Lower basket 4. Lower spray arm 5. 3rd basket( Model Depending) 6. Top nozzle( Model Depending) 7. Filters 8. Rating plate Upper Basket with Racks 9.
  • Page 29 OPERATION (24") 4.1. General Appearance 1. Upper basket with racks 2. Upper spray arm 3. Lower basket 4. Lower spray arm 5. 3rd basket( Model Depending) 6. Top nozzle( Model Depending) 7. Filters 8. Rating plate Upper Basket with Racks 9.

  • Page 30: Operation

    OPERATION BEFORE USING THE APPLIANCE Preparing The Dishwasher For First Use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the dishwasher. • Open the door of the dishwasher. • Remove all packaging material inside the dishwasher. •...

  • Page 31: Maintenance Information

    OPERATION MAINTENANCE INFORMATION When the dishwasher isn’t in operation: • Disconnect the plug and close the tap. • Leave the door slightly open to prevent odor formation. 2. Select the dry option to remove water droplets. 3. Place dishes in the dishwasher properly to achieve the best energy consumption, washing and drying performance.
  • Page 32 OPERATION TEST STRIP The washing effectiveness of your dishwasher depends on the softness of the tap water. For this reason, the dishwasher is equipped with a system that reduces the Test Strip ( For Models With Water Softener ) hardness in the main water supply. The washing effectiveness will increase when the Test Strip ( For Models With Water Softener ) Test Strip ( For Models With Water Softener ) Test Strip ( For Models With Water Softener )

  • Page 33: Salt Refill Indicator

    OPERATION OPERATION SALT INDICATOR Please check the salt indicator on the control panel to see whether there is adequate amount of softening salt in the dishwasher or not. Refill the salt reservoir with salt whenever salt warning indicator appears on the control panel of the dishwasher. In order to add salt to the dishwasher, Open the door of the dishwasher, 2.

  • Page 34: Detergent Usage

    OPERATION OPERATION DETERGENT USAGE WARNING: Use a detergent specifically designed for use in domestic dishwashers. WARNING • Use powder, gel, and tablet detergents in the market that have been designed for household dishwashers. • Detergent should be put into the compartment prior to starting the dishwasher. •...

  • Page 35: Filling The Detergent

    contact detergent manufacturers directly. Use a detergent ned for use in Check that the detergent dispenser is shers. empty after the completion of each wash OPERATION program der, gel,and tablet market that have been 5.6. Filling The Detergent sehold dishwashers. be put into the FILLING THE DETERGENT or to starting the machine.
  • Page 36 OPERATION Using Combined Detergents • Detergent manufacturers also manufacture combined detergents that are called 2 in 1, 3 in 1, 5 in 1, etc. • The 2 in1 detergents contain detergent salt or rinse aid. While using the 2 in 1 detergents, it should be observed which functions the tablet consists of.
  • Page 37 OPERATION CAUTION: Solubility of the tablet detergents produced by different companies can vary depending on the temperature and time. Therefore, it is CAUTION not recommended to use such detergents in short programs. It is more suitable to use powder detergents in such programs. WARNING: Should any problem that has not been encountered before arise with the use of this type of detergents, contact the detergent WARNING...

  • Page 38: Filling The Rinse-Aid And Setting

    the display, the machine will d setting, NOTE: When the Rinse Aid indicator 5. The amount of rinse aid is a lights up, the rinse aid reservoir contains pressing “Program Selection + sufficient rinse aid for 2 - 3 programs only. OPERATION 6.

  • Page 39: Loading The Dishwasher

    OPERATION LOADING THE DISHWASHER Places the dishes into the dishwasher properly is the best for energy consumption, washing and drying performance. • Load round and deep items, such as pots with long handles, pot lids, plates, salad plates, and cutlery sets, into the lower basket. •...
  • Page 40 OPERATION NOTE: Do not overload the dishwasher and pay attention to manufacturer instructions regarding which dishes are appropriate for use in a dishwasher. Only with suitable dishes will there be optimal washing results and appropriate use of energy. High temperature water and dishwasher detergent may form a chemical synthesis that can damage certain items.

