- Page 1 300 GT Function Guide Supports: 300 GT V1.0 Conspit R&D All rights reserved@2025...
-
Page 2: Table Of Contents
3. Games’ Telemetry List ..................................20 4. Revision History .....................................21 5. Disclaimer and Copyright Notice ..............................21 There may be slight differences between the visuals and descriptions presented and the actual situation. Please refer to the actual circumstances. Conspit 300 GT Function Guide V1.0... -
Page 3: Idle Mode
If the steering wheel buttons, knobs, paddles and other components are not operated, the 300 GT will enter the idle mode, the screen and lighting will dim after 1 minute and turn off after 5 minutes. The 300 GT can be awakened by operating the control input again or entering the game to receive signals. - Page 4 Check the connection status of the products in the SimHub software at the middle of the homepage. If it is red, please launch the SimHub software to access more features. Double-click the device name in the “Connected Devices” list, or click the corresponding icon of the device to enter the detailed settings pages. Conspit 300 GT Function Guide V1.0...
-
Page 5: Lights & Buttons Settings
In each setting page, in the "Config" section at the bottom left, you can select, rename, add, export, import, or delete configs. If you need to customize the settings, please create a new config, click “Save” after setting is completed, or modify the official default config and click ”Save as”. Conspit 300 GT Function Guide V1.0... - Page 6 When setting the light for a single button, you first need to turn off the "Global Button Color" option. Click on an individual button on the ops-panel to enter the corresponding settings interface for each button. Conspit 300 GT Function Guide V1.0...
- Page 7 Shift Lights Settings: Click on the RPM rev lights on the panel to enter the settings interface for shift lights. Conspit 300 GT Function Guide V1.0...
- Page 8 Knob Lights Settings: Click on the knobs on the panel to enter the settings interface for knob lights. Conspit 300 GT Function Guide V1.0...
- Page 9 After the settings are completed, click on the dropdown box of "Lighting Preview" to preview the lights you just set (while keeping the “SimHub Mode” and "Global Button Color" option turned off). Global Brightness Adjustment: Adjust the brightness of the lights and screen in the "Global Brightness" section). Conspit 300 GT Function Guide V1.0...
- Page 10 Click on the dropdown box of “Dash Switching Hotkey” to select the key or wheel you wish to bind. The selected component will be highlighted in purple. Enable SimHub Mode: Turn on this mode to adjust lighting effects in SimHub. Conspit 300 GT Function Guide V1.0...
-
Page 11: Controls Settings
2.4 Controls Settings Click on "Controls" in the menu bar to enter the controls settings interface. Knob Mode Settings: Each knob can be set as “Rotary Switch Mode” or “Encoder Mode”. Conspit 300 GT Function Guide V1.0... - Page 12 Then click on “Encoders Remap” in the Advanced Controls Section. By rotating Knob 1, the key mappings of P-Encoder 2 & 3 can be dynamically remapped, with customizable functions displayed on the dashboard, enables a single physical button to perform multiple inputs. Conspit 300 GT Function Guide V1.0...
- Page 13 To facilitate memory, after binding the functions respectively, you can type in prompts of the function’s names on this page, and the corresponding prompts will be displayed on the steering wheel's screen when central knob 1 is rotated. Conspit 300 GT Function Guide V1.0...
- Page 14 Conspit 300 GT Function Guide V1.0...
-
Page 15: Paddles Settings
Click on "Paddles" in the menu bar to enter the paddles settings interface. Paddle Shift Response Display: Press the paddle shifter group and check the response on the screen. Upon pressing, the corresponding paddle should be highlighted with a purple outline in the driving software. Conspit 300 GT Function Guide V1.0... - Page 16 Calibrate the left and right shifter paddles separately: When pressing and holding one of the shifter paddles, click the calibration button corresponding to that paddle to complete the calibration. Conspit 300 GT Function Guide V1.0...
- Page 17 Click "MAX" to calibrate the maximum value when the paddle is fully pressed. Clutch Mode Click on the dropdown menu for "Clutch Mode," where you can select from modes such as [Dual Axis], [Manual], and [Set Bite Point]. Conspit 300 GT Function Guide V1.0...
- Page 18 Click to select the "Set Bite Point" clutch mode. Drag the purple slider located below the "Clutch Mode" display section to adjust the bite point. (Note: Adjustments to the clutch bite point will only be visible after clicking "Save to Flash".) Conspit 300 GT Function Guide V1.0...
-
Page 19: Firmware Update
Click the ">" button on the right side of the pop-up window to select the firmware you have downloaded for the corresponding product; then click “Confirm” to update the firmware. Note: 1) If the progress bar gets stuck, please unplug and replug the USB cable and try again. Conspit 300 GT Function Guide V1.0... -
Page 20: One-Click Game Configuration
Enter Homepage, click on “One-Click Game Configuration” button to configure. You can also click on the "Settings" icon in the bottom left corner to enter the driver settings interface, and click on "One-click Game Configuration" to configure. Conspit 300 GT Function Guide V1.0... -
Page 21: Games' Telemetry List
Automobilista 2 No need to set up Race Room No need to set up One-click configuration is required within Conspit Link 2.0, rFactor 2 Enable telemetry plugin in the game settings. Le Mans Ultimate One-click configuration is required within Conspit Link 2.0 Dirt Rally 2.0... -
Page 22: Revision History
Conspit's proposals, specifications, or samples elsewhere. Conspit does not guarantee that this document does not infringe upon third-party rights and shall not be held liable for any infringement of intellectual property rights arising from the use of the information contained in this document.
