- Page 1 Installation Manual CLASSIC DISHWASHERS DW7713 AND DW7714 MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..... . 1 BEFORE INSTALLATION ........4 Water Connection . -
Page 5: Important Safety Instructions
It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating the dishwasher. ZLINE is not liable for damages resulting from improper use or installation. - Page 6 • The dishwasher must be properly grounded or it can result in a risk of electric shock. A permanent electrical connection is allowed. • Do not operate the appliance if it’s damaged, malfunctioning, partially disassembled, or has missing or broken parts. If the unit arrives damaged, contact ZLINE at 1-614-777-5004 for help. BASIC PRECAUTIONS BEFORE USE •...
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • To reduce the risk of injury, do not allow children to play in or on a dishwasher. Keep young children and pets away from the dishwasher when it is operating. Do not let children abuse, sit, or stand on the door or racks of the dishwasher. •...
-
Page 8: Before Installation
BEFORE INSTALLATION ELECTRICAL GROUNDING INSTRUCTIONS • As with all equipment using electricity, water, and moving parts, potential hazards exist. To safely operate this appliance, become familiar with its operation and exercise care when using it. • The dishwasher must be properly grounded. Never connect it to an ungrounded outlet. Prior to removal of the original dishwasher and the installation of your new unit, make sure to switch off your circuit breaker. -
Page 9: Water Connection
BEFORE INSTALLATION • In addition to these instructions, the dishwasher shall be installed in accordance with all local codes, or in absence of a local code: • In the United States, with the National Electric Code ANSI/NPA70- latest edition. • In Canada, with the Canadian Electric Code C22.1-latest edition/ Provincial and Municipal codes and/or local codes. -
Page 10: Product Dimensions
•600 mm W x 549 mm D x 822 mm (min) - 867 mm (max) H PRE-INSTALLATION NOTES: • When installing a ZLINE door panel (see instructions on page 23), the depth of each unit increases to 22 1/4" (565 mm). The depth of each unit including the panel and handle is roughly 24"... - Page 11 • NOTE: Since kitchen layouts vary, ZLINE recommends consulting with a professional installer to verify cabinet dimensions before installing the appliance.
-
Page 12: Installation
• Power cable braided line recommended) • Teflon tape or sealing compound • 90° Elbow (3/8 MIP x 3/8 Compression) • Dishwasher panel (sold separately by ZLINE • Tube fittings or custom type supplied by customer) TOOLS REQUIRED (NOT PROVIDED) •... - Page 13 INSTALLATION Step 2: Select the Best Location for the Dishwasher The following criteria are important to ensure the best location for the dishwasher: • The location must have a solid floor that is able to support the weight of the dishwasher. •...
-
Page 14: Water Supply
INSTALLATION Step 3: Check Water Supply Requirements and Cautions • The hot water supply line pressure must be between 20 PSI and 145 PSI. • Adjust the water heater to deliver water between 120 °F–149 °F (49 °C–65 °C). • This temperature range provides the best washing result with the shortest cycle time. Temperatures also should not exceed 149 °F (65 °C) to prevent damage to dishes. - Page 15 INSTALLATION Step 4: Check the Electrical Requirements and Cautions The electrical requirements for the dishwasher are as follows: • In the United States, install in accordance with the National Electric Code/State and Municipal codes and/or local codes. • For cable direct connections. •...
- Page 16 INSTALLATION Step 5: Unpacking and Inspecting the Dishwasher Unbox the dishwasher in an open area free of obstruction both around the carton and overhead. We recommend that you retain the carton and all of the packing materials until the dishwasher is fully installed and operational to ensure you have removed all the product’s components from the carton prior to disposal.
- Page 17 Parts Inspection: 1. Confirm you have all the parts listed in Step 1 (see page 8). NOTE: If the unit arrives damaged or if provided parts are missing, contact ZLINE Customer Service at 1-614-777-5004 for help.
- Page 18 INSTALLATION Step 6: Preparing the Dishwasher Ensure that the circuit breaker and water supply valve are turned off before proceeding with the following steps. 1. Before you move or lay down the dishwasher for installation, adjust the height of the legs so they are as short as possible.
-
Page 19: Water Line Connection
INSTALLATION Step 7: Placing the Dishwasher and Connecting the Hot Water Supply Line 1. Adjust the three leveling legs at the bottom of the dishwasher after measuring the height of the cabinet opening from under the countertop to the floor (see "Step 8: Leveling the Dishwasher"... - Page 20 INSTALLATION Step 8: Leveling the Dishwasher 1. Open the door and place the level against the top of the tub on the inside and check if the dishwasher is level. If it is not level, rotate the leveling legs at the bottom front of the dishwasher until the dishwasher is level.
-
Page 21: Securing The Dishwasher
INSTALLATION Step 9: Securing the Dishwasher • You must secure the dishwasher to the countertop or cabinet side walls for additional stability. • If the countertop is made of wood or a material that will not be damaged by drilling, follow the instructions in Option 1 below. - Page 22 INSTALLATION Step 9: Securing the Dishwasher, Option 2, Continued Next, put the installation bracket into the slot of the side plane and tighten to the dishwasher with screw ST3.5*9. Then, insert the provided screws into the holes and tighten to secure the dishwasher to the cabinet.
-
Page 23: Connecting The Drain Hose
INSTALLATION Step 10: Connecting the Drain Hose 1. Check the parts on the sink where the drain hose will be connected. 2. There are several ways to insert the drain hose into the drain hose connector of the sink, as shown in Figure 1 1 below. You must connect the drain hose in accordance with the drain pipe installation regulations in your region. - Page 24 INSTALLATION 6. When drilling a hole for the drain hose on the cabinet wall, use care not to damage the hose by sharp edges of the hole. On wooden walls, use sand paper to soften the edges. On metal walls, use insulation tape or duct tape to cover the sharp edges around the hole. 7.
- Page 25 INSTALLATION Step 1 1: Electrical Wiring Connections 1. Before connecting the power cable to the dishwasher, make sure the circuit breaker is completely turned off. 2. In the junction box located at the front bottom right of the dishwasher, find the three power wires from the dishwasher, including the green grounding line (Figure 15).
-
Page 26: Kick Plate And Final Steps
• Refer to the Troubleshooting section of the User Manual to address any error codes. If problems persist, contact ZLINE Customer Service at 1-614-777-5004 for help. Figure 17... - Page 27 13. Adjust the tension of the door spring. • The door springs are set at the factory to the proper tension of a field installed ZLINE panel. If a custom panel is installed, you will have to adjust the door spring tension.
-
Page 28: Warranty
ZLINE Kitchen and Bath (“ZLINE”) dishwashers have a one year parts and service warranty. ZLINE warranty periods begin from the original purchase date of the product and solely cover the original purchaser of the product, delivered new and in its original carton. The limited warranty covers all parts and labor for necessary repairs if any part of the product, or the product itself, proves to be defective in materials or workmanship. - Page 29 ZLINE reserves the right to offer to replace the defective part or the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
- Page 30 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
- Page 31 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Scan the QR code to view the most up-to-date version of our Installation Manual and User Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
- Page 32 2.1.2 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
