DEMO MANUAL DC2973A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 0 C3
4 1 C4
5 4 C5, C6, C7, C8
6 2 C9, C10
7 2 C11, C12
8 1 C13
9 1 C14
10 0 C15, C16
11 0 C17
12 2 D1, D4
13 2 D2, D3
14 4 E1, E2, E3, E4
15 3 E5, E6, E7
16 1 J1
17 1 J2
18 1 J3
19 4 JP1, JP2, JP3, JP4
20 1 L1
21 1 LB1
22 3 M1, M2, M3
23 3 M4, M5, M6
24 4 MH1, MH2, MH3, MH4 STANDOFF , NYLON, SNAP-ON, 0.50"
25 1 PCB1
26 3 R1, R2, R6
27 0 R3
28 2 R4, R5
29 3 R7, R16, R17
8
PART DESCRIPTION
CAP ., 10µF, X5R, 10V, 10%, 0603
CAP ., 150µF, X5R, 6.3V, 20%, 1210
CAP ., 180µF, ALUM POLY, OS-CON, 25V, 20%,
8mm × 11.9mm, SMD, RADIAL, E12
CAP ., 10µF, X5R, 6.3V, 20%, 0603
CAP ., 0.1µF, X5R, 10V, 20%, 0402
CAP ., 22pF, NP0, 50V, 5%, 0402
CAP ., 1µF, BJ, 10V, 20%, 0402
CAP ., 0.01µF, X7R, 25V, 10%, 0402
CAP ., 2.2µF, X5R, 10V, 20%, 0402
CAP ., 10F, ULTRA, 2.7V, –10/+20%, RADIAL, THT
CAP ., 0.12F, SUPERCAP , HIGH TEMP , 5.5V, 20%, 20mm ×
18mm × 2.5mm, SMD, DUAL CELL
LED, YELLOW, WATERCLEAR, 0603
LED, BRIGHT GREEN, WATERCLEAR, 0603
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK MILL-MAX, 2501-2-00-80-00-00-07-0
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK MILL-MAX, 2308-2-00-80-00-00-07-0
CONN., uUSB 2.0, RCPT., 5-PIN, 1PORT, REVERSE
MOUNT, R/A HORZ., TYPE B, FLANGELESS
CONN., HDR, MALE, 2x5, 1.27mm, VERT, ST, THT
CONN., HDR, MALE, 1x5, 2.54mm, VERT, ST, THT
CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT, 10u" Au
IND., 30Ω AT 100MHz, BEAD, 10%, 6A, 10mΩ, 0805, 1LN TDK, MPZ2012S300AT000
LABEL SPEC, DEMO BOARD SERIAL NUMBER
XSTR., MOSFET, N-CH, 20V, 1.4A, SOT-323, AEC-Q200
XSTR., MOSFET, DUAL, N-CH, 280mA, SOT-563
PCB, DC2973A
RES., 10k, 5%, 1/16W, 0402, AEC-Q200
RES., OPTION, 0603
RES., 0Ω, 1%, 0603, AEC-Q200
RES., 4.7k, 5%, 1/16W, 0402, AEC-Q200
MANUFACTURER/PART NUMBER
AVX, 0603ZD106KAT2A
MURATA, GRM188R61A106KAALD
SAMSUNG, CL10A106KP8NNNC
SAMSUNG, CL32A157MQVNNNE
PANASONIC, 25SVPF180M
MURATA, GRM188R60J106ME47D
MURATA, GRM188R60J106ME47J
TAIYO YUDEN, JMK107ABJ106MA-T
AVX, 06036D106MAT2A
NIC, NMC0603X5R106M6.3TRPF
TDK, C1608X5R0J106M080AB
WURTH ELEKTRONIK, 885012105010
WURTH ELEKTRONIK, 885012005057
TDK, CGB2A1JB1A105M033BC
WURTH ELEKTRONIK, 885012205050
WURTH ELEKTRONIK, 885012105013
NESSCAP CO. LTD., BCAP0010 P270 S01
NESSCAP CO. LTD., ESHSR-0010C0-002R7
CAP-XX, HA202F
WURTH ELEKTRONIK, 150060YS75000
WURTH ELEKTRONIK, 150060VS75000
TE CONNECTIVITY, 1932788-1
WURTH ELEKTRONIK, 62201021121
SAMTEC, TSW-105-07-L-S
SAMTEC, TMM-103-02-L-S
BRADY, THT-96-717-10
INFINEON, BSS816NWH6327XTSA1
DIODES INC., 2N7002VAC-7
KEYSTONE, 8833
ADI APPROVED SUPPLIER, 600-DC2973A
NIC, NRC04J103TRF
ROHM, MCR01MZPJ103
VISHAY, CRCW040210K0JNED
KOA SPEER, RK73Z1JTTDD
VISHAY, CRCW06030000Z0EA
NIC, NRC04J472TRF
VISHAY, CRCW04024K70JNED
Rev. 0
