ASSEMBLY INSTRUCTIONS
Quadro Square
Boardroom table
Size: 1100mm x 1100mm
STEP 01
Using Allen Key provided, attach 2 plastic brackets per leg (D)
(as per picture above) using M6x20MM (G) Socket head screw
STEP 03
Secure 1000mm beam (C)
using screws provided
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 02
G
Using Allen Key provided, attach M8x20MM Socket head (F)-
screw socket half way into leg for both legs (B)
F
Page 3 of 5
