- Page 1 User’s Manual by Thor’s Drone World...
- Page 2 Content A. LifThor RC PRO Utility Mount B. 2 x thumb screws M4 C. ¼”-20 Knob screw D. Hex Key & Wrench E. HDMI – Mini HDMI 4K High Speed cable (30cms) F. Adjustable Quick Release StrapThor Lanyard G. LifThor protection / carrying bag...
-
Page 3: How To Mount
How to mount: Unscrew the back of the mount and remove the back piece of the mount as shown. front back... - Page 4 Align the controller with the mount’s front plate to get access to the controller’s mounting points.
- Page 5 Secure the controller in place with the (2x)M4 thumb screws provided. We recommend to place both screws before tightening them to maintain the alignment.
- Page 6 Apply pressure with your thumb to secure the lower frame to install the back of the mount, make sure the mount is properly aligned and has a tight grasp of the controller. It’s recommended to extend the RC’s antennas for better access.
- Page 7 Without releasing the pressure of your fingers. Secure the mount in place with the wing bolt provided. – Congratulations! You have successfully mounted your LifThor RC PRO utility mount. wing bolt...
- Page 8 Set up the StrapThor Lanyard Unplug the Quick Release adapter from the lanyard by pressing firmly on the sides.
- Page 9 Loop the string through the LifThor SC PRO utility mount and pull to secure, reconnect it to the lanyard. Utility mount...
- Page 10 Care for a more adjustable & extremely balance lanyard system, then check out our LifThor KRAKEN upgrade for RC PRO...
- Page 11 How to mount an additional monitor (or any other utility / device) Slightly screw the ¼”-20 knob to the monitor (or any other utility) and slide it from the back through the opening of the utility mount, once in place secure the knob screw.
- Page 12 To fix the angle of the monitor use the provided hex key & wrench to adjust accordingly to your needs.
- Page 13 The LifThor RC PRO is equipped with a built-in mounting point located on the bottom of the unit to mount it to a tripod.
- Page 15 Use the LifThor bag to store your DJI Smart Controller & LifThor Pro...
- Page 16 www.lifthor.com...
