- Page 1 by Thor’s Drone World User’s Manual...
- Page 2 Congratulations on your new the Ultimate Tablet holder for DJI Mavic AIR 2...
- Page 3 Content: Tablet clamp Compatible with 7.9” up to 13” devices Ball joint plate Thumb screws (x4) Aluminum body...
- Page 4 How to assemble: Remove the 4 thumbs screws completely from the ball joint plate.
- Page 5 Remove completely the ball joint plate from the main body to mount the RC *Note: The body has pre-installed anti-slip pads to protect the RC from any scratches and keep it secure in place.
- Page 6 Prepare the RC by extracting the antenna all the way out...
- Page 7 Gently lower the RC into the bay of the base with a slight inclination. Aligning the RC center to the mount...
- Page 8 Place the ball joint plate back in place, and first screw the two back thumb screws loosely to hinge the plate in place before aligning the RC...
- Page 9 Once everything is in place, pressure the ball joint plate against the RC to secure it in place, and proceed to screw the remaining two screws. There is no need to force the screw tight...
- Page 10 Finish screwing the two back screws. The RC is now securely mounted to the LifThor Baldur holder...
- Page 11 Unscrew the tightening ring from the back of the Tablet Clamp and place it on the ball joint tightening ring ...
- Page 12 Attach the clamp to the ball joint and screw the ring back to secure the clamp position / angle. tightening ring ...
- Page 13 The clamp has two mechanisms to ensure your tablet sit secure and in place. Ratchet part The first mechanism is to adjust the the ratchet part, to height adjust to the size of your tablet. We recommend setting it a little smaller Lock ...
- Page 14 Place the tablet in landscape mode by pulling the spring mechanism upwards and release it to secure the tablet in place. You can adjust the top clamp brackets, if needed, to avoid pressing on any buttons Spring mechanism *Scan the QR code with your phone for a video tutorial...
- Page 15 Compatible with most small tablets like iPad Mini or similar up to larger tablets like the iPad Pro 12.9” - and everything in between...
- Page 16 Alternative setups: Integrated tripod mounting point located underneath the main body...
- Page 18 www.lifthor.com...
