Web Viewer Screen -
Basic Screen
2
3
4
5
6
7
8
9
Web Viewer is optimized for Microsoft Edge and Google Chrome.
Live video display - This is the region for live video streaming from the camera.
1
Set up popup button - Open the setup page to set up details of the IP camera like Video, Network,
2
Events, System etc. See the section 'Setup.'
Live Buffering - Live video can be turned on and off. You can get a faster response when turning off the live
3
video than the network band's camera setting.
Arrow buttons - Using the Pan and Tilt of the camera, can move in 8 directions.
4
This function is only supported by PTZ cameras.
Focus - Adjust the camera's focus automatically based on the current view and conditions.
5
Calibrate - For cameras with a motorized zoom lens, use the calibration button to set the camera's lens
6
settings to the current view and conditions.
Zoom/Focus buttons - The camera's zoom can be controlled using the six buttons, with three levels of
7
movement. These allow users to adjust the camera's view for wide, tele, near and far movements. Clicking
the buttons ( ) move the lens more extensively than the buttons (
Auto Focus - When enabled, the camera will adjust its focus according to the current view and conditions after
8
each zoom adjustment.
MFZ lock/unlock - Lock the focus and zoom settings.
9
PTZ function - This dashboard allows users to control and activate the camera's home position or run any set
10
presets, tours or actions on supporting cameras.
This function is supported on PTZ cameras only.
10 12 11
17
13
).
1
14
15
