2. OPERATING THE JABLOTRON 100 SYSTEM
The various types of access modules
and their combinations:
RFID Card reader
allows control of the system using
segments and user authorization using
contactless method (RFID card/tag).
When unsetting the alarm using the segment buttons,
user authorization is always required. When setting the alarm
and controlling automated processes using the segment
buttons, user authorization is optional for each segment.
Recommended contactless chips: JABLOTRON 100, Oasis and Azor or other third-party chips compatible
with 125 kHZ EM Unique standard. If higher security is required the alarm system can be set up to use confi rmed
authorization using RFID chips and codes (optional).
If the users want to control multiple segments simultaneously, he must authorize himself and then press
segments of the particular sections subsequently. This way the user can unset for example the house
and the garage within one single authorization.
The keypad authorization code can consist of up to eleven digits: a prefi x (one to three digits),
an asterisk * (which separates the prefi x and main code), and a 4,6 or 8-digit code depending
on confi guration (for example : 123*12345678, or 1*12345678). All users can change their own codes
which follow the prefi x. The code can be changed from the LCD keypad, the J-Link software
(Windows XP and higher) or MyJABLOTRON app.
The prefi x can be omitted for premises with a smaller number of users. In this case only
a code is required (4,6 or 8-digit code depending on confi guration). These codes can be changed
only by the system administrator or a service technician.
Keypad with a card reader
the user can control the system using
segments and authorization, either by
entering a code or the contactless me-
thod (RFID card/tag), or a combination
of both for higher security.
A user can be authorized by entering their assigned code or
using their RFID card/tag. Each user can have
one code and up to two RFID chips (cards or tags).
Keypad with display and card reader
the user can control the system
using segments and authorization,
using either a code, the contactless
method (RFID card/tag), both code
and card/tag for higher security, or by
authorizing and using the options avai-
lable on the keypad's LCD display.
7