  • Page 41: Upper Rack

    cutlery NOTE: While the appliance is running if ult. To you open the door all functions are s place automatically interrupted. Once the door is ed dishes closed functions will continue to work. th their ontally on Upper Rack 6.2. Alternative Basket Loads 6.3.
  • Page 42 OPERATION (18”) 6.3. Incorrect Loads INCORRECT LOADS USA-CAN - 19 SA-CAN - 19...
  • Page 43 6.1 Upper Rack 6.2. Lower Rack Load the upper rack with dessert plates, You can load into the lower basket such cups, glasses etc. round and deep items as pots with long UPPER RACK Top rack load pattern for 10 place settings. handles, pot lids, plates, salad plates, Load the upper rack with dessert plates, cups, glasses etc.
  • Page 44 OPERATION (24”) 6.2. Lower Rack plates, You can load into the lower basket such LOWER RACK round and deep items as pots with long Load round and deep items, such as pots with long handles, pot lids, plates, salad handles, pot lids, plates, salad plates, cutlery sets.
  • Page 45 1: Salad Fork 2: Teaspoon 3: Dinner fork 4: Knife-solid handle 5: Serving spoon 6.4. Incorrect Loads INCORRECT LOADS 6: Serving fork tings . Cutlery Basket load pattern for 8 place settings . y have WARNING: Sharp cutlery may have peration shifted position during the wash operation Carefully...
  • Page 46 Upper Cutlery Basket OPERATION Upper Cutlery Basket ( Model Depending ) ( Model Depending ) The upper cutlery basket is designed for the The upper cutlery basket is designed for the placement of large and small cutlery and The upper cutlery basket is designed for the placement of large and small cutlery and placement of large and small cutlery and utensils.

  • Page 47: Top Basket

    Top Basket Rack with height adjustment TOP BASKET These racks are designed to increase the capacity of top basket. You can place your Rack with height adjustment cups and glasses on these racks. Thanks • These racks are designed to increase the capacity of top basket. Place cups to adjustable feature of the racks, you can place glasses of different sizes under the and glasses on these racks.
  • Page 48 OPERATION Top Basket Rack with height adjustment These racks are designed to increase the your capacity of top basket. You can place your cups and glasses on these racks. Thanks to adjustable feature of the racks, you can place glasses of different sizes under the racks.
  • Page 49 Lower Basket Folding Racks 2) Height setting - when basket is filled filled Lower Basket Folding Racks ( model depending ) Folding racks consisting of four parts that Folding racks consisting of four parts that LOWER BASKET FOLDING RACKS The upper basket includes a mechanism are located on the lower basket of your are located on the lower basket of your Folding racks consisting of four parts that are located on the lower basket of the...
  • Page 50 the upper rack may be changed using the In certain models, the height setting of wheels which are present at two height the upper rack may be changed using the levels. wheels which are present at two height levels. CAUTION: Make sure that the rack is empty.
  • Page 51 OPERATION 2) Height setting - when basket is filled Lower Basket Folding Racks HEIGHT SETTING (WHEN BASKET IS FILLED): ( model depending ) 2) Height setting - when basket is filled Folding racks consisting of four parts that Lower Basket Folding Racks The upper basket includes a mechanism which enables the height of the basket The upper basket includes a mechanism ( model depending )

  • Page 52: Operating The Product

    8. OPERATING THE PRODUCT he program duration may ding to the amount of dishes, perature, the ambient and selected additional 18" he energy-usage label is “Regular” program. This 1. Display e most efficient in terms of its 1. Display ergy and water consumption at 2.

  • Page 53: Options Key

    OPERATION KEYS ON/OFF KEY This key is used as On/Off key if the corresponding button is held down for 3 seconds. Otherwise, it can be used as Start/Pause key. It is used to turn on or turn off the dishwasher. Dishwasher will turn on with Regular program and the number and the duration of the regular program will appear on the display.

