- Page 1 Tablet Holder for Autel Nano & Lite by Thor’s Drone World User’s Manual...
- Page 2 Content: Utility mount Aluminum body Tablet clamp Spare Screw Compatible with 7.9” up to 13” devices M3x10 (x2) washer wrench key Star knob thumbscrew Hex Key / Allen Key (1/4”-20x1/2”) (x2)
-
Page 3: How To Assemble
How to assemble: Aluminum body Utility mount M3x10 screws Using the provided small hex key remove the screws to dismount the top aluminum plate from the main body... - Page 4 Gently position the controller’s antenna though the opening of the aluminum body as shown.
- Page 5 Once the controller is in place align the utility mount’s plate and pre-screw all 4 screws back by hand.
- Page 6 When all 4 screws are in place procced to tightening it using the provided small hex key. *Note: The mount has an anti-slip pad to protect the RC from any scratches and keep it secure in place.
- Page 7 Place the washer in the star knob thumbscrew prior to mount the tablet clamp. Insert the star knob from below the utility mount through the small round hole to secure the tablet clamp...
- Page 8 Use the wrench key and big hex key provided to adjust the angle of the utility mount to your preferred position.
- Page 9 The clamp has two mechanisms to ensure Ratchet part your tablet sit secure and in place. to adjust the height The first mechanism is the Lock → ratchet part, to adjust to the size of your tablet. We recommend setting it a little smaller (1”...
- Page 10 Place the tablet Spring mechanism→ in landscape mode by pulling the spring mechanism upwards and *Scan the release it to QR code secure the tablet with your phone for a in place. You can video adjust the top tutorial clamp brackets, if needed, to avoid pressing on any buttons...
- Page 11 Compatible with most small tablets like 7.9” iPad Mini or similar up to larger tablets like the iPad Pro 12.9” Max. thickness 20mm...
- Page 12 Integrated tripod mounting point located underneath the main body...
-
Page 13: Separately Sold Accessories
Separately sold accessories: Quick Release mounting bracket ConnecThor Video Monitor Feed Cables Sun hoods... - Page 14 StrapThor Pro Body Tripod StrapThor Lanyard Universal Clamp for Smart Phone up to 12.9” Tablets...
