Monosem MS Series Operator's Manual
  1. Manuals
  2. Brands
  3. Monosem Manuals
  4. Farm Equipment
  5. MS Series
  6. Operator's manual

Monosem MS Series Operator's Manual

Planters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS Series and is the answer not in the manual?

Questions and answers

teboho mokoaqo
March 5, 2025

which monosem planter is used to plant squash or pumpkin?

0
1 comments:
Mr. Anderson
May 14, 2025

The Monosem MS Series planter suitable for planting squash or pumpkin would use seed discs sized for large seeds. While squash or pumpkin are not specifically listed, similar-sized seeds like melon or cucumbers (1.8–2.0 mm hole size) use seed discs such as M1818 or M1820. Therefore, a planter equipped with M1818 or M1820 seed discs would be suitable for planting squash or pumpkin.

This answer is automatically generated

0
lubambe ntalasha
January 29, 2025

Hi. Can the MS series plant onion and rice?

User image 679a75529cbfe
0
1 comments:
Mr. Anderson
February 10, 2025

The Monosem MS Series can plant onions, as the seed disc chart includes options for onions in different forms (encrusted, pelleted, and raw) with corresponding seed discs. However, the chart does not mention rice, so it cannot be confirmed whether the Monosem MS Series can plant rice.

This answer is automatically generated

0

Related Manuals for Monosem MS Series

Summary of Contents for Monosem MS Series

  • Page 3 MS SERIES PLANTERS MOUNTED FRAMES (Serial No. 23A##### - OPERATOR’S GUIDE MS SERIES PLANTERS MOUNTED FRAMES OMM900007 ISSUE A1 2023 (ENGLISH) CALIFORNIA Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm.
  • Page 4 If you are not the original owner of this machine, it is in your interest to contact your local Monosem dealer to inform them of this unit's serial number. This will help Monosem notify you of any issues or product improvements.
  • Page 5 To achieve the maximum performance, it is imperative basis, Monosem Inc. reserves the right to change that this machine is operated in accordance with the specifications or designs without notice and without procedures outlined in this manual.
  • Page 6 Introduction PAGE INTENTIONALLY LEFT BLANK...
  • Page 7 Version A - Single row unit Row spacing from 8" (20cm) 1/2" spacing between lines MS Monosem planter unit MS Monosem planter unit version A (1) Metering box version D (2) Metering boxes / (2) agitators Clod remover w/agitator Clod remover Rubber front press wheel 12"x4 Rubber front press wheel (6 1/2”x 10”) Rear press wheel...

  • Page 8: Table Of Contents

    Contents Page Page Safety Hydraulic Connections Recommendations..20-4 Recognize Safety Information ......05-1 Check The Hydraulic System ......20-5 Understand Signal Words........05-1 Attach the Warning Light Harness......20-5 Park Machine Safely...........05-1 Warning Lights and Slow Moving Live With Safety..........05-2 Vehicle Emblem ..........20-6 Prevent Machine Runaway.........05-2 Leveling The Planter...........20-6 Handling Batteries Safely ........05-3 Detach from Tractor ...........20-7...
  • Page 9 Contents Page Options – Row Unit Attachments......50-9 Seed Metering System ........50-14 Meter Box Adjustments ........50-15 Seed Disc ............50-16 MS Seed Disc Chart .........50-18 OPTIONS MS Version A Sync Chart and Setting Instructions For Timing Non-Staggered Units........60-1 MS Version D Sync Chart and Setting Instructions For Timing Non-Staggered Units........60-3 MS Version M Sync Chart and...

  • Page 10: Safety

    Safety Recognize Safety Information This is a safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices. DX,ALERT -19-03OCT22-1/1 Understand Signal Words DANGER;...

  • Page 11: Live With Safety

    Safety Live With Safety Before returning machine to customer, make sure machine is functioning properly, especially the safety systems. Install all guards and shields. DX,LIVE -19-25SEP92-1/1 Prevent Machine Runaway Avoid possible injury or death from machinery runaway. Do not start engine by shorting across starter terminals. Machine will start in gear if normal circuitry is bypassed.

