- Page 1 USER MANUAL ENGLISH ACT Fresnel 50 WW Product code: 34011 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 ACT Fresnel 50 WW Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
ACT Fresnel 50 WW Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 LEDs Lifespan ............................... 4 Text Conventions ..............................4 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................5 Safety .................................. - Page 4 ACT Fresnel 50 WW Manually Defined ..........................26 Fixture Information ..........................27 Special Functions ............................27 DMX Channels ..............................28 Troubleshooting ..............................29 Maintenance ..............................30 Safety Instructions for Maintenance ......................30 Preventive Maintenance ..........................30 Basic Cleaning Instructions ........................30 Corrective Maintenance ..........................31 Replacing the Fuse ..........................31 Deinstallation, Transportation and Storage ....................
-
Page 5: Introduction
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec ACT Fresnel 50 WW ● Barndoor ● Color frame ●... -
Page 6: Symbols And Signal Words
ACT Fresnel 50 WW Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER serious injury or death. -
Page 7: Safety
ACT Fresnel 50 WW Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children For adult use only. - Page 8 ACT Fresnel 50 WW WARNING Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device.
-
Page 9: Requirements For The User
ACT Fresnel 50 WW Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ● The safety devices are not damaged. ●... -
Page 10: Description Of The Device
ACT Fresnel 50 WW Description of the Device The Showtec ACT Fresnel 50 WW is a compact, professional theater spotlight with a manually adjustable zoom and dimmer. It comes complete with a barndoor and a color frame. Front View Spring-loaded screw... -
Page 11: Accessories
ACT Fresnel 50 WW Accessories Fig. 04 Fig. 05 Safety eye – barndoor Safety eye – color frame Product code: 34011... -
Page 12: Product Specifications
ACT Fresnel 50 WW Product Specifications Model: ACT Fresnel 50 WW Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 57 W Fuse: T1 AL/250 V AC Physical: Dimensions: 245 x 165 x 239 mm (L x W x H) (without accessories) Weight: 1,8 kg (without accessories) Optics:... -
Page 13: Dimensions
ACT Fresnel 50 WW Dimensions Fig. 06 Product code: 34011... -
Page 14: Installation
ACT Fresnel 50 WW Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. Installation Site Requirements ●... -
Page 15: Angle Adjustment
ACT Fresnel 50 WW Angle Adjustment You can adjust the angle of the device with the adjustment handle (06). Turn the adjustment handle (06) counterclockwise to loosen it. Tilt the device to the desired angle (see Fig. 09). Turn the adjustment handle (06) clockwise to tighten it. Make sure that the device cannot move freely after the adjustment handle (06) is tightened. -
Page 16: Color Frame Installation
ACT Fresnel 50 WW Color frame Installation The ACT Fresnel 50 WW is delivered with a color frame. You can insert a color gel or a diffusion filter into the color frame. To install the color frame, follow the steps below: 01) Push the spring-loaded screw (01) and at the same time lift the color frame clip (02) and flip it backwards (see Fig. -
Page 17: Connecting To Power Supply
ACT Fresnel 50 WW Connecting to Power Supply DANGER Electric shock caused by short-circuit The device can be powered by 100–240 V 50/60 Hz AC mains power. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. -
Page 18: Setup
ACT Fresnel 50 WW Setup Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. Stand-alone Setup When the ACT Fresnel 50 WW is not connected to a controller or to other devices, it functions as a stand- alone device. -
Page 19: Dmx Linking
ACT Fresnel 50 WW Fig. 16 DMX Linking To connect multiple devices on one DMX data link, follow the steps below: Connect the DMX OUT connector on the lighting controller to the DMX IN connector on the first device with a 3-pin DMX cable. Connect the DMX OUT connector on the first device to the DMX IN connector on the second device with a 3-pin DMX cable. -
Page 20: Dmx Addressing
ACT Fresnel 50 WW DMX Addressing In a setup with multiple devices, make sure that you set the DMX starting address of each device correctly. The ACT Fresnel 50 WW has 2 personalities: 1 channel and 2 channels. If you want to connect multiple devices on one data link and use them in 2-channel mode, for example, follow the steps below: Set the starting address of the 1 device on the data link to 1 (001). -
Page 21: Operation
ACT Fresnel 50 WW Operation Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for. This device is intended for use as a professional theater spotlight and is suitable for indoor use only. This device is not suitable for households or general lighting. -
Page 22: Control Panel
ACT Fresnel 50 WW Control panel A) OLED display ENTER button C) DOWN button D) UP button MENU button Fig. 19 ● Use the MENU button to exit the current submenu, to return to the Main Menu and to return to the start screen. -
Page 23: Menu Overview
ACT Fresnel 50 WW Menu Overview Product code: 34011... -
Page 24: Main Menu Options
ACT Fresnel 50 WW Main Menu Options The main menu has the following options: Press the UP/DOWN buttons to navigate through the main menu. Press the ENTER button to open the submenus. DMX Functions In this menu you can configure the DMX settings of the device. 01) Press the UP/DOWN buttons to scroll through the following options: ●... -
Page 25: Dmx Channel Mode
ACT Fresnel 50 WW DMX Channel Mode In this pop-up submenu you can select the DMX channel mode. Press the UP/DOWN buttons to select the DMX channel mode. There are 2 options available: ● 1-channel mode ● 2-channel mode Press the ENTER button to confirm the selection. DMX Fail In this pop-up submenu you can determine the behavior of the device in case there is no DMX signal. -
Page 26: Manual Settings
ACT Fresnel 50 WW Manual Settings In this pop-up submenu you can select how to operate the device manually. Press the UP/DOWN buttons to scroll through the following 2 options: ● Rotary Knob: You can control the device manually with the manual dimmer control (15). ●... -
Page 27: Display Settings
ACT Fresnel 50 WW Display Settings In this menu you can adjust the display settings of the device. Press the UP/DOWN buttons to select one of the following 3 options: ● Display Inverse: The OLED display will be rotated at 180° (NO/YES) ●... -
Page 28: Fixture Information
ACT Fresnel 50 WW Fixture Information In this menu you can view the LED operating hours and the firmware version of the device. Press the UP/DOWN buttons to select one of the following 2 options: ● Fixture Hour: Provides information about the total hours of operation of the LEDs ●... -
Page 29: Dmx Channels
ACT Fresnel 50 WW DMX Channels 1 CH 2 CH Function Value Setting Dimmer 000–255 Brightness adjustment (0–100 %) 000–019 Closed/Blackout 020–024 No strobe 025–064 Strobe, from high to low frequency 065–069 No strobe 070–084 Strobe, fast close/slow open, from high to low frequency 085–089 No strobe 090–104... -
Page 30: Troubleshooting
ACT Fresnel 50 WW Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 31: Maintenance
ACT Fresnel 50 WW Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ●... -
Page 32: Corrective Maintenance
ACT Fresnel 50 WW Corrective Maintenance The device does not contain user-serviceable parts. Do not open the device and do not modify the device. Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for more information. Replacing the Fuse DANGER Electric shock caused by short-circuit... -
Page 33: Deinstallation, Transportation And Storage
ACT Fresnel 50 WW Deinstallation, Transportation and Storage Instructions for Transportation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. -
Page 34: Disposal
ACT Fresnel 50 WW Disposal Correct disposal of this product Disposal of Old Electrical and Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product, its packaging or documents indicates that the product shall not be treated as household waste. -
Page 35: Approval
ACT Fresnel 50 WW Approval Check the respective product page on the website of Highlite International (www.highlite.com) for an available declaration of conformity. Product code: 34011... - Page 36 ©2022 Showtec...
