Digital Watchdog MEGApix Ai DWC-XSDE08Mi User Manual page 40

Set up - Network Set up
FTP Settings
1
2
3
4
5
6
7
An FTP needs to be set up to transfer/save the image to the relevant sites through FTP.
General Setting - Enable or disable the FTP function.
1
FTP Server Address - Define FTP Server IP Address. If the IP Address form is incorrect, a message box will be
2
shown to try again.
FTP Upload Path - Define a path in the FTP server to store image. For the path name, English Alphabet,
3
numbers and special characters ( / ~ !@ $ ^ ( ) _ - { } [ ] ; , ) can be used.
FTP Port - Define the FTP Server Port. If the port is not appropriate, accessing FTP Server is impossible.
4
User ID - Define User ID to access the FTP Server. Fill out the correct User ID registered in the FTP Server.
5
Password - Define the password to access the FTP Server. Fill out the correct password registered in the FTP
6
Server.
Click 'Apply' to save all settings.
7
Refer to the above image for an example.
40