  • Page 12: Handling Batteries Safely

    Safety Handling Batteries Safely Battery gas can explode. Keep sparks and flames away from batteries. Use a flashlight to check battery electrolyte level. Never check battery charge by placing a metal object across the posts. Use a voltmeter or hydrometer. Always remove grounded (-) battery clamp first and replace grounded clamp last.

  • Page 13: Operate The Machine Safely

    Safety Operate the Machine Safely Be careful when operating machine to avoid injury. If the machine must be in a raised position while working on or near it, be certain service locks are installed or machine is adequately supported. Anytime hydraulic work must be done, lower the machine.

  • Page 14: Prepare For Emergencies

    Safety Prepare for Emergencies Be prepared if a fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance service, hospital, and fire department near your telephone. DX,FIRE2 -19-03MAR93-1/1 Wear Protective Clothing Wear close fitting clothing and safety equipment appropriate to the job.

  • Page 15: Handle Agricultural Chemicals Safely

    Safety Handle Agricultural Chemicals Safely Chemicals used in agricultural applications such as fungicides, herbicides, insecticides, pesticides, rodenticides, and fertilizers can be harmful to your health or the environment if not used carefully. Always follow all label directions for effective, safe, and legal use of agricultural chemicals.

  • Page 16: Follow Tire Recommendations

    Safety Follow Tire Recommendations Keep your machine in proper working order. Use only prescribed tire sizes with correct ratings and inflate to the pressure specified in this manual. Use of other than prescribed tires may decrease stability, affect steering, result in premature tire failure, or cause other durability or safety issues.

  • Page 17: Transport Safely

    Safety Transport Safely Avoid serious injury or death resulting from loss of control or rear end collision while transporting the planter and any load towed behind the planter. Always raise the parking stand before transport. Tractor brakes must be latched together. Attach a properly sized safety chain at each drawbar connection.

  • Page 18: Tow Loads Safely

    Safety Tow Loads Safely Stopping distance increases with speed and weight of towed loads, and on slopes. Towed loads with or without brakes that are too heavy for the tractor or are towed too fast can cause loss of control. Consider the total weight of the equipment and its load.

  • Page 19: Practice Safe Maintenance

    Safety Practice Safe Maintenance Understand service procedure before doing work. Keep area clean and dry. Never lubricate, service, or adjust machine while it is moving. Keep hands, feet, and clothing away from power-driven parts. Disengage all power and operate controls to relieve pressure. Lower equipment to the ground.

  • Page 20: Remove Paint Before Welding Or Heating

    Safety Remove Paint Before Welding or Heating Avoid potentially toxic fumes and dust. Hazardous fumes can be generated when paint is heated by welding, soldering, or using a torch. Remove paint before heating: • Remove paint a minimum of 100 mm (4 in.) from area to be affected by heating.

  • Page 21: Auxiliary Hydraulic Attachment Operation

    Safety Auxiliary Hydraulic Attachment Operation Remote hydraulic outlet at rear of planter for auxiliary hydraulic equipment operation. CAUTION: Escaping fluid under pressure penetrates the skin causing serious injury. Avoid the hazard by relieving pressure before disconnecting hydraulic or other lines. Tighten all connections before applying pressure.

  • Page 22: Following Operation

    Safety FOLLOWING OPERATION • When you stop operation of the planter, even if periodically, stop the tractor, set the tractor or towing vehicle brakes, disengage the PTO and all power drives, shut off the engine and remove the ignition key. HS35416,0000A76 -19-01JAN19-1/1 UNHOOKING THE PLANTER Lower the toolbar stands to support the planter.

  • Page 23: Performing Maintenance

    Safety PERFORMING MAINTENANCE Good maintenance is your responsibility. Make repairs in an area with plenty of ventilation. Never operate the engine of the towing vehicle in a closed building. The exhaust fumes may cause asphyxiation. As a precaution, always recheck the hardware on equipment following every 100 hours of operation.