  • Page 54: Program Selection

    PROGRAM SELECTION Press the On/Off key to turn on the dishwasher. Note that the door of the dishwasher is OPEN position. 2. Refer to the “Programs Table” to determine a washing program suitable for the dishes. 3. Press program selection key until the number of the program selected appears on the display.
  • Page 55 Programs Duration Descriptions (min) Regular Dirty Standard program for daily, regular or typical use to completely wash a load of normally soiled dishes. Clean Auto Dirty This program automatically adjusts the temperature and the quantity of water, the energy consumption and the program duration.
  • Page 56 Intensive Plus Intensive Plus Suitable for heavily soiled dishes that are kept waiting. Intensive Plus Suitable for heavily soiled dishes that are kept waiting. Intensive Plus Suitable for heavily soiled dishes that are Suitable for heavily soi Auto Auto Auto Auto Clean Clean...

  • Page 57: Auxiliary Functions

    OPERATION AUXILIARY FUNCTIONS The dishwasher's washing programs are designed to give the best cleaning effect, based on the type of the soil, soiling degree, and properties of the dishes to be washed. Auxiliary functions are provided in order to save time, water, and energy and to perform a more comfortable washing with conditions specific to every customer.
  • Page 58 SANITIZE OPTION Sanitize function raises the water temperature in the final rinse. • At the end of a successful sanitization, “00” is displayed on the display. HI-TEMP OPTION When this option is selected, both the water temperature and the washing time are increased.

  • Page 59: Programming The Washing Time

    OPERATION PROGRAMMING THE WASHING TIME Delay Timer If an economical electricity tariff is applied in the region, use the Delay Timer function to wash dishes during appropriate hours. The start of the selected program can be delayed until 19 hours. Delay Timer cannot be set after the program starts. Press the Delay Timer function key after selecting the washing program and other auxiliary functions.

  • Page 60: Starting The Program

    TO CANCEL THE DELAY TIMER FUNCTION Open the door of the dishwasher. 2. Press and hold Delay Timer key for 3 seconds. 3. At the end of 3 seconds, delaying process will be canceled. • If the program is changed, the delay timer is canceled. •...

  • Page 61: Rinse Aid Indicator

    OPERATION SALT INDICATOR Please check the salt indicator on the control panel to see whether there is adequate amount of softening salt in the dishwasher or not. Refill the salt reservoir with salt whenever salt warning indicator appears on the control panel of the dishwasher. RINSE AID INDICATOR Please check the rinse aid indicator on the control panel to see whether there is adequate amount of rinse aid in the dishwasher or not.

  • Page 62: Maintenance And Cleaning

    MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING WARNING : Before cleaning or carrying out maintenance, switch off the appliance, disconnect the main plug and turn off the water tap. WARNING The dishwasher can only be repaired by an authorized service agent. Do not try to repair the dishwasher unless any recommendation by this manual.

  • Page 63: Spray Arms

    MAINTENANCE AND CLEANING • Filters: • Check if any food wastes have remained on the coarse and fine filters. ENANCE AND CLEANING Filter If any food wastes are left, remove the filters and clean them a. Micro Filter b. Coarse Filter thoroughly under the water tap.

  • Page 64: Cleaning The Impellers

    MAINTENANCE AND CLEANING CLEANING THE IMPELLERS Clean the impellers at least once a week in order for the dishwasher operates 9.2. Cleaning The Impellers UPPER IMPELLER efficiently. Check if the holes on the uppe Clean the impellers at least once a week in order for the machine operates efficiently.
  • Page 65 MAINTENANCE AND CLEANING g The Impellers UPPER IMPELLER Upper Impeller Check if the holes on the upper impeller ellers at least once a week in Check if the holes on the upper impeller (1) are clogged. If they are clogged, remove achine operates efficiently.

  • Page 66: Troubleshooting

    TROUBLESHOOTING ZLINE Customer Service is available at 1-614-777-5004. POSSIBLE FAULT POSSIBLE FAULT WHAT TO DO Water inlet system failure Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of the hose.
  • Page 67 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING The screen does not come The breaker is not in the on Switch the breaker to the on position. position. The supply cord is not Plug in the supply cord. plugged in. The program does not start. Your dishwasher is not Plug your dishwasher in plugged in...
  • Page 68 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Shaking and hitting The spray arm is hitting the Move or remove items noises are heard during a dishes in the lower basket. blocking the spray arm. wash operation. Partial food wastes Dishes placed incorrectly, Do not overload baskets.
  • Page 72 Installation Guide and User Manual 1.3.1 1-614-777-5004 contact@zlinekitchen.com www.zlinekitchen.com...
