BP1
Pivot
Profile 80X40
M8 X 25
Slot-Nut M8
End-Cap
(LEFT)
Adapter
C3
1X
2X
2X
4X
4X
C5
BUILD 2X
B3
C1
B1
Instructions for the right side (B2)
are similar. See page 10 for the
orientation of the profile.
* Mind the orientation of the Slot-Nuts.
8
8 13
|
