Dimension; Safety Precaution; Warning Guidelines - MULTISPAN CYL-22 Installation Manuallines

Dimension

SAFETY PRECAUTION

All safety related codifications, symbols and instructions that appear in this operating
manual or on the equipment must be strictly followed to ensure the safety of the operating
personnel as well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might
impair the protection provided by the equipment.
Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.

WARNING GUIDELINES

WARNING : Risk of electric shock.
1. To prevent the risk of electric shock, power supply to the equipment must be kept OFF
while doing the wiring arrangement. Do not touch the terminals while power is
being supplied.
2. To reduce electro magnetic interference, use wire with adequate rating and twists of the
same of equal size shall be made with shortest connection.
3. Cable used for connection to power source, must have a cross section of 1mm or greater.
These wires should have insulations capacity made of at least 1.5kV.
4. A better anti-noise effect can be expected by using standard power supply cable for the
instrument.
66.35
22.5
NOTE:
All dimension are in mm.
