- Page 1 by Thor’s Drone World User’s Manual...
- Page 2 Congratulations on your new Tablet Holder for Parrot Anafi & Skydio 2...
- Page 3 Content: Fully assembled mount Universal Clamp * (2x) M4 x 10 steel thumb screws Star Knob thumbscrew Wrench Hex Key / Allen Key *Universal clamp: Compatible with smart phones and up to 12.9” tablets (expanding clip range 65mm - 230mm)
- Page 4 To assemble: Secure the pre-assemble mount in place by gently tightening the two thumb screws provided as shown in the picture.
- Page 5 Utility mount Loosen up the utility mount Mount the universal clamp using the hex key and wrench using the star knob through provided to adjust its angle. the utility mount.
- Page 6 Our LifThor universal clamp has two mechanisms to ensure your tablet sit secure and in place. Ratchet part to The first mechanism is adjust the height the ratchet part, it can be extended in 6 fixed Release steps (3 on the top / 3 button on the bottom) to adjust to the size of your...
- Page 7 Place the phone / tablet in landscape mode by pulling the spring mechanism upwards and release it to secure the device in place. * It’s the spring-loaded part that will hold your device in place ! Spring mechanism...
- Page 8 Compatible with most smart phones and tablets up to 12.9” Minimum expanding 6.5cm – Maximum expanding 23 cm...
- Page 9 Alternative setups: Integrated tripod mounting point located underneath the aluminum base *Quick release bracket sold separate...
- Page 10 *StrapThor Pro Lanyard sold separately...
- Page 11 www.lifthor.com support@lifthor.com...