  • Page 24: Preparing The Planter

    PREPARING THE PLANTER PREPARING THE PLANTER For the initial preparation of the planter, lubricate the planter and row units. Make sure that all tires are evenly inflated, that all drive chains have the proper tension, alignment and lubrication. CAUTION: Before starting up the planter, check that all main bolts are properly tightened and that planting units are equipped with the proper seed disc.

  • Page 25: Transporting The Planter

    PREPARING THE PLANTER DANGER Rim and tire servicing can be dangerous. Explosive separation of a tire and rim parts can cause serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experience to perform the job. Only properly trained and equipped people should do this job.

  • Page 26: Field Test

    PREPARING THE PLANTER • FIELD TEST Check that each metering unit is metering properly (see Row Unit section). Before the initial operation of the planter, a field test is • Check that the seed disc has the proper number of holes advised.

  • Page 27: Use Your Tractor Operator's Manual

    FRAME MOUNTED FRAMES Use Your Tractor Operator's Manual Always refer to your tractor operator's manual for specific detailed information regarding the operation of your equipment. The following tractor-related information uses John Deere™ tractors to illustrate preparation, attachment, and operational procedures. Use your tractor operator's manual for detailed information, as procedures vary by equipment.

  • Page 28: Planter Effective Weight

    FRAME MOUNTED FRAMES Planter Effective Weight !! Keep in mind that a tractor’s rated lift capacity may be what it can lift in the field, but is very likely not what it’s Normally a tractor's 3 pt. hitch lift capacity is rated with the rated to safely carry on the road.

  • Page 29: Case Drain And Hydraulic Motor Requirements

    FRAME MOUNTED FRAMES Case Drain and Hydraulic Motor Requirements IMPORTANT: Most planter hydraulic configurations utilize hydraulic motors equipped with case drain connections. To avoid damage to the hydraulic motors, connect the case drain hose to the tractor with a low-pressure drain coupler. Install the coupler in a port with less than 25 psi.

  • Page 30: Hydraulic Connections Recommendations

    FRAME MOUNTED FRAMES CAUTION: When the latch control levers (A) are properly locked, the handles are horizontal and against the hitch frame. 5. Raise the rockshaft enough to engage the planter hitch pins in the quick-hitch hooks. Push both latch control levers (A) down to lock the planter to the quick-hitch.

  • Page 31: Check The Hydraulic System

    FRAME MOUNTED FRAMES Check The Hydraulic System CAUTION: Escaping fluid under pressure can penetrate the skin and cause serious injury. Relieve the hydraulic pressure before disconnecting the hydraulic or other lines to avoid this hazard. Tighten all of the hydraulic connections before applying pressure. Search for leaks with a piece of cardboard.

  • Page 32: Warning Lights And Slow Moving Vehicle Emblem

    FRAME MOUNTED FRAMES Warning Lights and Slow Moving Vehicle Keep lights visible, clean, and in working order. Emblem Check local governmental regulations. Various safety When transporting the planter on a roadway, use flashing devices are available from your John Deere dealer or warning lights and turn signals day and night.

  • Page 33: Detach From Tractor

    FRAME MOUNTED FRAMES Detach from Tractor IMPORTANT: Top of parking stand (B) must extend out the top of support tube (C) for stability. 1. Lower parking stand (B) and fasten with pin (A). 2. Lower machine to ground. See tractor operator's manual.

  • Page 34: Support The Machine Before Service

    FRAME MOUNTED FRAMES Support The Machine Before Service CAUTION: Avoid crushing injury or death from falling machine. Ensure service locks are installed on all cylinders and machine is supported on blocks before performing any service or adjustments. 1. Raise the machine. 2.

  • Page 35: Remove From Storage

    FRAME MOUNTED FRAMES Remove from Storage IMPORTANT: Do not use a heavy petroleum base lubricant that causes a buildup of dust or Before using the machine after it has been stored, inspect dirt in the sprocket or gear teeth. the seed hoppers for cleanliness and verify that the seed passages are clear.

