I N T R O D U C T I O N
The Prommercial ® CM860 and CM660 are designed for a wide range of
commercial applications. When properly installed, this product will
provide years of high quality sound reproduction.
To obtain the full potential of this Sound Advance speaker, please read
all instructions before starting the installation.
P A R T S L
Each Sound Advance CM860 and CM660 speaker package includes the
following items:
(2) Sound Advance CM860 or CM660 speakers
(4) Tile support rails
(2) C shaped tile supports
(2) Paint plugs
(1) Cutout template
O P T I O N A L A C C E S S O R I E S
FlexBracket (part number 901358): Plastic template to reserve a hole
for the speaker in new construction. Designed to be used with the
RotoLock mounting system.
®
Coverplate (part number 91457): Designed to cover the hole made
by the FlexBracket until the speaker is installed.
O P T I O N A L A C C E S S O R I E S
FlexBracket (part number 901315): Plastic template to reserve a
hole for the speaker in new construction. Designed to be used with
the RotoLock ® mounting system.
Coverplate (part number 900643): Designed to cover the hole made
by the FlexBracket until the speaker is installed.
Adapter Ring (part number 900768): A plastic ring used to cover the
13" diameter hole created by low-grade commercial speakers.
I S T
C M 8 6 0
C M 6 6 0
I N S T A L L A T I O N
C M 8 6 0 & C M 6 6 0 P R O M M E R C I A L
S A F E T Y A G E N C Y
S o u n d A d v a n c e C M 8 6 0 S p e a k e r s
UL-2043: Suitable for use in air-handling spaces.
NFPA-70: 2002 National Electrical Code
NFPA-90A: Installation of Air Conditioning and Ventilation Systems,
Section 2-3.10.1(A)
Listed UL-1480 Standard For Safety For Speakers for Fire Alarm,
Emergency, and Commercial and Professional Use. Suitable for use
in air-handling spaces.
S A F E T Y A G E N C Y
S o u n d A d v a n c e C M 6 6 0 S p e a k e r s
NFPA-70: 2002 National Electrical Code
Listed UL-1480 Standard For Safety For Speakers for Fire Alarm,
Emergency, and Commercial and Professional Use.
1
I N S T R U C T I O N S
® S P E A K E R S
C O M P L I A N C E
C O M P L I A N C E
