HOMCOM A91-191 Using Instruction page 11

ASSEMBLY INSTRUCTIONS
Step1: Lift the equipment with back support frame (2) on the ground and insert the ring bolt
(11) in the joint hole.
Step2: Put the front support frame (1) on the ground to make it stand still and insert the
ball pin (10) into the hole of seat adjustment frame (5) and the front support frame (1).
Step3: The seat adjustment frame (5) has four holes to change the angle.
Put the backrest adjustment frame (6) in the fixed six slots of the back support frame (2) so
as to adjust the angle of the backrest cushion (8) as you like.
EN-5