  • Page 36: Ms Planter Frame

    FRAME MOUNTED FRAMES MS Planter Frame Continued on next page ch177nn,1687511956725 -19-26JUN23-1/2 20-10 062623...
  • Page 37 FRAME MOUNTED FRAMES The MS planter frame consists of: (4) have an adjustment spindle allowing the operator to raise or lower the height of the gauge wheel block with • Toolbar (1) the length of which depends on the number ease.
  • Page 38 FRAME MOUNTED FRAMES PAGE INTENTIONALLY LEFT BLANK 20-12 062623...
  • Page 39 FRAME MOUNTED FRAMES MS TOOLBAR HITCH CAT 2 Free Link This hitch is generally used on planters 8 rows or less. MS TOOLBAR HITCH ch177nn,1687774352502 -19-26JUN23-1/1 5" x 5" Mounted Toolbars (Hitch Configurations) STANDARD TOOLBAR HITCH CAT 1, 2 Free Link If necessary, the lower mounting brackets of the standard hitch can be mounted as a counter clamp of the planting This hitch is generally used on planters 8 rows or less.
  • Page 40 FRAME MOUNTED FRAMES DOUBLE TOOLBAR HITCH The planter hitch of the double toolbar consists of two lower hitch brackets (right and left) and one upper mounting bracket. This tool bar works with CAT 2 & 3 Free Link, CAT 2, 3, 3N Quick Hitch.
  • Page 41 FRAME MOUNTED FRAMES COMBO TOOLBAR HITCH This hitch consists of two lower hitch brackets (left and right) and one upper bracket. This hitch is used with CAT 2 & 3 Free Link, and CAT 2, 3, 3N Quick Hitch. This hitch is generally used with two added spacer brackets for extra support on 8 row and larger planters.
  • Page 42 FRAME MOUNTED FRAMES 8R30 7 X 7 STACKING TOOLBAR WITH 5 X 5 OFFSET 8R30 7 X 7 STACKING TOOLBAR WITH 5 X 5 OFFSET This toolbar works with CAT 2 & 3 Free Link, and CAT 2, 3, 3N Quick Hitch. Continued on next page ch177nn,1687511353587 -19-23JUN23-6/7 20-16...

  • Page 43: Hex Shaft, Couplers, Bushing Stops

    FRAME MOUNTED FRAMES 5 X 5 STACKING TOOLBAR 5 X 5 STACKING TOOLBAR This toolbar works with CAT 2 & 3 Free Link. Hitch adapters are available for CAT 2, 3, 3N Quick Hitch compatibility. ch177nn,1687511353587 -19-23JUN23-7/7 Hex Shaft, Couplers, Bushing Stops Check that bushing stops are tight to prevent the hex shaft from moving side to side.

  • Page 44: Adjustable Wheel Blocks

    FRAME MOUNTED FRAMES Adjustable Wheel Blocks Tire Size Adjustable wheel blocks use the following tire and pressures: Tire size = 5.90” x 15” Pressure = (36 PSI) (248 kPa) Check tire pressure regularly. Incorrect tire pressure will affect target population. A periodic check of tire pressure is very important.
  • Page 45 FRAME MOUNTED FRAMES ADJUSTABLE DRIVE WHEEL Refer to Figure 1. A: To lower the drive wheel, turn the hand wheel (1) counterclockwise. B: To raise the drive wheel, turn the hand wheel (1) clockwise. The spring-loaded drive wheel adjustment assembly is intended to act as a “shock absorber”...

  • Page 46: Transmission

    (7). 13 gear combinations are possible. NOTE: More sprocket combinations may be available with custom orders. Please consult Monosem or your Monosem dealer in case you have such special requirements. To change sowing distance, first select the desired spacing from the following gearbox chart.
  • Page 47 NOTE: More sprocket combinations may be available with custom orders. Please consult Monosem or your Monosem dealer in case you have such special requirements. To change sowing distance, first select the desired spacing from the following gearbox chart. A decal placed on the planter will provide the same information for on-the-spot reference.

