- Page 1 Dock Bundle Maintenance Manual v1.0 2023.07...
- Page 2 Users should only refer to this document and the content thereof as instructions to operate DJI UAV. The document should not be used for other purposes.
-
Page 3: Table Of Contents
Lower Compartment Inspection Lower Compartment Assembly External Circulating Fan External Circulating Vents Lower Compartment Drain Emergency Stop Button Inspection Aircraft Maintenance Aircraft Body Inspection Propulsion System Frame Arms Motors Propellers and Propeller Adapters Landing Gear Gimbal Camera © 2023 DJI All Rights Reserved... - Page 4 DJI Matrice 30 Series Dock Bundle Maintenance Manual Infrared Sensing and Vision Systems, Auxiliary Lights, and Beacons Aircraft Ports Checklist Before Leaving Intelligent Flight Battery Battery Maintenance Battery Replacement Standard Battery Disposal Battery Usage Warnings List of Wearing Parts Wearing Parts of the Dock...
-
Page 5: Introduction
Failure to read and follow instructions and warnings may result in serious injury to yourself or others, damage to your DJI product, or damage to other objects in the vicinity. By using this product, you hereby signify that you have read this disclaimer carefully and that you understand and agree to abide by all terms and conditions of this document and all relevant documents of this product. -
Page 6: Safety Guidelines
Before conducting on-site maintenance, make sure that there is no flight plan to be executed on DJI FlightHub 2 and that the aircraft has landed inside the dock. Make sure to press the emergency stop button on the dock before any operations. When using the DJI RC Plus remote controller for on site testing, make sure to connect the remote controller to the dock before releasing the emergency stop buttons. -
Page 7: Recommended Maintenance Interval
[2] Per half year / Per year / Per three years expresses the device activation time. • DJI Enterprise may adjust the above maintenance services accordingly in different areas. Please contact authorized dealers or DJI Support for the latest information. -
Page 8: Maintenance Tool List
DJI Matrice 30 Series Dock Bundle Maintenance Manual Maintenance Tool List Adjustable Wrench Screws and Tools Triangular Key DJI RC Plus Remote Controller PH0 2.5 mm 2 mm 3 mm USB-C Cable Dust Blower Soft Brush Stiff Brush Water Container Dry Cloth ©... -
Page 9: Dock Maintenance
1. Clean the dock shell with a soft, dry cloth and make sure the dock shell is clear of dirt or foreign matter. 2. If there is any noticable damage or deformation, contact a DJI authorized service provider in time. -
Page 10: Electrical Cabinet Inspection
DJI Matrice 30 Series Dock Bundle Maintenance Manual Electrical Cabinet Inspection 1. Open the electrical cabinet door using the triangular key. 2. Check the SPD trip indicator. Contact an authorized service provider to replace and repair the SPD if the indicator turns red. - Page 11 Dock Cover Drag Chain Tension Spring • If any of the mentioned parts are broken or damaged, contact a DJI authorized service provider to replace them. • The dock cover propeller bumpers and the tension springs are wearing parts. Contact a DJI authorized service provider and replace them in time when necessary.
-
Page 12: Wind Speed Gauge Module And Rainfall Gauge
Gently rotate the wind cups and check if DJI Pilot 2 displays data. b. Gently tap the surface of the rainfall gauge and check if DJI Pilot 2 displays data. c. Tap Open or Close in the app to test if the dock cover can oparate normally. -
Page 13: Landing Pad Inspection
6. Connect the remote controller to the dock, run DJI Pilot 2, and test if the driving rods can move normally. -
Page 14: The Back Of The Landing Pad
DJI Matrice 30 Series Dock Bundle Maintenance Manual The Back of the Landing Pad 1. Use the triangular key to loosen the two bolts on the landing pad, hold the landing pad edge to lift it up. Make sure the support prop rod is stably holding the landing pad. -
Page 15: External Circulating Fan
DJI Matrice 30 Series Dock Bundle Maintenance Manual 1. Drive Shaft 2. Dock Cover Motor 3. Motor Driver 4. Main Controller Module 5. Return Vent 6. Supply Vent 7. Air Conditioning Controller 8. Position Sensor 9. Magnetic Ring External Circulating Fan •... -
Page 16: External Circulating Vents
DJI Matrice 30 Series Dock Bundle Maintenance Manual External Circulating Vents 1. Power on the dock. Press and hold the manual release button, then lift and rotate the dock cover arms to open the cover half way. 2. Power off the dock, use the triangular key to loosen the two bolts on the landing pad, lift the landing pad and open the lower compartment. -
Page 17: Lower Compartment Drain
Lower the landing pad and close the lower compartment. Power on the dock, connect the remote controller to the dock, run DJI Pilot 2, open Dock Onsite Debugging page, and tap Cooling or Heating. Check if there is cool air or hot air from the supply vent to test the air conditioning system. -
