Digital Watchdog MEGApix Ai DWC-XSDE08Mi User Manual page 51

Set up - Event Set up
Motion Detection Configuration
1
2
3
4
5
Motion Detection - It shows the Motion event status.
1
Event Alert Icon( ) appears if 'Motion Detection' is activated.
Area - Set the motion detected area. Click in the display window to draw the motion area.
2
You can set up to four areas.
Activation - Enable or Disable motion detection function.
3
Sensitivity - Define the sensitivity of motion detection.
4
If a high value is selected, it will detect very small motion, while it becomes relatively insensitive when a low
value is selected.
Click 'Apply' to save all settings.
5
Click 'Cancel' to return to the previous setting.