  • Page 48: Standard Sowing Distances Chart

    TRANSMISSION Standard Sowing distances chart The following planting distances were obtained with standard assembly and sprocket system. Additional settings are possible by using different combinations or special sprockets. Please consult us in case you have such special requirements. IMPORTANT: Poor alignment of the sprockets of the seed spacing gearbox and stiffness of the chain will cause premature side wear on the pinions.
  • Page 49 TRANSMISSION Standard Sowing distances chart Number of holes in seed disc Driver Driven inch 5 1/8 2 1/2 1 1/2 1 1/4 inch 5 5/8 3 3/8 2 3/4 1 5/8 1 3/8 inch 5 7/8 3 1/2 1 3/4 9/16 inch 6 7/8...

  • Page 50: End-Mounted Transmission

    TRANSMISSION End-Mounted Transmission The following planting distances were obtained with standard assembly and sprocket system. Additional settings are possible by using different combinations or special sprockets. Please consult us in case you have such special requirements. IMPORTANT: Poor alignment of the sprockets of the seed spacing gearbox and stiffness of the chain will cause premature side wear on the pinions.
  • Page 51 TRANSMISSION uuf6xgz,1682678134683 -19-11MAY23-2/2 30-6 062623...

  • Page 52: Extended Center Transmission

    TRANSMISSION Extended Center Transmission The following planting distances were obtained with standard assembly and sprocket system. Additional settings are possible by using different combinations or special sprockets. Please consult us in case you have such special requirements. IMPORTANT: Poor alignment of the sprockets of the seed spacing gearbox and stiffness of the chain will cause premature side wear on the pinions.
  • Page 53 TRANSMISSION Extended Center Transmission Number of holes in seed disc Driver Driven inch 1.75 0.25 inch 4.75 2.75 2.25 1.25 0.75 inch 1.25 0.75 12.6 5.75 inch 1.75 0.75 14.8 inch 3.75 1.75 15.4 inch 3.75 2.25 1.75 0.75 11.4 inch 4.75 2.25...

  • Page 54: Vacuum

    VACUUM Standard Turbofan standard with hydraulic drive. PTO options in 450, 540, or 1000 rpm are available. The standard turbofan has a plastic impeller blade and is used on smaller planters. The standard turbofan comes ch177nn,1687513044947 -19-23JUN23-1/1 High Output Turbofan used on medium sized planters.
  • Page 55 Refer to your tractor’s operators manual Monosem hydraulic drives are closed center systems. for further information. Contact your Monosem dealer if you tractor has an open You can control oil flow to the motor in one of three center hydraulic system.
  • Page 56 VACUUM HYDRAULIC SYSTEM SAFETY DANGER. Before applying pressure to the hydraulic system, check that all connections are tight and that the hoses and fittings have not been damaged. Hydraulic fluid escaping under pressure can penetrate the skin causing serious injury. If injured by escaping hydraulic fluid see a doctor at once.
  • Page 57 VACUUM Hydraulic Motor Case Drain High Output and Extra High Output (and some Standard) fan motors are equipped with a case drain port. The case drain is plumbed into the back end of the motor, opposite the output shaft. The case drain allows excess heat and pressure to escape the body of the motor.

  • Page 58: Vacuum Gauge Settings

    VACUUM Vacuum Gauge Settings All Monosem planters are equipped with a vacuum gauge that allows you to read the vacuum level of the turbofan. The vacuum level should be set depending on the weight and size of the seed to be planted. Planters with 2 turbofans may be equipped with 2 vacuum gauges.

  • Page 59: Secondary Air System

    VACUUM Secondary Air System ATTENTION: The secondary air manifold has 2 outlets. One is to be used to connect the air pressure tube. The other outlet remains open as standard, but may be plugged in order to increase vacuum pressure. A—Seed Collection C—Pressure Tube E—Keep one outlet fully open...

