Terminal Connection:

Timing Diagram:

Power
Cyclic ON
ON Time
OFF Time
Cyclic OFF

Dip switch selection:

OFF
ON
Switch
Settings
Switch-1,2 & 3 for
time range selection
A1 25
15 26
CYL
16 28
18 A2
OFF Time
ON Time
SW 1 SW 2 SW 3
ON ON ON
OFF ON ON
ON OFF ON
OFF OFF ON
ON ON OFF
OFF ON OFF
ON OFF OFF
OFF OFF OFF
1 2 3 4
NO 1 C1
18 15
NO 2 C2
25
28
OFF Time
ON Time
OFF Time
ON Time
Multiplier
Range
(Knob Indication)
0.1 Sec X 10 1 Sec
10 Sec
1 Sec X 10
3 Sec X 10 30 Sec
10 Sec X 10 100 Sec
1 min X 10 10 Min
3 min X 10 30 Min
10 min X 10 100 Min
1 Hrs. X 10 10 hrs.
Switch 4
ON Cycle ON
OFF Cycle OFF
NC 1
16
NC 2
26
Switch 4 for
Mode selection
