INPUT MENU
INPUT SIGNAL INFORMATION
CURRENT INPUT
RESOLUTION
FREQUENCY
COLOR FORMAT
HDR EOTF
COLOR DEPTH
(SIGNAL/DISPLAY)
HDCP
VIDEO RANGE
VIDEO ID CODE
OVERSCAN
ADVANCED
INPUT SIGNAL SETTINGS
DisplayPort
DisplayPort1, DisplayPort2,
OPTION (DisplayPort)* inputs only
2
DisplayPort VERSION
HDCP VERSION
HDR
EQUALIZER
DSC
DisplayPort1 input only
Shows input signal information.
These functions shows their current settings in the [INPUT SIGNAL INFORMATION] for the selected input
signal.
NOTE: The functions listed here do not have settings for all input terminals available.


Configure settings specific to the video input terminal.
Select the DisplayPort input feature.
The following settings can be made according to the input selection.
DisplayPort1: 1.1a, 1.2, 1.4
DisplayPort2: 1.1a, 1.2
OPTION (DisplayPort): 1.1a, 1.2
Select [SST] or [MST] when [1.2] or [1.4] is set.
NOTE: • When receiving an 8K signal, select [1.4] for [DisplayPort1].



• [MST] is available on the DisplayPort1 input terminal only.

• [1.4] is available on the DisplayPort1 input terminal only.

• If [1.4] is selected, the following restrictions are applied:

- Deactivates [MULTI PICTURE], [MOTION] in [SCREEN SAVER], STILL, POINT ZOOM,
[IMAGE FLIP], [QUICK INPUT CHANGE], [DUAL DAISY CHAIN MODE], [AUDIO INPUT],
[ROTATE], [TILE COMP], [TILE CUT] and [DP to HDMI CONVERT].

- [H MONITORS] and [V MONITORS] in [TILE MATRIX] is up to [2].
Depending on the selection in the [DisplayPort VERSION], set items as below.
1.2: HDCP 1.3, HDCP 2.2
1.4: HDCP 1.3, HDCP 2.2
NOTE: When [DisplayPort VERSION] is set [1.1a], this function set [HDCP1.3] automatically.


Depending on the selection in the [DisplayPort VERSION], set items as below.
1.2: ENABLE, DISABLE
1.4: ENABLE, DISABLE
NOTE: When [DisplayPort VERSION] is set [1.1a], this function is disabled.


Compensates the video signal for better image stability.
If the image flashes or picture noise occurs, please change the setting.
Enables displaying compressed images. (DSC is an abbreviation of Display Stream Compression).
- Input signal 8K 60 Hz SST connection. (4 monitors in a multi-monitor daisy-chain setup (including this
monitor)).
- Input signal 4K 60 Hz MST connection.
NOTE: • DSC is only available when [DisplayPort VERSION] is set to [1.4]. Note that version 1.4 is only


available on the DisplayPort1 input.

• For signals compressed by DSC, the input signal is output as-is.