  • Page 60: Vacuum Seed Emptying System

    VACUUM Vacuum Seed Emptying System The seed collection container is mounted to the turbofan by means of a mounting bracket and is connected to one of the outlets of the manifold. To suck out the remaining seeds in each hopper and the seed meter, simply insert the flexible hose into the bottom of the hoppers and meter.

  • Page 61: Row Unit

    ROW UNIT Row Unit Versions are shown on the following pages with standard features. Other options are available for specific conditions or uses. There are 6 versions of the Mini Seed row unit available in single or twin line. Row Unit Version A, B, C, D, G, & M uuf6xgz,1685957802163 -19-05JUN23-1/1 Row Unit Version A Min.

  • Page 62: Row Unit Version B

    ROW UNIT Row Unit Version B Min. 5½" (14cm) spacing between units. This is a simplified planter unit without the intermediate press wheel. Standard features: • Front rubber press wheel (2”x 12”) • A concave cast iron press wheel w/ rubber tire •...

  • Page 63: Row Unit Version C

    ROW UNIT Row Unit Version C Min. 8" (20cm) spacing between units Twin line unit, 2”- 4” between seed lines in the row. Similar to Version. A, but is suited to planting double rows in well prepared soils (no clods or stones). Standard features: •...
  • Page 64 ROW UNIT The Version D unit consists of two offset metering boxes within one unit frame. This allows for one or two seed lines per metering box, for a combination of 2, 3, or 4 seed lines within one unit frame. Adjust the row spacing between the lines by loosening the set screws and sliding the metering boxes on hex shaft as needed.

  • Page 65: Row Unit Version G

    ROW UNIT Row Unit Version G Min. 8" (20cm) spacing between units. Standard features: • Screw type depth adjust. • Rear stainless steel press wheel (4”x 8”). • Narrow shoe with cast point and regular wings. • Intermediate hillers for closing the furrow. •...

  • Page 66: Row Unit Version M

    ROW UNIT Row Unit Version M For seed bed planting- multiple lines of narrow row spacing. Units are assembled within a fixed frame with standard front and rear painted steel rollers. This planter is ideal for high population crops requiring multiple lines of close spacing such as packaged lettuce, pine trees, carrots, etc.
  • Page 67 ROW UNIT Before starting planting, • Set the toolbar height to 16". This is the distance from the top of the bed to the bottom of the 5x5 toolbar. • Increase/decrease front roller weight to move the desired amount of soil. - The top handle on the linkage adjusts front roller weight.

  • Page 68: Main Adjustments Versions A, B, C, D

    ROW UNIT Main Adjustments Versions A, B, C, D A—Cage Wheel with Tire (other C—Down Pressure Intermediate F— Up Pressure Spring L— Rubber Front Press Wheel options available) Press Wheel G—Lock-up M—Shoe B—Intermediate Hillers Height D—Down Pressure Rear Wheel H—Wing Nut N—Intermediate Hillers and Pressure Adjustment Adjustment...