Page 18: Aircraft Maintenance
DJI Matrice 30 Series Dock Bundle Maintenance Manual Aircraft Maintenance Aircraft Body Inspection Visual Inspection for the Aircraft 1. Make sure the aircraft body is clean and not damaged. 2. Clean the aircraft body with a soft, dry cloth, especially when cleaning the lenses of the infrared sensing and vision systems and the heat dissipation vents. -
Page 19: Propulsion System
DJI Matrice 30 Series Dock Bundle Maintenance Manual Propulsion System Frame Arms Folding Frame Arms 1. Make sure the 12 screws on the four frame arms are firmly secured. 2. Make sure the screw nuts attached on the shaft screws are firmly secured when rotating the frame arms. -
Page 20: Motors
DJI Matrice 30 Series Dock Bundle Maintenance Manual Motors Motor Rotation 1. Unfold and lock the frame arms. 2. Rotate the motor to check if there is any blockage or rubbing. Observe the gap between the rotor and stator of the motor to check if there is any contact with the motor base. -
Page 21: Propellers And Propeller Adapters
4. Replace the propeller adapters if they are deformed or damaged. [1] The propellers need to be replaced in pairs. Make sure to use screw glue (recommended model: 243) when replacing the propellers. It is recommended to contact a DJI authorized service provider for propeller replacement. -
Page 22: Landing Gear
DJI Matrice 30 Series Dock Bundle Maintenance Manual Landing Gear 1. Make sure the landing gears are not cracked or damaged, and the landing gear pads are not worn. 2. Make sure the charging connectors are clean and not damaged. Clean them using a soft, dry cloth. -
Page 23: Infrared Sensing And Vision Systems, Auxiliary Lights, And Beacons
DJI Matrice 30 Series Dock Bundle Maintenance Manual Infrared Sensing and Vision Systems, Auxiliary Lights, and Beacons 1. Clean the lenses with a soft, dry cloth. 2. Make sure the lenses are not loose or cracked. 3. Make sure the auxiliary lights and beacons are not loose or cracked. -
Page 24: Aircraft Ports
DJI Matrice 30 Series Dock Bundle Maintenance Manual Aircraft Ports Battery Compartment 1. Check if the battery ports are clean and dry without any corrosion. Make sure to clean any water and dust with a soft, dry cloth. 2. Make sure the screws on the battery release toggles are firmly secured. -
Page 25: Checklist Before Leaving
DJI Matrice 30 Series Dock Bundle Maintenance Manual Rubber Port Covers Make sure the rubber port covers are not damaged or loose, and are properly sealed. microSD Card slot 1. Check if there are any foreign objects in the microSD card slot, and if the microSD card can be correctly installed and removed. -
Page 26: Intelligent Flight Battery
The Intelligent Flight Battery will conduct an intelligent self-evaluation when it is used with the dock. A prompt will appear in DJI FlightHub 2 when battery capacity calibration or battery maintenance is required. Open the DJI FlightHub 2 Devices page, Click Dock >... -
Page 27: List Of Wearing Parts
DJI Matrice 30 Series Dock Bundle Maintenance Manual List of Wearing Parts Replace parts that are easily damaged and worn in time to keep the dock and the aircraft in good condition and reduce flight safety risks. Wearing Parts of the Dock... -
Page 28: Dji Maintenance Program
DJI Matrice 30 Series Dock Bundle Maintenance Manual DJI Maintenance Program Users can check the DJI Maintenance Program using DJI FlightHub 2 or DJI Pilot 2. DJI FlightHub 2 1. Open DJI FlightHub 2, click Devices > Dock > , and enable Remote Debugging. - Page 29 DJI Matrice 30 Series Dock Bundle Maintenance Manual Flights Flight Distance © 2023 DJI All Rights Reserved...
-
Page 30: Dji Pilot 2
1. Connect the remote controller to the dock to enter the Onsite Debugging page. USB-C Pilot 2 App 2. Tap DJI Maintenance Program to view device data, maintenance records, and maintenance details of the dock and the aircraft to help users determine if maintenance is required. ©... - Page 31 DJI Matrice 30 Series Dock Bundle Maintenance Manual 3. After completing standard maintenance for the dock, connect the DJI RC Plus remote controller to the dock and reset the standard maintenance count. Tap to reset the standard maintenance count. D J I M a i n t e n a n c e P r o g r a m D J I C a r e E n t e r p r i s D o c k D a t a S N ：...
-
Page 32: After-Sales Service
DJI Matrice 30 Series Dock Bundle Maintenance Manual After-Sales Service Visit https://www.dji.com/service/policy to view product warranty period and warranty policy. © 2023 DJI All Rights Reserved... - Page 33 This content is subject to change without prior notice. Download the latest version from https://www.dji.com/dock/downloads If you have any questions about this document, contact DJI by sending a message to DocSupport@dji.com. DJI and MATRICE are trademarks of DJI Copyright © 2023 DJI All Rights Reserved.
