Model: S31501
Wireless Temperature/Humidity/Reed Switch/Glass Break Sensor
Wireless Temperature/Humidity/
Reed Switch/Glass Break Sensor
S31501
User Manual
Copyright©Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It
shall be maintained in strict confidence and shall not be disclosed to other parties, in whole or in
part, without written permission of NETVOX Technology. The specifications are subject to change without
prior notice.
Advertisement
Table of Contents
Related Manuals for netvox S31501
Summary of Contents for netvox S31501
- Page 1 User Manual Copyright©Netvox Technology Co., Ltd. This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX Technology. The specifications are subject to change without...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction ........................ 2 2. Appearance ......................... 3 3. Features........................3 4. S31501 Sensor Function ..................... 4 5. Set up Instruction ......................4 6. Data Report ......................... 6 7. Important Maintenance Instruction ................8... -
Page 3: Introduction
S31501 is a comprehensive detection device with temperature and humidity detection, door magnetic switch detection, and glass breaking state detection. The S31501 device is suitable for flow control, data collection, and other applications such as home intelligent terminals and industrial applications. -
Page 4: Appearance
Compatible with Amazon Sidewalk Powered by 2 x 3V CR2450 button batteries Simple operation and setting Low power consumption and long battery life Note: Please refer to http://www.netvox.com.tw/electric/electric_calc.html for battery life calculation and other detailed information... -
Page 5: S31501 Sensor Function
4. S31501 Sensor Function (1) Reed Switch Detect the opening and closing state of the reed switch. Open: report 1 Close: report 0 ➢The reed switch needs to be fixed when used, such as the double sided tape. (2) Temperature and Humidity Sensor Detection of temperature and humidity in ambient air. - Page 6 --- Network Joining--- Turn on the device to search the network. Never joined the network The green indicator stays on for 5 seconds: Success The green indicator remains off: Fail Turn on the device to search the previous network. Had joined the network (without The green indicator stays on for 5 seconds: Success factory resetting) The green indicator remains off: Fail...
-
Page 7: Data Report
6. Data Report When the device is turned on, it will immediately send a version package. Default setting: Max Interval: 0x0E10 (3600s) Min Interval: 0x0E10 (3600s) (Automatically checking the current voltage every Min Interval) Battery Change: 0x01 (0.1V) Temperature Change: 0x64 (1°C) Humidity Change: 0x14 (10%) Note: The device report interval will be programmed based on the default firmware. - Page 8 Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V. MaxTime Sleeping (MinTime) sleeping sleeping sleeping Wakes up and collects data Wakes up and Wakes up and 2.8V collects data collects data Does not report REPORTS 2.8V REPORT 2.8V Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e.
-
Page 9: Important Maintenance Instruction
7. Important Maintenance Instruction Your device is a product of superior design and craftsmanship and should be used with care. The following suggestions will help you use the warranty service effectively. • Keep the device dry. Rain, moisture, or any liquid might contain minerals and thus corrode electronic circuits.
