Digital Watchdog MEGApix Ai DWC-XSDE08Mi User Manual page 44

Setup - Network Setup
RTSP Information
1
2
3
4
5
6
7
Target Stream - Select the stream you want to set.
1
Time out - Set, in seconds, the time limit fo the RTSP stream to disconnect. The RTSP time out is disabled by
2
default.
RTSP Options - Check the box to include audio and/or metadat with the RTSP stream.
3
QoS Setting - Set the quality of service to ensure data transfer performance. select from 0~255. The function is
4
disabled by default.
RTP Multicast - Check RTP Multicast Start/Stop. RTP multicast is disabled by default.
5
To activate RTP Multicast:
1. Click on the "Start" button to enable.
2. Enter an IP address, port for video streram control, and packet TTL information for the RTP Multicast.
3. Click 'Apply' to save all settings.
Users can set separate RTP mutlticasts for each stream.
Click 'Apply' to save all settings.
6
Click this button when completed setup each channels.
The table shows all active RTP settings.
7
