- Page 1 Installation Instructions / Warranty Talis S Allegro E 06857XX0 14801XX1 Talis C Talis S 04217XX0 04287XX0...
- Page 2 Talis S 06857XX0 Allegro E 14801XX1...
- Page 3 Talis C 04217XX0 Talis S 04287XX0...
-
Page 4: Installation Considerations
Technical Information / Données techniques / Datos tecnicos Recommended water Pression d’eau recommandée Presión recomendada 15 - 75 psi pressure en servicio Max. water pressure Pression d’eau maximum Presión en servicio max. 145 psi Recommended hot Température recommandée Temperatura recomen- 120�... -
Page 5: Consideraciones Para La Instalación
À prendre en considération pour l’installation • Pour de meilleurs résultats, Hansgrohe re- • Conservez ce livret et le reçu (ou une autre commande que ce produit soit installé par un preuve sur laquelle figurent la date et l’endroit plombier professionnel licencié. de l’achat) pour ce produit dans un endroit sûr. - Page 6 English 06857XX0, 04217XX0, 04237XX0 Installation Place the faucet and sealing washer on the mounting surface. 06857XX0, 04217XX0 If the mounting surface is less than 1⅜", install the plastic washer, fiber washer, friction washer, and mounting nut. If the mounting surface is greater than 1⅜", (1¾" for 04237XX0) or if there is insufficient space, omit the plastic washer.
- Page 7 Français Español Installation du robinet Instalación del grifo 06857XX0, 04217XX0, 06857XX0, 04217XX0, 04237XX0 04237XX0 Placez l’anneau d’étanchéité et le robinet sur la Coloque el aro de sellado y el grifo sobre la surface de montage. superficie de montaje. Installez la rondelle de plastique, la rondelle en fi- Instale la arandela plástica, la arandela de fibra, bre, la rondelle de friction et l’écrou de montage.
- Page 8 English 14801XX1 Installation Position the faucet and sealing ring on the mount- ing surface. Install the fiber washer, metal washer, and mount- ing nut. Tighten the tensioning screws. Install the hot and cold supply hoses on the stops. Use two wrenches, as shown, to prevent the hoses from twisting and becoming loosened from the faucet.
- Page 9 Français Español Installation du robinet Instalación del grifo 14801XX1 14801XX1 Coloque el aro de sellado y el grifo sobre la superficie de montaje. Placez l’anneau d’étanchéité et le robinet sur la surface de montage. Instale la arandela de fibra, la arandela de fric- ción y la tuerca de fijación.
- Page 10 Replacement Parts / Pièces détachées / Repuestos 88744XX0 97662000 96338000 92646000 97558000 95008000 96059000 06985XX0 96468XX0 96461000 92730000 96338000 92646000 97523000 97558000 96059000 95049000 95008000 97662000 96468XX0 96461000 14099001 92730000 Talis S 06857XX0 94071001 97523000 xx = colors / couleurs / acabados 95049000 00 = chrome 62 = oil rub bronze...
- Page 11 88744XX0 96338000 92646000 95560XX0 97662000 96059000 95498XX0 95008000 97209000 97558000 96521XX0 92730000 96455XX0 97662000 98597XX1 97558000 92646000 95008000 97523000 96059000 96468XX0 95049000 96461000 92730000 14099001 Talis S 04287XX0 95049000 94071001 Allegro E 14801XX1...
- Page 12 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 13 Nettoyez vos produits de robinetterie et de douche aussi souvent que nécessaire. • Utilisez la quantité de produit nettoyant et respectez la durée recommandée par le fabricant. Ne laissez pas le produit sur les articles de robinetterie plus longtemps que nécessaire. •...
-
Page 14: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. - Page 15 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
- Page 16 Hansgrohe, Inc. • 10 Bluegrass Lakes Parkway • Alpharetta, GA 000 Tel. 0-0-0 • Fax 0-0- www.hansgrohe-usa.com...