  • Page 69: Options - Row Unit Attachments

    ROW UNIT drive chains are spring loaded and therefore, self- When the spring is un-notched, the unit can be locked up adjusting. The only adjustment needed is to shorten the in a raised position. chain if wear stretches the chain and reduces spring tension.
  • Page 70 ROW UNIT 3. Stainless steel intermediate press wheel Version A & C ch177nn,1687517415920 -19-23JUN23-3/10 4. 6512 - Rear press wheel, rubber, 5-1/2" x 10" Version A & C 6612 - Rear press wheel, rubber, 6-1/2" x 10" Version D ch177nn,1687517415920 -19-23JUN23-4/10 5.
  • Page 71 ROW UNIT 6. 6600- Stainless steel press wheel, 4” x 10” Version A & C 642458- Stainless steel press wheel, 5½” x 10” Version C 6581.A- Stainless steel press wheel, 6½” x 10” Version ch177nn,1687517415920 -19-23JUN23-6/10 7. 100650- Adjustable split shoe right (standard) 100651- Adjustable split shoe left (standard) 100653- Adjustable split shoe right (wide) 100654- Adjustable split shoe left (wide)
  • Page 72 ROW UNIT 9. 6465.A- 1.5 L metal hopper 643508- 3 L plastic hopper with lid ch177nn,1687517415920 -19-23JUN23-9/10 10. 65030090- MS scatter shoe, 2.5” wide (67mm) 65009476- MS scatter shoe, 4” wide (100mm) *Optional intermediate press wheel shown. ch177nn,1687517415920 -19-23JUN23-10/10 50-12 062623...
  • Page 73 ROW UNIT PAGE INTENTIONALLY LEFT BLANK 50-13 062623...

  • Page 74: Seed Metering System

    ROW UNIT Seed Metering System Each version M unit is hung within a fixed frame with front rear stainless-steel rollers for seed bed planting. When Metering box for Versions A, B, and G planting in a single line, the same metering box as for Single row planting version A and B is used.

  • Page 75: Meter Box Adjustments

    ROW UNIT Meter Box Adjustments Main Adjustment The outside indicator lever on the meter box. The outside lever on the metering box adjusts the height of the scraper in relationship to the holes in the seed disc. The " 0 " position is recommended as a starting point because in most cases, it provides the best balance between skipping and doubling.

  • Page 76: Seed Disc

    ROW UNIT Secondary Adjustment Adjustable pins The adjustable pins activate a secondary scraper along the bottom of the seed disc holes for use with small raw seeds. An optional singulation method is available for small raw seeds (broccoli, carrots, cabbage) by using the 2 adjustable pins.
  • Page 77 ROW UNIT Seed Disc Recommendations Prefix M Indicates the seed plate has one row of holes, w/o agitator. Prefix 2M Indicates the seed plated has two rows of holes, w/o agitator. Prefix MC or 2MC Indicates seed plate is complete with agitator.

  • Page 78: Ms Seed Disc Chart

    ROW UNIT MS Seed Disc Chart Crop Hole Size (mm) Seed Disc Asparagus 1.8 - 2.0 M6020 , M12020 Beets M6020 Bok choy 0.8 - 1.0 M3612 , M7212 Broccoli M3612 , M6012 , M7212 M3612 , M6012 , M7212 Cabbage Cantaloupe 1.8 - 2.0...
  • Page 79 ROW UNIT Sugarbeets M4020 , M6020, M12020 Swiss chard M6022 , M7222 Tomatoes M7210 Turnips M7209 Water melons M0325 , M0625 , M0925 uuf6xgz,1683010916059 -19-02MAY23-2/2 50-19 062623...

  • Page 80: Options

    OPTIONS MS Version A Sync Chart and Setting Instructions For Timing Non-Staggered Units A—Indicator Tool #804060 B—See Inset Below D—Disc Adjusting Rod C—Offset Angle Timing Instructions number listed in the chart and zero for each subsequent meter. 1. Remove meter covers and install the timing indicator #804060 on the meter that is being timed.
  • Page 81 OPTIONS Meter number Timeable meter Offset angle *The table below shows an example of timing a group of 4 Likewise, meter 3 is set at zero to drop seed the same consecutive meters (meters are numbered starting at 1 on time as meter #1.

  • Page 82: Ms Version D Sync Chart And Setting Instructions For Timing Non-Staggered Units

    OPTIONS MS Version D Sync Chart and Setting Instructions For Timing Non-Staggered Units A—Calibration Tool #804060 D—3. Replace calibration tool with correct singulator , test with B—1. Remove all slack from chain drive system. Turn main hex seed in field and fine tune as required until hole center is aligned with end of singulator.
  • Page 83 OPTIONS (chart) distances from the owners manual and the actual Insure that the seed spacing you select is correct by planted distance due to soil type, planting speed, etc. If averaging the measured distance of several planted this does occur, use the measured seed spacing value. seeds.

