Digital Watchdog MEGApix Ai DWC-XSDE08Mi User Manual page 71

Set up - System Set up
Firmware Update
1
2
3
Version Information - It shows the current Firmware Version in the system.
1
Web Update - Select the Firmware file on your computer by clicking the [Select file] button.
2
Start F/W Update - Click this button to start the update. Progress of uploading will be displayed using
3
Progress Bar. An error message will be shown if you assign the wrong file name.
Warning:
1. Do not turn off the power to the camera during the firmware update. Interrupting the update may
cause the system to become unstable. Once the update is completed, the system will reboot
automatically.
2. Make sure to check the 'Notice' shown on the screen.
The camera will reboot and show the login window if the firmware update is completed successfully.
71
