Dimensional Drawings; Wzsv 62(H)(K)3M - Wzsv 122(H)(K)3M - Alpha-InnoTec WZSV Series Operating Manual

Dimensional drawings

Keys: UK819447a Keys: UK819447a
All dimensions in mm.. All dimensions in mm..
A A Front view Front view
B B Side view from left Side view from left
C C Plan view Plan view
A1 A1 Front view of module box Front view of module box
C1 C1 Top view of module box Top view of module box
Subject to change without notice | 83056900kUK | ait-deutschland GmbH
WZSV 62(H)(K)3M – WZSV 122(H)(K)3M
Pos. Pos. Name Name
1 1 Heating water outlet (flow) Heating water outlet (flow)
2 2 Heat source inlet (in heat pump) Heat source inlet (in heat pump)
optionally at the top, on the right or left optionally at the top, on the right or left
3 3 Heating water inlet (return) Heating water inlet (return)
4 4 Heating circuit safety valve Heating circuit safety valve
(in the separate package) (in the separate package)
5 5 Heat source outlet (from heat pump) Heat source outlet (from heat pump)
optionally at top, right or left optionally at top, right or left
6 6 Domestic hot water charging circuit inlet (Return) Domestic hot water charging circuit inlet (Return)
7 7 Drinkwater warm Drinkwater warm
8 8 Drinkwater cold Drinkwater cold
Dim. Dim.
Ø 28 *) Ø 28 *)
Ø 28 *) Ø 28 *)
Ø 33 **) Ø 33 **)
Rp ¾" " internal thread Rp ¾ internal thread
Ø 28 *) Ø 28 *)
Ø 28 *) Ø 28 *)
R ¾" " external thread R ¾ external thread
R ¾ R ¾" " external thread external thread
*) outside diameter **) inside diameter *) outside diameter **) inside diameter