  • Page 84: Ms Version M Sync Chart And Setting Instructions For Timing Non-Staggered Units

    OPTIONS MS Version M Sync Chart and Setting Instructions For Timing Non-Staggered Units Timeable Meter Timing Instructions 1. Install the timing indicator #804060 on the meter that is being timed. 2. Turn the main hex shaft until all the slack is removed from the drive chains and the center of a disc hole is aligned with the end of the singulator on the meter without the timing sprocket.
  • Page 85 OPTIONS MS Version M Sync Chart and Setting Instructions For Timing Non-Staggered Units Disc hole # Offset angle *The offset angle is half the angle between the seed 4 will require the same drop time so the offset angle will holes.

  • Page 86: Ms Version M Sync Chart And Setting Instructions For Timing Staggered Units

    OPTIONS MS Version M Sync Chart and Setting Instructions For Timing Staggered Units Timeable Meter Timing Instructions 1. Install the timing indicator #804060 on the meter that is being timed. 2. Turn the main hex shaft until all the slack is removed from the drive chains and the center of a disc hole is aligned with the end of the singulator on the meter without the timing sprocket.
  • Page 87 OPTIONS uuf6xgz,1683011498109 -19-11MAY23-2/2 60-8 062623...

  • Page 88: Microsem Microgranular Insecticide System

    OPTIONS Microsem Microgranular Insecticide System Standard Microsem System The microsem system meters microgranular products such as insecticide and herbicide with precision. The system is ground driven, and the distribution mechanism only engages in the forward direction. The output is set by means of a transmission that is unaffected by a change in planting speed.

  • Page 89: How To Test For Insecticide Rates

    OPTIONS How To Test for Insecticide Rates And “X” is your Output in pounds per acre. Measure out a distance of 328 feet (100m). Example: Set the sprocket combination to: A=12, B=30, C=12. (This Row Spacing (S) = 60 cm (23.63") ratio = 0.24 or the number of Microsem shaft rotations for 1 drive wheel rotation).

  • Page 90: Possible Sprocket Combinations

    OPTIONS Possible Sprocket Combinations Possible Sprocket Combinations Ratios Obtained ----------0.21 Less Product ----------0.22 ----------0.24 ----------0.29 ----------0.33 ----------0.36 ----------0.4 ----------0.45 ----------0.48 or ----------0.48 ----------0.51 ----------0.54 NOTE: The bold sprocket numbers for the interchangeable B sprocket are standard. ----------0.57 ----------0.6 ----------0.63 The remaining sprockets for the interchangeable B sprocket are available on request.

  • Page 91: Dry Fertilizer

    If you place the fertilizer closer than 2”, it may cause the plant to burn and curb its growth. The Monosem dry fertilizer system is precisely metered by use of an auger. The standard output is adjustable The primary adjustment is set by using the lower double from 80-350 lbs/acre and up to 600 lbs/acre using a high sprocket.
  • Page 92 OPTIONS PAGE INTENTIONALLY LEFT BLANK 60-13 062623...
  • Page 93 PARTS ILLUSTRATIONS MS SERIES MOUNTED...
  • Page 94 PAGE INTENTIONALLY LEFT BLANK...
  • Page 95 INFORMATION Please record you planter identification information in box below for reference when ordering replacement parts for your Monosem planter. Planter Type:_____________________________________________ Serial Number:____________________________________________ Purchase Date:____________________________________________ Dealership:_______________________________________________ _______________________________________________ _______________________________________________ Suggestions For Successful Planting: 1. Choose a reasonable working speed adapted to the field conditions and desired accuracy.
  • Page 96 C. Exclusions. Excluded from this warranty are: 1) Used Products; 2) repairs or replacements caused in whole or in part by parts or components not manufactured by or obtained from Monosem or by service not performed by Monosem authorized personnel or an authorized Monosem dealer; 3) any Product that has...
