Conspit GT-lite Quick Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CONSPIT GT-lite
Quick Guide
Elite Sim-racing Development

Advertisement

loading
Need help?

Need help?

Do you have a question about the GT-lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conspit GT-lite

Summary of Contents for Conspit GT-lite

  • Page 1 CONSPIT GT-lite Quick Guide Elite Sim-racing Development...

  • Page 2: Product Disclaimer

    If you have any questions about this Disclaimer or the following product safety tips and operating specifications, you can consult through support@conspit.com. In the process of reading this Disclaimer and the following product safety tips and operating specifications, you should immediately stop using this product if you do not agree with any of the contents.
  • Page 3 - If the product is damaged or cannot be used properly, please stop using it immediately and consult CONSPIT's after-sales customer service. Continuing to use it may cause further damage to the product. - Do not attempt to repair the product or its accessories by yourself.
  • Page 4 With a well-developed ergonomic system, it offers powerful adjustability to meet the personal preferences of each driver. GT-lite is designed with an Easy-Assembly Structure. Please verify all the components listed in the packing list before starting the installation.

  • Page 5: Packing List

    Packing list M6*12mm M8 flange nuts M8 nylon anti-loose nuts M8*16mm Round head hex bolts (26 pieces) (6 pieces) Hex bolts (18pieces) (26 pieces) 13mm M8*16mm M8 Spacer M8*100mm open-end wrench round head hex bolts （5 pieces） Semi-tooth bolts (5 pieces) （1 ）...
  • Page 6 Packing list A×2 B×2 C×2 F×2 E×2 D×1 G×1 H×1 *Safety Warning: Contains metal parts with sharp edges, stay safe when installing. - 5 -...
  • Page 7 Packing list (pre-assembled version) * Skip to page 13 if your GT-lite is pre-assembled version. M6*12mm M8 flange nuts M8*16mm Round head hex bolts M8 Spacer （5 pieces） (22 pieces) round head hex bolts (5 pieces) （6 pieces） Hex wrench 6.0 13mm Hex wrench 5.0...
  • Page 8 Installation of seat base Parts required for this step: M6*12mm M8*16mm Hex bolts （4 pieces） M8 flange nuts （ 4 pieces） Round head hex bolts (12 pieces) A×2 B×2 C×2 D×1 - 7 -...
  • Page 9 M6*12mm Round head hex bolts （8 pieces） * Do not tighten the bolts in this step for the convenience of subsequent installation steps. The position shown in the picture is the recommended seating position. However, you can adjust the rear mounting position of the L-shaped plate to your preference to change the angle of the seat.
  • Page 10 M6*12mm Round head hex bolts （ （4 pieces） ） *Tighten all the fasteners in the previous steps before continue installing. - 9 -...
  • Page 11 Installation of the wheelbase supporting pillars Parts required for this step: M8 nylon anti-loose nuts M8*100mm M8*16mm (6 pieces) Semi-tooth bolts (4 pieces) Hex bolts (2 pieces) E×2 F×2 - 1 0 -...
  • Page 12 * During installation, please ensure that the heights of the pillars on both sides are the same. We recommend using this hole position as initial set-up, but if you prefer a different wheelbase height, you can adjust the fixing hole position on the pillar to your desired setting.
  • Page 13 Installation of pedal mounting plate G×1 Parts required for this step: M8*16mm Hex bolts M8 flange nuts (4 pieces) (4 pieces) Because the angle of the pedal surface of different brands of pedals may differ, we suggest that you install your pedals on the pedal base before tightening the bolts shown in the figure below to facilitate the adjustment of the driving position.
  • Page 14 Installation of wheelbase mounting plate Parts required for this step: M6*12mm M8*16mm M8 flange nuts Round head hex bolts (8 pieces) Hex bolts (4 pieces) (4 pieces) H×1 - 1 3 -...
  • Page 15 Please install bolts of the corresponding specifications according to the instructions provided by your base manufacturer. (GT-lite provides M6*12mm round head hex bolts) Supported devices: Fanatec: Clubsport V1, Clubsport V2,Clubsport V2.5, CSL, CSL ELITE, DD1, DD2 Thrustmaster: T300, T500 RS, TS-PC Racer, TX-XW Racer,...
  • Page 16 M6*12mm Round head hex bolts (4 pieces) M8*16mm M8 flange nuts hex bolts (4 pieces) (4 pieces) - 1 5 -...

  • Page 17: Seat Angle Adjustment

    Seat Angle Adjustment * The middle mounting hole is recommended to be the first option Steering Wheel Position Adjustment Pitch angle adjustment Front/rear adjustment - 1 6 -...
  • Page 18 Height adjustment - 1 7 -...
  • Page 19 Pedal Pitch Angle Adjustment Pitch angle adjustment A. The flatter angle of the pedal （-12°— 5°） base is suitable for pedals with a more vertical pedal surface (such as CONSPIT CGP&CPP). - 1 8 -...
  • Page 20 Installation of M-DVF kit M3*8mm bolt (2 pieces) USB cable DC 12V power block *Optional for M-DVF kit users Knob VIB controller Motor - 1 9 -...
  • Page 21 Connect the motor to the knob Mount the controller to the rig and connect the knob to the controller. M3*8 rounded head hex bolts (2 pieces) Plug DC 12V power in, then connect the controller to PC through USB cable. to PC DC 12V in - 2 0 -...
  • Page 22 Installation of seat J×1 Parts required for this step： M8*16mm M8 flange nuts Round head hex bolts (4 pieces) (4 pieces) - 2 1 -...
  • Page 23 Pull up the lever located underneath the seat to unlock the slide rails, then pull out the inner slide rails as indicated in the diagram. *Ensure that the length of both sides of the slide rails is equal. Mount the rear end of the seat slide rails to the rig. M8*16mm M8 flange nuts round head hex bolts (2 pieces)
  • Page 24 Pull up the seat slide rail lever and move the seat backward. Mount the front end of the seat slide rails to the rig. M8*16mm round head hex bolts (2 pieces) M8 flange nuts (2 pieces) - 2 3 -...
  • Page 25 Installation of the monitor bracket (need to be purchased separately) Parts required for this step: M8*16mm M8*30mm M6 flange nuts (1 pieces) black hex bolt (4 pieces) black hex bolt (3 pieces) M6*12mm M4*12mm M8 flange nuts (3 pieces) white round head bolt (12 pieces) black hex bolt (4 pieces) K×1 L×1...
  • Page 26 M8*16mm black hex bolts (4 pieces) M6*12mm white round head bolts (2 pieces) - 2 5 -...
  • Page 27 M8*30mm black hex bolts (2 pieces) * Do not tighten the bolts here for subsequent installation M8 flange nuts (2 pieces) M8 flange nuts (1 pieces) M8*30mm black hex bolt (1 pieces) - 2 6 -...
  • Page 28 * The reinforcing rod for the monitor M6 flange nuts stand can be optionally installed if the weight of the monitor is relatively heavy (such as a 49-inch screen). M6*12mm white round head bolts (3 pieces) M6*12mm white round head bolts (4 pieces) Pitch angle adjustment.
  • Page 29 M4*12mm black hex bolts (4 pieces) Mounting holes on the back of the monitor. *Only supports installation of monitors with the template of 100mm*100mm between mounting holes. Monitor height adjustment. - 2 8 -...
  • Page 30 Installation of the shifter/handbrake bracket and bottle holder (need to be purchased separately) M8*55mm black hex bolts (3 pieces) M6*12mm white round head bolts (5 pieces)） - 2 9 -...
  • Page 31 To ensure a secure fit during use, please tighten the bolts here with a greater force. Height adjustment. M8*55mm black hex bolts （ 3 pieces） M6*12mm white round head bolts （ 3 pieces） Front and back adjustment. - 3 0 -...
  • Page 32 M6*12mm white round head bolts （ 2 pieces） - 3 1 -...
  • Page 33 Installation of the mouse pad(need to be purchased separately) M6*12mm white round head bolts （ 4 pieces） - 3 2 -...
  • Page 34 M6*12mm white round head bolts （ 2 pieces） M6*12mm white round head bolts （ 2 pieces） - 3 3 -...
  • Page 35 Installation of keyboard holder (need to be purchased separately) M8*45mm black hex bolt （ 1 pieces） M6*12mm white round head bolts （2 pieces） M8 nylon anti-loose nut ABS pillars and (1 pieces) nylon washers - 3 4 -...
  • Page 36 M6*12mm white round head bolts （2 pieces） - 3 5 -...
  • Page 37 M8*45mm black hex bolt （ 1 pieces） M8 nylon anti-loose nut (1 pieces) Installation illustration. Bolt ABS Isolation column Nylon Gasket nylon anti-loose nut - 3 6 -...
